M30FP-3RCA-110 Video/Audio Adapter Installation Instructions
General
The 3-port RCA-type adapter provides baseband video and audio connectivity to 24 AWG unshielded twisted-
pair (UTP) wiring. The 3RCA adapter connects audio and video electronics to building wiring utilizing a 110
insulation displacement connecting (IDC) block. Each adapter connects to four pairs of a 4-pair UTP cable and
has red, white, and yellow color-coded connectors.
The adapter is compatible with the M13FP/M26FP flexible faceplates and the M204SMB/M208SMB surface
mount boxes and is available in four colors.
Ordering Number
760017541
M30FP-3RCA-110-003
760017558
M30FP-3RCA-110-246
760017566
M30FP-3RCA-110-262
760017574
M30FP-3RCA-110-270
How to Contact Us
•
To find out more about CommScope
•
For technical assistance:
-
Within the United States, contact your local account representative or technical support at
1-800-344-0223. Outside the United States, contact your local account representative or
Authorized Business Partner.
-
Within the United States, report any missing/damaged parts or any other issues to
CommScope Customer Claims at 1-866-539-2795. Outside the United States, contact your
local account representative or Authorized Business Partner.
CAUTION
Follow local regulations and applicable codes. Refer to ANSI/TIA/EIA-568-B for safe installation
practices.
www.commscope.com
Catalog Number
®
products, visit us on the web at
© 2012 CommScope, Inc. All rights reserved
Color
Black
Ivory
White
Gray
http://www.commscope.com/
Instruction Sheet 860336478
Issue 4, December 2012
For RoHS Inquiries:
CommScope Inc.
Page 1 of 3
Corke Abbey, Bray
Co. Dublin, Ireland
