  • Page 1 E Series Analog Speed Dome User Manual UD.6L0201D1665A01...
  • Page 2 User Manual of E Series Analog Speed Dome Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact the dealer. This manual is applicable to E Series Analog Speed Domes. This manual may contain several technically inaccurate points or printing errors, and the content is subject to change without notice.
  • Page 3 User Manual of E Series Analog Speed Dome Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 User Manual of E Series Analog Speed Dome Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected.
  • Page 5 User Manual of E Series Analog Speed Dome Cautions:  Make sure the power supply voltage is correct before using the product.  Do not drop the product or subject it to physical shock. Do not install the product on vibratory surface or places.

  • Page 6: Table Of Contents

    User Manual of E Series Analog Speed Dome Table of Contents Chapter 1 Overview .............................. 6 Description ................................6 Functions ................................6 Chapter 2 Getting Started ............................. 9 Power-up Action ..............................9 Basic Operations ..............................10 System-defined Presets ............................10 On-screen Displays .............................

  • Page 7: Chapter 1 Overview

    Chapter 1 Overview 1.1 Description Integrated with the built-in pan/tilt unit, the E series speed dome features highly sensitive response and reliable performance. The speed dome can be adopted in various surveillance fields with its full-integral functions and features, such as corridor, large venue, meeting room, station, neighborhoods, etc.
  • Page 8 User Manual of E Series Analog Speed Dome function can also be realized by auto mirror image depending on different camera models.  Privacy Mask This function allows you to block or mask certain area of a scene, for preventing the personal privacy from recording or live viewing.
  • Page 9 User Manual of E Series Analog Speed Dome The dome supports the power off memory capability with the predefined resume time. It allows the dome to resume its previous position after power is restored.  Time Task A time task is a preconfigured action that can be performed automatically at a specific date and time.

  • Page 10: Chapter 2 Getting Started

    User Manual of E Series Analog Speed Dome Chapter 2 Getting Started 2.1 Power-up Action After the speed dome is power-on, it will perform a series of self-test actions. It runs the pan checking firstly, then the tilt checking and the camera checking at last. After the power-up actions, the system information will be displayed for 2 minutes on the live view screen as shown below.

  • Page 11: Basic Operations

    User Manual of E Series Analog Speed Dome 2.2 Basic Operations You can operate the speed dome using a control device, including the control keyboard, DVR, DVS, etc. In this manual, accessing the speed dome via the web browser will be taken as an example.

  • Page 12: On-Screen Displays

    User Manual of E Series Analog Speed Dome 2.4 On-screen Displays The speed dome supports following on-screen displays: Zoom Show: Identifies the amount of magnification. The format is ZXXX. XXX is the zoom amount. PT Show: Displays panning and tilting direction, with the format of NEXXX/TXXX. The NE followed with XXX indicates the degrees in north east direction, while the T followed with XXX indicates the degrees in tilt position.

  • Page 13: Chapter 3 Menu Operation

    User Manual of E Series Analog Speed Dome Chapter 3 Menu Operation  The operation interface of the different speed domes may differ. Please refer to the actual operation interface.  You can click the left and right direction buttons in the PTZ control panel via the web browser of the DVR to enter the next page or return to the previous page of the submenu if more than one page is available.

  • Page 14: Configuring System Information

    User Manual of E Series Analog Speed Dome Steps: 1. Connect the video and RS-485 cables of speed dome to a DVR. 2. Visit the DVR via the web browser. 3. View the live video of the speed dome. 4. For PELCO-P/D and other private PTZ protocols, call preset 95 from the preset list in the PTZ control panel of the DVR.

  • Page 15: Configuring System Parameters

    User Manual of E Series Analog Speed Dome information shown after the power-up action. Please refer to Section 2.1 for more details. Enter the system information display menu: MAIN MENUS > SYSTEM INFO SYS INFO SYS INFO CAM VERSION X.XX...
  • Page 16 User Manual of E Series Analog Speed Dome To Set the Soft Address of the Speed Dome If the SET SOFT ADDR is set as ON, the soft address is the valid address for connecting the speed dome. The selectable soft address range is from 1 to 255;...
  • Page 17 User Manual of E Series Analog Speed Dome Y - M - D 12 12 12 H - M - S 15 33 25 IRIS + OK IRIS - CANCEL Figure 3-5 Set the System Time  Angle Zero Configuration Purpose: You can define the angle zero of the speed dome on the ANGLE ZERO submenu.
  • Page 18  Select the protocol. Choose the protocol on PROTOCAL submenu. You can configure it as AUTO MATCH, PELCO-P, PELCO-D, or HIKVISION. When you choose AUTO MATCH, it is protocol self-adaptive.  Set the protocol status. Set the PROTOCOL STATUS as ON to enable the user-defined protocol.

