HIKVISION E Series User Manual

HIKVISION E Series User Manual

5-inch speed dome
Hide thumbs Also See for E Series:
Table of Contents

Advertisement

Quick Links

See also: User Manual , Installation Manual
E Series 5-inch Speed Dome

User Manual

UD.6L0201D1139A01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIKVISION E Series

Summary of Contents for HIKVISION E Series

  • Page 1: User Manual

    E Series 5-inch Speed Dome User Manual UD.6L0201D1139A01...
  • Page 2 User Manual of E Series 5-inch Speed Dome Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact the dealer. This manual is applicable to E Series 5-inch Speed Dome. This manual may contain several technically inaccurate points or printing errors, and the content is subject to change without notice.

  • Page 3: Regulatory Information

    User Manual of E Series 5-inch Speed Dome Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Safety Instruction

    User Manual of E Series 5-inch Speed Dome Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected.
  • Page 5 User Manual of E Series 5-inch Speed Dome Cautions:  Make sure the power supply voltage is correct before using the product.  Do not drop the product or subject it to physical shock. Do not install the product on vibratory surface or places.

  • Page 6: Table Of Contents

    User Manual of E Series 5-inch Speed Dome Table of Contents Chapter 1 Overview .............................. 6 Description ..............................6 Functions ..............................6 Chapter 2 Getting Started ............................. 9 Power-up Action ............................9 Basic Operations............................10 System-defined Presets ..........................10 On-screen Displays ............................11 Chapter 3 Menu Operation ..........................12...

  • Page 7: Chapter 1 Overview

    User Manual of E Series 5-inch Speed Dome Chapter 1 Overview 1.1 Description Integrated with the built-in pan/tilt unit, the high speed dome features highly sensitive response and reliable performance. The speed dome can be adopted in various surveillance fields with its full-integral functions and features, such as corridor, large venue, meeting room, station, community, etc.
  • Page 8 User Manual of E Series 5-inch Speed Dome and panorama scanning. The scanning speed can be set by OSD menu from level 1 to 40, with the corresponding speed ranging from 1° /second to 40° /second. Preset Freeze Frame This feature freezes the scene on the monitor when going to a preset. This allows for smooth transition from one preset scene to another and also guarantees that masked area will not be revealed when going to a preset.
  • Page 9 User Manual of E Series 5-inch Speed Dome recalled with a command from a controller or automatically by a configured function (park, time task, or power-up). By default the focus and iris are in auto status during the preset is being memorized.

  • Page 10: Chapter 2 Getting Started

    User Manual of E Series 5-inch Speed Dome Chapter 2 Getting Started 2.1 Power-up Action After the power is connected, the speed dome will perform a series of self-test actions. It performs lens actions firstly, then the panning movement and the tilting movement at last. After the power-up self-test actions, the system information will be displayed for 2 minutes on the live view screen as shown below.

  • Page 11: Basic Operations

    User Manual of E Series 5-inch Speed Dome 2.2 Basic Operations You can operate the speed dome using a control device. The control devices include the control keyboards, DVRs, DVSs, etc. In this and the following chapters, operation of the speed dome by the IE browser of a DVR will be taken as an example.

  • Page 12: On-Screen Displays

    User Manual of E Series 5-inch Speed Dome Note: For Manchester code control protocol, the system-defined presets with special functions are shown as below: Table 1-1 System-defined Presets of Manchester Code Control Protocol Set Preset Function Call Preset Function Remote reboot...

  • Page 13: Chapter 3 Menu Operation

    User Manual of E Series 5-inch Speed Dome Chapter 3 Menu Operation The OSD menu tree is shown in the following figure. Note: The menu varies depending on the model of speed dome. Figure 3-1 Main Menu Before you start: You can operate the speed dome using the on-screen display menu remotely by connecting to a DVR or a DVS (encoder).

  • Page 14: Configuring System Information

    User Manual of E Series 5-inch Speed Dome MAIN MENUS <SYS INFO> <DOME SETTINGS> <RESTORE DEFAULTS> <RESTORE CAMERA> <RESBOOT DOME> <LANGUAGE> ENGLISH <SET TITLE> EXIT Figure 3-2 Main Menu To move the cursor and operate the menu:  Move the cursor up/down: On control panel of the live view interface of the DVR, click up and down direction buttons or FOCUS+ and FOCUS- buttons to move the cursor in the menu up and down.

  • Page 15: Configuring System Parameters

    User Manual of E Series 5-inch Speed Dome Enter the system information display menu: MAIN MENUS > SYS INFO SYS INFO TYPE DS- 0XXXXX-X ADDRESS COM FORMAT 0000,0,0 PROTOCOL XXXXX VERSION 0. 00 HARDVERSION 0. 00 BUILD DATE 13 08 05...
  • Page 16 User Manual of E Series 5-inch Speed Dome Task 2: Set the broadcast address of the speed dome. When the BROADCAST ADDRESS is set to ON, the control devices with address 0 can control the speed dome remotely regardless of the address of the speed dome.

