Bush CR-828P Instruction Manual

95mm
Instruction Manual
95mm
OPERATION OPERATION
Stop automatically in the desired station. In such
case, please use the Manual Tuning method to tune
to the desired station according to instruction
above. The may happen more probably when
tuning the radio in AM band.
4. Press ALARM 2/VOLUME+ button (7) or
ALARM1/VOLUME- button (6) to increase or
decrease the volume to the desired level. The
fig.4
volume level ranges from 0 to 16, and the LED will
show the volume level during volume adjustment.
(fig. 4)
5. Press and hold the ON/OFF/BAND button (1) to
turn off the radio. (fig. 5)
Note 1: The current station (either AW or FM) and
also the current volume level will be memorized at
the time when the radio is turned off. Once you turn
on the radio again, the memorized station will fig. 5
broadcast with the memorized volume level.
Note 2: For the best FM reception, extend the FM
antenna wire to its full length and vary the direction
to capture the strongest signal. Do not connect the
FM antenna wire to an outdoor antenna.
Note 3: For MW reception, a ferrite-bar antenna is
built-in. Since this antenna is direction oriented,
turn the unit to a direction at which the reception
becomes optimal.
PRESETTING YOUR FAVOURITE STATION
BIG LED ALARM CLOCK RADIO | Instruaction Manual 7 BIG LED ALARM CLOCK RADIO | Instruaction Manual
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
CR-828P
Read all instructions before use and keep for future reference.
Read all instructions before use and keep for future reference.
CHILDREN
Children do not always understand the dangers associated with operating electrical appliances. Never allow
WARNING
children to use this appliance.
Misuse or modification of this appliance may result in breakdown or injury.
To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
POWER SUPPLY
If the unit uses a mains supply, ensure that the plug is securely inserted into the mains socket, and it is easily
IMPORTANT INFORMATION
accessible.
The appliance is intended for household use only.
Protect the power lead from sharp objects, excessive heat and damp or wet locations. Check the power lead
The appliance should always be turned to OFF before plugging or unplugging from socket. Never yank cord
periodically, and replace if damaged.
to disconnect from socket; instead, grasp plug and pull to disconnect.
If the unit uses batteries, please ensure that they are inserted correctly - observing the polarity (+/-).
Check that the voltage on the rating plate of your product corresponds with your local electricity supply
Do not mix new and used batteries.
which must be A.C. (Alternating Current ).
Please make sure that used batteries are disposed of correctly. Do not burn or incinerate.
If the mains sockets in your home are not suitable for the plug supplied with this product, check with a
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
qualified electrician for replacement.
Check that the voltage on the rating plate of your product corresponds with your local electricity supply which
must be A.C. (Alternating Current).
Any repairs should only be carried out by a fully qualified electrician or an authorized service agent.
FOR OPTIMUM PERFORMANCE
The socket-outlet shall be installed near the equipment and shall be easily
Do not use in environments which are extremely hot, cold, dusty or humid.
accessible.
Keep the unit free from dust and clean with a dry cloth.
Do not use in areas exposed to direct sunlight or where it can become extremely hot.
Keep away from sources of strong magnetism - such as televisions or speakers.
Avoid placement where there is a lot of movement, vibration or on an unstable surface. LISTENING WITH SPEAKER
Listen at moderate volumes to avoid hearing damage.
If you hear no sound during playback, do not turn the volume up as the music may suddenly begin at a high
FOR SAFETY volume.
To avoid damaging your ears, adjust the volume to the lowest level before playback, and turn up to the desired
DO NOT :
level when playback has started.
Attempt to disassemble this unit or carry out repairs.
Attempt to modify the unit in any way.
Make sure that foreign objects do not get inside the unit.
Place naked flame sources - such as lit candles on or near the unit.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER
Place objects filled with liquids - such as vases, on or next to the unit.
(OR BACK), THERE ARE NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO
Cover the unit - allow the unit to be well ventilated.
QUALIFIED SERVICE PERSONNEL
Drop the unit or subject it to strong shocks
BIG LED ALARM CLOCK RADIO | Instruaction Manual 1 BIG LED ALARM CLOCK RADIO | Instruaction Manual
OPERATION OPERATION
108MHz for FM band, but all the 10 memories function. Each alarm function can be set
locations are not yet used up, then the scanning will independently, either wake to radio, or wake to
start again from the low end, i.e. 87.5 MHz until all buzzer. When any one of the set alarm is wake
the 10 memories location are filled up. to radio, please be reminded to select the
4. After the scanning is completed, the radio will be desired band, station and volume level before
Tuned to the station stored in the PRESET number turning off the radio.
P01.
ALARM SETTING
TUNING INTO A PRESET STATION
1. When the radio is on (either AM or FM), press
Preset-button (3) or Preset+ button(4) to choose
the PRESET number, in which your desired
station is stored. (fig. 11)
2. Radio is then tuned to the stored station. The
preset number will be shown for 3 seconds, then
change to show the radio frequency. After 5
seconds, the LED will switch to show the time
again.
TIME SETTING
1. When the unit is first plugged into the AC mains,
"0:00" will appear with the 1 st 0 digit flashing,
indicating that the TIME is ready to be set.
2. Press HOUR/TUNE- button (8) repeatedly to
choose the correct HOUR. (fig.12) In case if the
time is set to afternoon time, the PM indicator
( 13 ) will be turned on.