  • Page 19: Configuring Image Parameters

    User Manual of E Series Analog Speed Dome You can set 485 CHECK as ON or AUTO for automatic RS-485 configuration diagnosis. If the configuration is incorrect, an alert will be received; if you set the value as AUTO, it will automatically stop the diagnosis when no errors exist.
  • Page 20 User Manual of E Series Analog Speed Dome CAMERA SETTINGS CAMERA SETTINGS WB MODE AUTO MIN. ZOOM LIMIT CHROMA SUPPRESS BLUE SATURATION IMAGE FLIP CONTRAST FOCUS LIMIT INIT LENS OF F HR MODE NOISE REDUCE GAIN LIMIT BACK EXIT BACK...
  • Page 21 User Manual of E Series Analog Speed Dome (3) Click IRIS+ button to confirm. If you set the ZOOM LIMIT as the minimum value 22, the digital zoom function will be disabled, and the optical zoom function is at its maximum value.
  • Page 22 User Manual of E Series Analog Speed Dome BLC level configuration varies according to the different camera models. Some models don’t support user-defined BLC level. Task 6: Configuring the iris, gain and shutter speed  Set the Exposure Mode Purpose: AE mode defines the priority of iris, shutter and gain while the speed dome adjusting the brightness of the live view.
  • Page 23 User Manual of E Series Analog Speed Dome fewer the amount of entering light per second is, and the darker the image is. You can set the value as 1, 2, 4, 8, 15, 30, 50, 125, 180, 250, 500, 1000, 2000, 4000 or 10000.

  • Page 24: Configuring Privacy Mask

    User Manual of E Series Analog Speed Dome less the noise will be in the low illumination environment. You can also disable the function by turning the value as OFF. Task 12: Configure the image quality.  Min. Zoom Limit Set the value of MIN.
  • Page 25 User Manual of E Series Analog Speed Dome PRIVACY MASK MASK NO. MASK STATUS SET MASK DELETE MASK BACK EXIT Figure 3-8 Privacy Mask Configuration Menu 2. Choose the privacy mask number: Steps: (1) Move the cursor to MASK NO. and click IRIS+ to enter the editing mode.

  • Page 26: Configuring Output Standard

    User Manual of E Series Analog Speed Dome IRIS+ button again to edit. The tilt range for configuring the privacy masks is from 0° to 70°. 4. Enable or disable the privacy mask function. Move the cursor to BLANK STATUS. Click IRIS+ button to enter the editing mode and click the up and down direction buttons to set it ON or OFF.

  • Page 27: Configuring Ptz Control Parameters

    User Manual of E Series Analog Speed Dome IR SETTINGS SENSITIVITY MEDIUM N/M LED CURRENT FAR LED CURRENT ZOOM LIMIT IR CONTROL AUTO SWITCH DELAY(S) BACK EXIT Figure 3-10 IR Settings  Set the sensitivity of the IR LED. You can set the SENSITIVITY to HIGH, MEDIUM, or LOW.

  • Page 28: Configuring Ptz Parameters

    User Manual of E Series Analog Speed Dome 3.4.1 Configuring PTZ Parameters Enter PTZ configuration menu: MAIN MENU > DOME SETTINGS > MOTION SETTINGS MOTION SETTINGS MOTION SETTINGS AUTO FLIP PRESET SPEED PROPORTIONAL PAN ENABLE LIMIT PARK TIME LIMITS SETTING...
  • Page 29 User Manual of E Series Analog Speed Dome received after the park time: in the process of performing dome actions by calling special presets; or in the process of performing external alarm linkage actions.  Preset freezing This feature enables the live view to switch directly from the current scene to another scene that is defined by a preset, without showing the middle areas between these two scenes.

  • Page 30: Configuring Presets

    User Manual of E Series Analog Speed Dome The range of the elevation angle is 0~90° by default and it changes to -15°~90° after the ELEVATION SET is set as ON. 3.4.2 Configuring Presets Purpose: A preset is a user-defined monitoring position/point. You can simply call the preset number to change the monitor scene to the defined position.

  • Page 31: Configuring Patrols

    User Manual of E Series Analog Speed Dome preset. 5. Clear the preset settings. Move the cursor to CLEAR and click IRIS+ to clear the settings of the current preset. 3.4.3 Configuring Patrols Purpose: A patrol is a scanning track specified by a group of user-defined presets. You can call a patrol to scan the scenes automatically among the user-defined presets in sequence.

