CLAS B
Product Guide
Release 01_01.10.08

Advertisement

Table of Contents
loading

Related Manuals for Ariston 24 CF

Summary of Contents for Ariston 24 CF

  • Page 1 CLAS B Product Guide Release 01_01.10.08...

  • Page 2: Table Of Contents

    INDICE VALUE PROPOSITIONS........................5 1.1 ADVANTAGES FOR THE END USER.................... 6 1.1.1 Main advantages for the end user ..................6 1.1.2 1.2 ADVANTAGES FOR THE INSTALLER................... 7 1.2.1 Main advantages for the installer..................7 1.3 ADVANTAGES FOR SERVICE TECHNICIANS................8 1.3.1 Main advantages for the service Technicians ..............
  • Page 3 6.1 ZONE MANAGEMENTS HEATING MODULES ................39 6.1.1 Single-temperature zone management heating module............39 6.1.2 Multi-temperature zone management heating module ............40 6.2 WIRED THERMOREGOLATION ACCESSORIES .................41 6.3 WIRELESS TERMOREGOLATION ACCESSORIES ..............42 6.4 GAS ACCESSORIES ........................43 6.5 HYDRAULIC ACCESSORIES .......................44 6.5.1 First installation hydraulic kit ....................44 6.5.2 Replacement kits .......................45 TECHNICAL DATA ..........................46...
  • Page 4 Al fine di facilitare la lettura del Product Guide, i vari argomenti trattati verranno contrassegnati con simboli che si riferiscono alle “value propostions” principali CUSTOMISED COMFORT AND ENERGY SAVING MULTIFUNCTIONAL INTERFACE WITH DIGITAL DISPLAY EASINESS OF INSTALLATION Pag. 4 di 48...

  • Page 5: Value Propositions

    1 VALUE PROPOSITIONS The new CLAS B boiler from Ariston is a fusion of technology and reliability, of comfort and high performance levels. CUSTOMISED COMFORT AND ENERGY SAVING The innovative functions offered by CLAS B boiler enable the user to achieve maximum comfort within a room, while assuring minimum energy consumption and maximising energy efficiency.

  • Page 6: Advantages For The End User

    1.1 ADVANTAGES FOR THE END USER With CLAS B, Ariston is hoping to bring the boiler closer to the requirements of end users, giving them the opportunity of interacting with their own appliance through a MULTIFUNCTIONAL INTERFACE WITH DIGITAL DISPLAY, which can be used to check appliance operation, ensure there is always a supply of hot water and guarantee the most suitable room temperature all day.

  • Page 7: Advantages For The Installer

    ADVANTAGES FOR THE INSTALLER The CLAS B is easy to install because it is compact and light. Set up for installation with kit barrette and wide range substitution kits are available. The boiler is set up for use in a system which uses solar panels in series and in parallel and, where forced circulation is used, it can control the system without the addition of an extra P.C.B.

  • Page 8: Advantages For Service Technicians

    ADVANTAGES FOR SERVICE TECHNICIANS The CLAS B boiler is easy to maintain. Thanks to frontal access for all components, the boiler is able to offer reduced maintenance times and most of the work can be performed without using tools. The two “stratification” storages ensure high performaces for long time and don’t need any maintenance work due to deposit of limestone on internal parts.

  • Page 9: Main Features Intended For The End User

    CLAS B boiler from Ariston automatically recognises how many devices are connected to the boiler, and what type of devices these are (ON/OFF Room Thermostat, Room Sensor, Outdoor Sensor, Clima Manager), optimising the operation of the appliance.

  • Page 10: Optimised Power Modulation

    2.1.2 Optimised power modulation This type of modulation, arising from the activation of the AUTO function, consists of the following points: At the start, the power is reduced by 30% in relation to the Maximum Heating Power and is Central Heating then increased gradually;...

  • Page 11: Quantifying Energy Savings

    2.1.4 Quantifying energy savings If, for example, a 15-year old boiler is replaced with an Ariston Clas B, an immediate energy saving of 10% is obtained. RISPARMIO CLAS B 15-year old (normal operation) installation If the AUTO function is active, more than a better room comfort, it is assured a gas saving of more than 15%.

