Config:
Tick the check box of [Item select] and [Enable] of the desired parameters and click [config] button to
finish configuration operation.
Notice: [Enable] box
by ticking the [Enable] box, the alarms can be monitored by the OMT/OMC.
5.4

PROPERTIES INFO.

5.4.1 EQUIPMENT ID

Equipment ID is to be configured after local commission has been completed, which includes Site ID, and
Site Sub ID.
See the table below for configuration details of each parameter.
Item Description
Site ID Site ID is the unique equipment identification. It is a hexadecimal string of eight
characters in the range of [00000000~FFFFFFFF]. e.g. 00000000
Site Sub ID Site Sub ID is used for Master-Slave System. It is the unique identification of
each Master/ Slave Unit and is a hexadecimal string of two characters in the
range of [00~FF].
For the system located with single equipment, the Site Sub ID should be FF.
For Master-Slave system, the Site Sub ID for Master Unit is 00, and the Site Sub
ID for each Slave Unit is represented in the range of [01~FE] in ascending order.
e.g. Master Site ID: 00, Slave Site ID: 01

5.4.2 COMM. CONFIG

If the equipment is to be monitored by OMC software over
finish the [Comm. Config.] in the next step.
The Comm. Config information requires to be manually entered by users after successful connection to
the equipment.
ENU STATUS : 1-0-0
USER MANUAL FOR RX-2620
Figure 21: External Alarm
is to enable the alarm monitoring for system. Only if users enable the alarm
Figure 22: Equipment ID
Table 9: Equipment ID
Copyright - refer to title page
w
ireless GSM / CDMA network, users must