3. Press HOUR/TUNE+ button (9) repeatedly to
choose the correct MINUTE. (fig.12)
4. After setting to the correct time, either press
TIME/PRESET button (2) once, or just leave 5
seconds, then the display stop flashing, and the
clock will start run from the set time. (fig.13)
5. To change the current time, switch off the radio.
Press and hold TIME/PRESET button (2) for 2
seconds until the display flashes, then follow the
same steps as point 2, 3 & 4 above to set the new
time. (fig. 13)
DUAL ALARM FUNCTION
This product allows the user to set to dual alarm
8 BIG LED ALARM CLOCK RADIO | Instruaction Manual 9 BIG LED ALARM CLOCK RADIO | Instruaction Manual
CONTENT
Know Your Machine .......................................................................................................................................4
Getting Started ...............................................................................................................................................5
Operation ........................................................................................................................................................6
Radio Operation.......................................................................................................................................6
Presetting your favorite station ................................................................................................................7
Presetting by auto scanning......................................................................................................................8
Tuning into a preset station.......................................................................................................................9
Time setting ..............................................................................................................................................9
Dual alarm function....................................................................................................................................9
Alarm setting......................................................................................................................10
Snooze setting...................................................................................................................12
Setting the sleep timer.........................................................................................................12
High / Low dimmer for Led display.........................................................................................13
.
2 BIG LED ALARM CLOCK RADIO | Instruaction Manual
OPERATION
.20
fig. 19
10 BIG LED ALARM CLOCK RADIO | Instruaction Manual
KNOW YOUR MACHINE
GETTING STARTED
1. ON / OFF/ BAND 2. TIME / PRESET
3. PRESET - 4. PRESET +
5. SNOOZE / SLEEP / DIMMER 6. ALARM 1 / VOLUME –
7. ALARM 2 / VOLUME + 8. HOUR / TUNE –
9. MINUTE / TUNE + 10. FM Indicator
11. ALARM 2 BUZZER INDICATOR 12. ALARM 2 RADIO INDICATOR
13.: PM INDICATOR 14. ALARM 1 BUZZER INDICATOR
15. ALARM 1 RADIO INDICATOR
3 BIG LED ALARM CLOCK RADIO | Instruaction Manual 4 BIG LED ALARM CLOCK RADIO | Instruaction Manual
OPERATION OPERATION
5. Press the SLEEP/SNOOZE/DIMMER (5)
button again during SLEEP mode, the LED,
will show the remaining time of the SLEEP
period, and the SLEEP time can be set again
b pressing the SLEEP/SNOOZE/DIMMER (5)
button.(fig.24)
6. To turn off the radio during the SLEEP mode,
simply press and hold ON/OFF button (1)
once and the radio will be turned off
immediately. (fig. 25)
2.
activated, the alarm indicator will flash.
3. To switch off the SNOOZE function, simply press
ON/OFF/BAND button (1) once. You can then
see the alarm indicator stop flashing, and the
alarm will not sound again after the snooze
period elapse. (fig. 23)
SETTING THE SLEEP TIMER
The sleep function allows the radio to play in
Blocks of 10,20, 30, 40, 50, 60, 70, 80, or 90
minutes, and then being turned off automatically,
thus, you can enjoy falling asleep when listening the
radio.
1. Turn on the radio.
2. Press the SLEEP/SNOOZE/DIMMER (5)
button,, then the radio is turned on with the
display showing 90 (for 90 minutes) (fig.19)
3. Press the SLEEP/SNOOZE/DIMMER (5) button
repeatedly until the display shows the desired
SLEEP time period. The time period is shown on
the display in sequence as
90>80>70>60>50>40>30>20>10>0 (OFF).
(fig.24)
4. In 2 seconds after the desired SLEEP period is
chosen, the display will change to show the
radio frequency, and then the current time. The
radio will play for the SLEEP time duration you
have set and then be turned off automatically.
11 BIG LED ALARM CLOCK RADIO | Instruaction Manual 12 BIG LED ALARM CLOCK RADIO | Instruaction Manual
OPERATION
RADIO OPERATION
1. Press the ON/OFF/BAND button (1) once to turn on
the radio. The radio is receiving in FM band with the
FM indicator (10) turned on and the LED I s
showing the frequency. (fig. 1)
2. Press the ON/OFF/BAND button (1) once again to
alternate the radio band that the radio is receiving.
No indicator will be turned on in case AM band is
chosen. After 3 seconds, the LED will change
back to show the time. (fig. 2)
3. Press HOUR/TUNE+(9) or MINUTE/TUNE-(8) to
turn into the desire station by either of the following
methods: (fig. 3)
Manual Tuning: Press either of the 2 tuning button,
HOUR/TUNE+ (9) or MINUTE/TUNE-(8),
repeatedly until the desired station is reach.
For AM tuning, the radio can tune starting from 522
fig. 2
KHz to 1620 KHz, each pressing of HOUR/TUNE-
button (8) can tune down by 9 KHz and each
pressing MINUTE/TUNE+ button(9) can tune up by
9KHz.
For FM tuning, the radio can tune starting from 87.5
MHz to 108 MHz, each pressing of HOUR/TUNE-
button (8) can tune down by 0.1 MHz and each
pressing of MINUTE/TUNE+ button (9) can tune up
by 0.1 MHz.
Auto Tuning: Press and hold either of the 2 tuning
button, HOUR/TUNE- button (8) or
MINUTE/TUNE+(9) for more than 2 seconds and
auto tuning will be performed. Tuning will stop
fig. 3
automatically until a clear radio signal is found.
Repeat the same procedure by using the same
button until your desired station is found.
To stop auto tuning, press any button once.
Note: In some area where the radio signal is not strong
enough, the auto tuning process may not be able to
5 BIG LED ALARM CLOCK RADIO | Instruaction Manual 6
fig.24
fig. 26
13 BIG LED ALARM CLOCK RADIO | Instruaction Manual 14