  • Page 17: Configuring Image Parameters

    User Manual of E Series 5-inch Speed Dome  Fan parameter configuration You can set the FAN CONTROL as ON or OFF.  EIS (Electronic Image Stabilization) configuration You can set the EIS FUNCTION as ON or OFF; and set the EIS LEVEL as 0-3.
  • Page 18 User Manual of E Series 5-inch Speed Dome CAMERA CAMERA WHITE BALANCE AUTO WIDE LIMIT CHROMA SUPPRESS BLUE SATURATION IMAGE FLIP CONTRAST FOCUS LIMIT INIT LENS HR MODE NOISE REDUCE GAIN LIMIT BACK EXIT BACK EXIT Figure 3-6 Camera Settings Task 1: Configure the focus settings.
  • Page 19 User Manual of E Series 5-inch Speed Dome  Configure the zoom speed. Purpose: You can define the speed at which the lens changes from full wide zoom to the optical zoom. Steps: (1) Move the cursor to ZOOM SPEED using the direction buttons and click IRIS+ to enter.
  • Page 20 User Manual of E Series 5-inch Speed Dome define the iris value according to related content in this section if you choose IRIS mode. SHUTTER: User-defined shutter speed, auto iris and auto gain. It is the shutter-priority mode. Please define the shutter speed according to related content in this section if you choose SHUTTER mode.
  • Page 21 User Manual of E Series 5-inch Speed Dome AUTO: In Auto mode, the dome retains color balance automatically according to the current color temperature. INDOOR, OUTDOOR: These two modes are for indoor use and outdoor use respectively. SELFDEF: In this mode, you can adjust the color temperature manually to meet your own demand.

  • Page 22: Configuring Privacy Mask

    User Manual of E Series 5-inch Speed Dome Set the HR MODE as ON to adjust the resolution higher. Switch it OFF to disable the function, which can avoid cross color of the image. 3.3.2 Configuring Privacy Mask Purpose: Privacy mask enables you to cover certain areas on the live video from being live viewed and recorded.

  • Page 23: Configuring Osd Settings

    User Manual of E Series 5-inch Speed Dome ADJUST BLANK POS FOCUS SHIFT STATUS SAVE: OPEN QUIT: CLOSE Figure 3-8 Set the Privacy Mask (2) You can see ADJUST BLANK POS message on the screen. Click the direction buttons to adjust the position of the privacy mask to the designed scene.
  • Page 24 User Manual of E Series 5-inch Speed Dome TITLE CODE TITLE Figure 3-9 Set Dome Title 7. Click the left/right direction buttons to position the cursor to the characters of the title. 8. Get the codes for a specific character and enter each code (number) by calling the preset number, i.e.

  • Page 25: Configuring Ptz Control Parameters

    User Manual of E Series 5-inch Speed Dome  Display the PTZ movements, alarm, system time, etc. Purpose: You can enable or disable the on-screen display of PTZ movements, presets, etc., and configure the display time. Steps: 1. Enter the display settings menu: MAIN MENUS >...

  • Page 26: Configuring Ptz Parameters

    User Manual of E Series 5-inch Speed Dome 3.4.1 Configuring PTZ Parameters Enter PTZ configuration menu: MAIN MENU > DOME SETTINGS > MOTION PARAMETER MOTION MOTION PRESET SPEED AUTO FLIP LIMIT STOP PROPORTIONAL PAN <SETTING STOPS> PARK TIME CLEAR STOPS...

  • Page 27: Configuring Presets

    User Manual of E Series 5-inch Speed Dome You can set IMAGE FREEZE as ON or OFF to enable or disable this function. Note: The function varies according to the different camera models.  PTZ speed Purpose: You can define the speed of the dome movements.

  • Page 28: Configuring Patrols

    User Manual of E Series 5-inch Speed Dome PRESETS PRESET NUM [UNDEFINED] PRESET PTZ CLEAR PRESET BACK EXIT Figure 3-13 Preset Configuration Menu 2. Choose the preset number: Move the cursor to PRESET NUM and click IRIS+ to enter. Click the up and down buttons to choose the preset number which needs to be edited.
  • Page 29 User Manual of E Series 5-inch Speed Dome PATROLS PATROL NUM EDIT PATROL PREVIEW CLEAR PATH PATROL_D BACK EXIT Figure 3-14 Patrol Configuration Menu  Choose the patrol number. Steps: (1) Move the cursor to PATROLS NUM and click IRIS+ to enter edit mode.

