- Page 1 DTB Series Battery Powered Digital Thermometer USER MANUAL KOBOLD Instruments Inc. 1801 Parkway View Drive Pittsburgh, PA 15205 Phone: 412-7 88 -2830 Fax: 412-788-4890 www.koboldusa.com Rev. 2-11/2013...
- Page 2 1. Description 3.2.2. Installation: these devices must be installed by The DTB series Digital Temperature Gauges are a com- qualified personel taking all necessary precautions. The plete solution for most industrial temperature monitoring installation should adhere to all local regulations.
- Page 3 4.5. Wiring Note that the LCD based DTB is a battery powered device and needs no wiring. 5. Limits 5.1. Pressure Limits The pressure limits for the probe is 500 psig, but the pressure limits for the process connection could be considerably less.
-
Page 4: Error Codes
8. Error Codes 9. Dimensions 1.86 ” The DTB is programmed to display the following error conditions. Code Description 3.19 ” 3.10 ” Err1 Open RTD condition Err2 Shorted RTD condition Err3” General Error Valid reading, but out of display range low ompression 1.25”...