  • Page 32: Configuring Patterns

    User Manual of E Series Analog Speed Dome DW ELL SPEED IRIS+ OK IRIS- CANCEL Figure 3-14 Edit the Patrol (2) Click up/down direction buttons to choose the number and locate the preset to be edited. (3) Click left/right direction buttons to position the cursor to the column of PRESET, DWELL and SPEED.
  • Page 33 User Manual of E Series Analog Speed Dome and power-up). Steps: 1. Move the cursor to enter the PATTERNS submenu: MAIN MENU > DOME SETTINGS > PATTERNS PATTERNS PATTERN NO. RECORD PATTERN PREVIEW CLEAR REMAINING BACK EXIT Figure 3-15 Pattern Configuration Menu 2.

  • Page 34: Configuring Timing Tasks

    User Manual of E Series Analog Speed Dome automatically memorize the path you operated as a pattern. (3) Click IRIS+ again to save the pattern and exit edit mode.  REMAIN MEMORY indicates the remaining memory of the speed dome for configuring the patterns.
  • Page 35 User Manual of E Series Analog Speed Dome 2. Choose the task number. Steps: (1) Move the cursor to TASK NO. and click IRIS+ to enter edit mode. (2) Click the up/down direction buttons to select the number of the task which is to be configured.

  • Page 36: Configuring Zone

    User Manual of E Series Analog Speed Dome WEEK WHOLE W EEK START (H-M) 00 : 00 END (H-M) 00 : 00 IRIS+ OK IRIS- CANCEL Figure 3-18 Set the Task Time 6. Delete the task. Move the cursor to TASK CLEAR, click IRIS+ to delete the time and action of the current task, and click IRIS+ again to confirm the settings and exit.

  • Page 37: Others

    User Manual of E Series Analog Speed Dome Steps: (1) Move the cursor to EDIT ZONE and click IRIS+ button to enter the edit mode. (2) You can see SET LEFT LIMIT on the screen. Click the direction buttons to set the left limit.

  • Page 38: Rebooting The Dome

    User Manual of E Series Analog Speed Dome 3.5.3 Rebooting the Dome Enter MAIN MENU > REBOOT DOME and click IRIS+ to reboot the speed dome remotely. © Hikvision...

  • Page 39: Appendix

    User Manual of E Series Analog Speed Dome Appendix Appendix 1 Lightning & Surge Protection This product adopts TVS plate lightning protection technology to avoid damage caused by pulse signal that is below 3000W, like instantaneous lighting stroke, surging, etc. According to the actual outdoor situation, necessary protection measures must be taken, besides ensuring the electrical safety.

  • Page 40: Appendix 2 Rs485 Bus Connection

    User Manual of E Series Analog Speed Dome Appendix 2 RS485 Bus Connection  General Property of RS485 Bus According to RS485 industry bus standard, RS485 is a half-duplex communication bus which has 120Ω characteristic impendence, the maximum load ability is 32 payloads (including controller device and controlled device).
  • Page 41 User Manual of E Series Analog Speed Dome Controller Figure A-4 Star Shape Connection For such case, the best way is adding a RS485 distributor. This product can effectively change the star-shape connection to which satisfies the requirement of RS485 industry standard, in order to avoid those problems and improve the communication reliability.
  • Page 42 User Manual of E Series Analog Speed Dome Problem Possible Reasons To Solve the Problem 2. RS485+ or RS485-wire is 2. Change a RS485 wire. controlled broken. but not 3. The speed dome is too far away 3. Add a terminal resistor.

  • Page 43: Appendix 3 24Vac Wire Gauge & Transmission Distance

    User Manual of E Series Analog Speed Dome Appendix 3 24VAC Wire Gauge & Transmission Distance The following table describes the recommended Max. distance adopted for the certain wire gauge when the loss rate of 24VAC voltage is less than 10%. For the AC driven device, the maximum voltage loss rate is 10% allowable.

  • Page 44: Appendix 4 Wire Gauge Standards

    User Manual of E Series Analog Speed Dome Appendix 4 Wire Gauge Standards American Cross-sectional Bare Wire British Wire Wire Gauge Area of Bare Gauge(mm) Gauge SWG Wire(mm 0.750 0.4417 0.800 0.5027 0.900 0.6362 1.000 0.7854 1.250 1.2266 1.500 1.7663 2.000...
  • Page 45 User Manual of E Series Analog Speed Dome...
