Figure 23: Com. Config - Comba Telecom RX-2620 User Manual

See the table below for configuration details of each parameter.
Item
Checking Control
OMC Server IP
Phone No.
Report Config
SMSC No.
ENU STATUS : 1-0-0
USER MANUAL FOR RX-2620

Figure 23: Com. Config.

Table 10: Com. Config.
Description
Select "Enable" or "Disable" from the drop down menu as shown to enable
or disable the Phone Number Authentication feature. Refer to [Phone No.] in
details.
Based on the current network conditions, users can enter the IP address
information of the equipment, which is connected to the OMT/OMC via
Ethernet. This connection via Ethernet is not available at this stage.
This is designed for authentication purpose when remote connection via
modem is required. It is the phone number to dial the equipment. Only the
phone number pre-defined in this field, will it be allowed to dial the
equipment. It is required to manually enter the phone number. Up to 5 phone
numbers are allowed. The use of phone number authentication can avoid
unauthorized use of the OMT. In addition, it can prevent the equipment
receiving piles of spam short messages, thus help the operator greatly
reduce the cost.
The Report No. is the SIM card number of the modem built into the OMC
Server computer. The equipment will send alarm SMS to this number.
If remote communication is needed via modem, users have to enable SMS
mode and set the report phone No. by entering the SIM card number of the
equipment built-in modem.
It specifies the SMS center. Users have to set the service No. of SMSC for
the first installation, so that the alarms can be sent to OMC.
End of Section