  • Page 12: Comfort Acustico (La Caldaia Che Toglie Il Disturbo)

    2.1.6 Comfort acustico (La caldaia che toglie il disturbo) Thanks to the wide heating power modulation range, the CLAS B boiler is able to constantly adapt to the requested comfort level. This important feature enables the appliance to operate with a minimum energy consumption and guarantees a high level of acoustic comfort, thanks to the modulating fan and modulating circulation pumps that operate most of the time at a reduced speed, resulting in a considerable reduction in the amount of noise produced and electrical consumption.

  • Page 13: End User Faqs

    END USER FAQS Who is responsible for the independent heating system? The owner or occupant is responsible for the system. What does “Self-diagnosis” mean? Self-diagnosis means having immediate information related to any operating errors which occur, whether temporary (these can be resolved automatically by the boiler) or persistent (these require the intervention of an authorised Assistance Centre).
  • Page 14 It is nevertheless recommended that the installation is checked and serviced every year, even if it is simply to ensure that all the components are operating efficiently and to avoid unnecessary consumption of excess gas. How can I save energy? Here are a few pieces of advice for saving energy and heating the room and domestic hot water in an environmentally-friendly way: Activate the AUTO function, to optimise the performance of the boiler in line with the type of system,...

  • Page 15: Main Features For The Installer

    3 MAIN FEATURES FOR THE INSTALLER 3.1 OVERALL DIMENSIONS 3.1.1 Open chamber LEGEND Central heating flow Domestic cold water inlet Domestic hot water flow Central heating return Gas inlet Pag. 15 di 48...

  • Page 16: Sealed Chamber

    3.1.2 Sealed chamber LEGEND Central heating flow Domestic cold water inlet Domestic hot water flow Central heating return Gas inlet Pag. 16 di 48...

  • Page 17: Flue Connections

    FLUE CONNECTIONS 3.2.1 Open-chamber system 3.2.2 Coaxial system DISCHARGE MAX LENGHT MODEL I TIPE 60/100 80/125 60/100 80/125 60/100 80/125 60/100 80/125 Pag. 17 di 48...

  • Page 18: Twin Pipe System (80-80)

    3.2.3 Twin pipe system (80-80) DISCHARGE MAX LENGHT MODEL I TIPE 36 (S1=S2) 80/80 24 (S1=S2) 60 (S1=S2) 80/80 40 (S1=S2) 84 (S1=S2) 80/80 56 (S1=S2) S1=1 (S2=83) 80/80 S1=1 (S2=55) 84 m 137 Pa B23/B23 80/80 84 m 128 Pa Pag.

  • Page 19: Set Up For External Controls

    3.3 SET UP FOR EXTERNAL CONTROLS The control panel may be fitted with the following P.C.B.s which are capable of connecting the boiler operation with the most modern and advanced types of system: 1: BUS INTERFACE (cod.3318229): connects all the modulating peripherals which communicate via BUS ….

  • Page 20: Accessories Supplied

    The packaging, in card and polystyrene, has been designed in such a way so as to make easier the movement and transportation, without damaging the product. The name of the product, a picture and the ARISTON brand graphics are shown on the outside.

  • Page 21: Paper Template For Wall Installation

    3.4.2 Paper template for wall installation Inside the standard hydraulic kit (specific market required). Pag. 21 di 48...

  • Page 22: Temperature Control Accessories

    TEMPERATURE CONTROL ACCESSORIES he new accessories for climatic control are available in two different versions: Wired (with wires) and Wireless (without wires) 3.5.1 Wired LEGEND Wired modulating room sensor Wired ON/OFF room thermostat RSw: RTw: Wired modulating Clima Manager Wired outdoor sensor RCw: ESw: Wired ON/OFF time-thermostat (T-Control)

  • Page 23: Wireless

    3.5.2 Wireless LEGEND RM ws Wireless receiver(for modulating devices) ESws: Wireless outdoor sensor Wireless receiver(for ON/OFF devices) CTws: Wireless ON/OFF time-thermostat (T-Control) R ws RCws: Wireless modulating Clima Manager (BUS) RP ws: Wireless display RSws: Wireless modulating room sensor (BUS) Pag.

  • Page 24: Electric Connections Box

    3.5.3 Electric connections box All the thermoregulation devices can be connected to the boiler by means the “Electric connections box” easily accessible removing only one screw (see a picture). Pag. 24 di 48...

  • Page 25: Comfort

    COMFORT 3.6.1 DHW comfort The innovative system for Domestic Hot Water is designed to meet the news user’s requirements in terms of COMFORT and ENERGY SAVING needs. Consist of a stainless steel plate heat exchanger (1) where the heat exchange with primary circuit of the boiler and two accumulation storages, each of 21 liters of capacity, installed in series.