  • Page 30: Configuring Patterns

    User Manual of E Series 5-inch Speed Dome to cancel and return to the previous menu.  Preview the patrol. Move the cursor to PREVIEW and click IRIS+ to preview the current patrol. You can click IRS+ again to stop the preview.

  • Page 31: Configuring Time Tasks

    User Manual of E Series 5-inch Speed Dome 3. Edit the pattern. Steps: (1) Move the cursor to EDIT PATTERN and click IRIS+ to enter edit mode. REMAIN MEMORY DONE: OPEN QUIT: CLOSE Figure 3-17 Edit the Pattern (2) Click the PTZ control buttons and direction buttons to operate the speed dome to draw a movement path, including pan scan, tilt scan, zoom in, zoom out, etc.
  • Page 32 User Manual of E Series 5-inch Speed Dome 1. Move the cursor to enter the TIME TASK submenu: MAIN MENU > DOME SETTINGS > TIME TASK TIME TASK TASK NUM TASK STATE TASK ACTION NONE TASK TIME TASK PREVIEW TASK CLEAR...

  • Page 33: Configuring Zone

    User Manual of E Series 5-inch Speed Dome Note: The weekday can be set to be from Monday to Sunday or Whole Week; the H refers to Hour and the M refers to Minute. WEEK WHOLE WEEK START(H-M) END(H-M) DONE: OPEN...

  • Page 34: Clearing Ptz Control Settings

    User Manual of E Series 5-inch Speed Dome 3. Configure the zone area. Steps: (1) Move the cursor to EDIT ZONE and click IRIS+ button to enter the edit mode. (2) You can see SET LEFT LIMIT on the screen. Click the direction buttons to set the left limit stop.

  • Page 35: Others

    User Manual of E Series 5-inch Speed Dome DIAGNOSTICS DIAGNOSTICS HIGH TEMP PAN LOST HIGHEST TEMP 47° C TILT LOST LOW TEMP CAMERA LOST LOWEST TEMP 23° C VIDEO LOSS LOW VOLTAGE POWER UP BACK EXIT BACK EXIT Figure 3-22 Self-diagnostics...

  • Page 36: Restoring Default Dome Settings

    User Manual of E Series 5-inch Speed Dome You can modify the password and enable/disable the password protection to prevent unauthorized settings of the speed dome. After you set and enable the password, you need to input the password every time you call preset 95 to enter the menu.

  • Page 37: Restoring Default Camera Settings

    User Manual of E Series 5-inch Speed Dome Zoom limit Max Optical Zoom Zoom speed High Slow shutter IR cut filter D/N level AE mode Auto Exposure compensation White balance Auto Auto-flip Proportional pan Park time 5 seconds Park act...

  • Page 38: Appendix

    User Manual of E Series 5-inch Speed Dome Appendix Appendix 1 Lightning & Surge Protection This product adopts TVS plate lightning protection technology to avoid damage caused by pulse signal that is below 3000W, like instantaneous lighting stroke, surging, etc. According to the actual outdoor situation, necessary protection measures must be taken, besides ensuring the electrical safety.

  • Page 39: Appendix 2 Rs485 Bus Connection

    User Manual of E Series 5-inch Speed Dome Appendix 2 RS485 Bus Connection  General Property of RS485 Bus According to RS485 industry bus standard, RS485 is a half-duplex communication bus which has 120Ω characteristic impendence, the maximum load ability is 32 payloads (including controller device and controlled device).
  • Page 40 User Manual of E Series 5-inch Speed Dome faraway. At this time, the dome will be uncontrollable, or self-running, etc. Star Shape Connection Figure A-4 For such case, the best way is adding a RS485 distributor. This product can effectively change the star-shape connection to which satisfies the requirement of RS485 industry standard, in order to avoid those problems and improve the communication reliability.
  • Page 41 User Manual of E Series 5-inch Speed Dome Problem Possible Reasons To Solve the Problem dome can tightly. 2. RS485+ or RS485-wire is 2. Change a RS485 wire. controlled broken. but not 3. The speed dome is too far away 3.

  • Page 42: Appendix 3 24Vac Wire Gauge & Transmission Distance

    User Manual of E Series 5-inch Speed Dome Appendix 3 24VAC Wire Gauge & Transmission Distance The following table describes the recommended max. distance adopted for the certain wire gauge when the loss rate of 24VAC voltage is less than 10%. For the AC driven device, the maximum voltage loss rate is 10% allowable.

  • Page 43: Appendix 4 Table Of Wire Gauge Standards

    User Manual of E Series 5-inch Speed Dome Appendix 4 Table of Wire Gauge Standards American Cross-sectional Bare Wire British Wire Wire Gauge Area of Bare Gauge(mm) Gauge SWG Wire(mm2) 0.750 0.4417 0.800 0.5027 0.900 0.6362 1.000 0.7854 1.250 1.2266 1.500...
