Logik L26HED13I Quick Start Manual

Quick Start Guide
26" HD Ready LED TV
with DVD Player
L26HED13I
L26HE13I
(Non-DVD version)

Unpacking

Remove all packaging from the TV. Retain the packaging.
If you dispose of it please do so according to local regulations.
TV
TV Stand
Remote Control/AAA Batteries x 2
Screw x 4
Component Adapter Cable (YPbPr)
Composite Adapter Cable (AV)
Instruction Manual

Operating Your Remote Control

1. Press and lift the back cover to
open the battery compartment
of the remote control.
2. Insert two AAA size batteries.
Make sure to match the (+) and
( - ) ends of the batteries with
the (+) and ( - ) ends indicated
in the battery compartment.
3. Close the battery compartment
cover.
L26HED13I_QSG.indd 1

Installing the Base Stand

1. Disconnect all cables connected to the TV.
2. Lay the TV down on a flat surface ideally on the edge of a table so the
base of the TV slightly overhangs the edge of the table, with the back
side facing up. Please make sure a soft cushioned material (such as
a dry bath towel or thick piece of foam)
is placed beneath the screen.
3. Place the
plastic collar onto
the neck of the
TV stand as shown.
4. Place the glass over the screw holes on the neck of the TV stand
and attach using the 4 screws provided. Make sure you attach the
glass the right way around, so that the majority of the glass stand is
towards the front of the TV.
Cushioned
material
*TV stand installation may vary depending on model

Connecting the Aerial

Connect one end of the RF coaxial cable to the aerial
socket on the wall and the other end of the cable to
the AERIAL IN socket at the rear of your TV.

Connecting to the Mains Socket

1. Connect the mains adapter to the mains socket
after you have completed all the connections. At
this stage, the TV switches to standby mode. The
red LED indicator will illuminate on the front panel
of the TV.
2. In standby mode, press the
button on the
remote control to turn the TV on. The red LED
indicator will turn blue.

Turning On and Tuning In the TV

Auto Installation
- Setup 1 -
Country: Ireland
Austria
Please ensure your
aerial is plugged in Slovskia
before tuning in your TV.
Croatia
Serbia
Next Page
Move Enter Exit
Ok Exit
The first time you turn the TV on, the above menu will appear
on the screen.
Please ensure the aerial is plugged in.
1. Press the buttons to select your desired country.
The default country is Ireland. Then press OK.
Auto Installation
- Setup 3 -
Auto Search
DTV
Previous Page
Move
Enter Exit
OK Exit
3. Press the OK button. Your TV will now start to tune in all
available channel.
Well done
, your new TV is now ready to use. You will find that there are many exciting features available. To get to know all these features,
please take some time to read the instruction manual provided with your TV.
If after reading the instruction manual you have additional questions related to the use of your TV please call our Call Centre on 1 890 818 575.
Our Customer Contact Centre is open Monday-Saturday 8am-8pm or Sunday 8am-6pm.
To the mains
To the mains socket
socket
PC
VGA (PC) Coaxial
Audio In
DC IN Out
SCART
Auto Installation
- Setup 2 -
Language: English
French
Italian
Spanish
Netherland
Previous Page Next Page
Move Enter Exit
OK Exit
2. Press the buttons to select your desired language. The
default language is English. Then press OK.
Auto Installation
DTV channels found:
0
Radio channels found:
0
CH:22 482000 KHz
Process 9%
Exit
Exit
The above menu will appear, the tuning process will take a few
minutes. When a picture appears your TV has finished tuning.