  • Page 26: Special Functions

    SPECIAL FUNCTIONS In order to improve ENERGY SAVING and COFORT are always active “Energy recovery” e “Small tapping” functions. 3.7.1 Small tapping Usually in standard boilers the ignition of the boiler is managed by a flow-meter that when the flow-rate reaches a certain value (minimum flow-rate), gives the signal to the boiler to start to deliver hot water to the user.

  • Page 27: Energy Recovery

    3.7.2 Energy recovery It a function to use all energy that otherwise will go lost ; in this way I get a saving and I can guarantee a better comfort. The function works optimizing the post circulation of the pump in the boiler. Usually post circulation starts at the end of an heating cycle (when the room temp has reached the set value by the user), the burner switches off, but the pump continue to run the water in the heating circuit avoiding overheating of the boiler and exploiting all energy inside the boiler that otherwise will get lost.

  • Page 28: Installer Faqs

    3.8 INSTALLER FAQS Is it possible to perform thermoregulation? Yes, the boiler is set up for use with a digital remote control (Clima Manager)l and an outdoor sensor which enables the heating system flow temperature can fluctuate according to the current atmospheric conditions. The CLAS B is also set up for climatic temperature control with the option of controlling two zones.

  • Page 29: Main Features For The Technical Assistance Service

    4 MAIN FEATURES FOR THE TECHNICAL ASSISTANCE SERVICE 4.1 SELF-DIAGNOSIS To make it easier for the technical assistance service to identify the problem, the boiler is fitted with a state- of-the-art self-diagnosis system, which shows the error code offering further information on the display. The new error codification was thereby introduced;...

  • Page 30: Multifunctional Interface

    MULTIFUNCTIONAL INTERFACE LEGENDA 1. Multifunctional LCD display “Esc” button 2. “Reset” button “+” button 3. Red “flame lockout” led Domestic hot water temperature control knob 4. Yellow “not recovered storage” led Timer (optional) 5. Pressure gouge Main switch 6. Heating temperature control knob Green “AUTO function ON”...

  • Page 31: Overall View

    OVERALL VIEW 4.5.1 Open chamber LEGEND Exhaust fume collar Electric connections box Fume thermostat Central Heating return filter Fume hood DHW flow meter Main heat exchanger CH pump Safety thermostat 105 °C DHW 7 bar security valve Central Heating delivery sensor 3 way valve Burner Spark generation electrodes...

  • Page 32: Camera Stagna

    4.5.2 Camera stagna LEGEND Coaxial exhaust collector Central Heating return filter Fume discharge pressure switch DHW flow meter Condensate tank CH pump Main heat exchanger DHW 7 bar security valve Safety thermostat 105 °C 3 way valve Central heating delivery sensor Detection electrode Burner Combustion chamber...

  • Page 33: Hydraulic Diagram

    HYDRAULIC DIAGRAM LEGENDA 1. Safety thermostat 105 °C DHW pump 2. Central Heating retuirn sensor No return valve 3. Central Heating delivery sensor DHW flow sensor 4. Auxiliary storage Idrometer 5. Main storage Minimum pressure switch 6. Storage sensor 3 way valve 7.

  • Page 34: Hydraulic Circuit

    HYDRAULIC CIRCUIT LEGEND CH return sensor DHW flow sensor CH flow sensor DHW flow meter Storages 10 DHW 7 bar security valve Plates exchanger with collector 12 CH pump CH 3 bar security valve 13 Minimum pressure switch Storage sensor 14 3 way valve DHW pump 15 DHW expansion vessel...
  • Page 35 LEGEND Main storage Auxiliary storage LEGEND Cool water inlet Link with “main storage” (to point 5) 16 plates exchanger DHW pump inlet Hot water inlet from plate exchanger DHW pump To the boiler Domestic Hot Water delivery DT Storage drainage valve Link with “auxiliary storage”...

  • Page 36: Combustion Group

    COMBUSTION GROUP LEGEND 1. Main exvhanger Gas valve 2. Gas nozzle collector Burner 3. Gas pipe Pag. 36 di 48...

  • Page 37: Open Chamber Collar

    4.8.1 Open chamber collar 4.8.2 Sealed chamber inlet-exhaust collar LEGEND 60/100 inlet-exhaust collar 4. Air inlet adaptation (supplied as standard) Fume analysis socket 5. Air pressure signal cover Plastic cover (standard) Pag. 37 di 48...

  • Page 38: Boiler Codes

    5 BOILER CODES 5.1 Open chamber NWE area COD. DESCR. BE FR 3665111 CLAS B 24 CF 3665113 CLAS B 24 VMC HMO_EE area COD. DESCR. 3665111 CLAS B 24 CF 5.2 Sealed chamber NWE area COD. DESCR. BE FR...

  • Page 39: Accessory Codes

    ACCESSORY CODES 6.1 ZONE MANAGEMENTS HEATING MODULES 6.1.1 Single-temperature zone management heating module DESCRIPTION MGz I Control module for one high- 3318286 temperature zone For a Central Heating application in which is request a water flow upper than boiler’s pump performance. Include ‘CLIP IN’...

  • Page 40: Multi-Temperature Zone Management Heating Module

    6.1.2 Multi-temperature zone management heating module DESCRIPTION MGm II Control module for two multi- temperature zones 3318288 For a Central Heating application composed by two different zones (1 high temperature – 1 low temperature) in which is request a water flow upper than boiler’s pump performance.

  • Page 41: Wired Thermoregolation Accessories

    6.2 WIRED THERMOREGOLATION ACCESSORIES DESCRIPTION 3318230 MARKETS: • CLIMA MANAGER IT.ES,UK,FR 3318318 modulating wired (RCw) MARKETS: Allows to manage all the boiler’s functions, shows the error codes and manage 2 Central Heating zones. 3318319 MARKETS: • ROOM SENSOR modulating wired (RSw) 3318331 Allows to select the Central Heating mode, set and shows the room temperature.

  • Page 42: Wireless Termoregolation Accessories

    6.3 WIRELESS TERMOREGOLATION ACCESSORIES DESCRIPTION 3318234 MARKETS: • CLIMA MANAGER (IT.ES,UK,FR) 3318320 modulating wireless (RCws) MARKETS: Allows to manage all the boiler’s functions, (EE1) shows the error codes and manage 2 Central Heating zones. 3318321 MARKETS: (EE2) • ROOM SENSOR modulating wireless (RSws) 3318235 Allows to select the Central Heating mode, set...

  • Page 43: Gas Accessories

    DESCRIPTION • SIGNAL RECIVER for modulating devices (RMws) 3318233 Allows to receive the signal sent from the modulating wireless devices. • SIGNAL RECIVER for on/off time thermostat (Rws) 3318240 Allows to receive the signal sent from the ON/OFF wireless devices. DENOMINAZIONE •...

  • Page 44: Hydraulic Accessories

    6.5 HYDRAULIC ACCESSORIES 6.5.1 First installation hydraulic kit DESCRIPTION Barrette KIT 3678470 First installation kit 3678471 Rear chassis kit 36784177 DHW recirculation kit 3678478 Pag. 44 di 48...

  • Page 45: Replacement Kits

    6.5.2 Replacement kits DESCRIZIONE • REPLACEMENT KIT 3678472 NIAGARA • REPLACEMENT KIT 3678474 CELTIC • REPLACEMENT KIT 3678475 TWIN&SILVA • REPLACEMENT KIT 3678476 FRISQUET HYDROCONFOR Pag. 45 di 48...

  • Page 46: Technical Data

    7 TECHNICAL DATA 7.1 CLAS B CF Model Name 24 CF General CE certification (pin) 1312BR4794 comments Boiler type Max./min. nominal heat output (60/80°C) (Hi) 25,8/11 Max./min. nominal heat output (60/80°C) (Hs) 28,7/12,2 Max./min. heat output in Domestic Hot Water mode (60/80°C) (Hi)

  • Page 47: Clas B Ff

    7.2 CLAS B FF Model Name 24 FF 30 FF General CE certification (pin) 1312BR4793 comments B22-B32-C12-C32-C42-C52-C82 Boiler type 25,8/11 30,0/13 Max./min. nominal heat output (60/80°C) (Hi) 28,7/12,2 33,3/14,4 Max./min. nominal heat output (60/80°C) (Hs) 27,0/11,0 31,3/13,0 Max./min. heat output in Domestic Hot Water mode (60/80°C) (Hi) 30,0/12,2 34,8/14,4...

  • Page 48: Certificati Di Omologa

    CERTIFICATI DI OMOLOGA Pag. 48 di 48...
