  • Page 1 FC-29W 9” UN-UNIVERSAL Dome Housing Installation Instructions...
  • Page 3 Safe Use of Equipment WARNING WARNING To reduce the risks of an electric shock, do not expose inside of this unit to rain or moisture. Installation on a rainy day may also cause fog around the capsule. Installation Installation shall be done by qualified installer only and should conform to all local codes.
  • Page 4: Table Of Contents

    2. AXIS 215 PTZ network camera housing installation……………………..…P.6 3. AXIS 233D PTZ network dome camera Housing installation……………...P.8 4. AXIS P55XX series PTZ network dome camera Housing installation…..P.10 5. AXIS Q6034 PTZ network dome camera Housing installation………...….P.12 6. Installation of FC-9002 Pole Mount Bracket and Dome housing………….P.14 7.
  • Page 5: Axis 214 Ptz Network Camera Housing Installation

    AXIS 214 PTZ network camera Housing installation The unit must be properly and securely mounted to a supporting WARNING structure capable of sustaining the weight of unit. Recommend use stainless screws. Cables 9” dome housing L603 Power cable to PC board and external power supply...
  • Page 6 Assembly Steps of the Camera and the Dome Housing 1-1-1 1-1-2 1-1-3 Fix No. 2 side board (Hole 2) to the Use 4x8 double washer screws to Fix screws on back of round-shaped bottom board (Hole 5) Fix Fan/Heater side board on square-shaped upper board which with 3x8 Double Washer screws.
  • Page 7: Axis 215 Ptz Network Camera Housing Installation

    AXIS 215 PTZ network camera Housing installation The unit must be properly and securely mounted to a supporting WARNING structure capable of sustaining the weight of unit. Recommend use stainless screws. Cables 9” dome housing L603 Power cable to PC board and external power supply...
  • Page 8 Assembly Steps of the Camera and the Dome Housing 2-1-1 2-1-2 2-1-3 Fix No. 3 side board (Hole 1) to the Use 4x8 double washer screws to Fix screws on front of square-shaped round-shaped bottom board (Hole 6) Fix Fan/Heater side board on upper board to fix the camera on with 3x8 Double Washer screws.
  • Page 9: Axis 233D Ptz Network Dome Camera Housing Installation

    AXIS 233D PTZ network dome camera Housing installation The unit must be properly and securely mounted to a supporting WARNING structure capable of sustaining the weight of unit. Recommend use stainless screws. Cables 9” dome housing L605P-2 Power cable to PC board and external power supply L704P-2.0...
  • Page 10 Assembly Steps of the Camera and the Dome Housing 3-1-1 3-1-2 3-1-3 Fix No. 1 side board (Hole 1) to the Fix screws on front of square-shaped Fix the camera to the L board with round-shaped bottom board (Hole 5) upper board to fix the L board on 4x10 double washer screws.
  • Page 11: Axis P55Xx Series Ptz Network Dome Camera Housing Installation

    AXIS P55XX series PTZ network dome camera Housing installation The unit must be properly and securely mounted to a supporting WARNING structure capable of sustaining the weight of unit. Recommend use stainless screws. Cables 9” dome housing L605P-2 Power cable to PC board and external power supply L704P-2.0...
  • Page 12 Assembly Steps of the Camera and the Dome Housing 4-1-1 4-1-2 Fix No. 2 side board (Hole 2) to the Fix screws on front of square-shaped upper board to fix the camera base round-shaped bottom board (Hole 5) on square-shaped upper board (Hole J) with 4x10 double washer screws. with 3x8 Double Washer screws.
  • Page 13: Axis Q6034 Ptz Network Dome Camera Housing Installation

    AXIS Q6034 PTZ network dome camera Housing installation The unit must be properly and securely mounted to a supporting WARNING structure capable of sustaining the weight of unit. Recommend use stainless screws. Cables 9” dome housing L605P-2 Power cable to PC board and external power supply L704P-2.0...
  • Page 14 Assembly Steps of the Camera and the Dome Housing 5-1-1 5-1-2 Use 4x8 double washer screws to Fix screws on front of square-shaped upper board to fix the camera base Fix Heater side board on on square-shaped upper board (Hole J) with 4x10 double washer screws. Round-shaped bottom board, Then tighten camera on camera base.
  • Page 15: Installation Of Fc-9002 Pole Mount Bracket And Dome Housing

    Installation of FC-9002 Pole Mount Bracket and Dome housing 6-2-1 6-2-2 FC-9002 Pole Mount Bracket For installation with FC-9009 + For installation with FC-9009N wall FC-9010 (wall mount bracket and mount bracket, screw FC-9009N on power box), screw FC-9010 power FC-9002 Pole Mount Bracket box on FC-9002 Pole Mount Bracket Thread the hoop through FC-9002...
  • Page 16: Installation Of Fc-9005 Ceil Mount Bracket And Dome Housing

    Installation of FC-9005 Ceil Mount Bracket and Dome housing Fix FC-9010 power box on ceil Twist and Tighten the Pole to the Insert cables through power box Top of FC-9005 and FC-9005, buckle up the safety rope, and then tighten up screws Fix dome housing with FC-9005 Fix camera to dome housing and Use Hex Head Cap nut to fix cover...
  • Page 17: Installation Of Fc-9006 Ceil Mount Bracket And Dome Housing

    Installation of FC-9006 Ceil Mount Bracket and Dome housing Top of FC-9006 Pendant Mount Twist and Tighten the Pole Insert cables through FC-9006 Bracket clockwise to the Top of FC-9006 (Two HEX HEAD CAP SCREWS are already installed on Pole), use Allen Key to tighten the screws.
  • Page 18: Installation Of Fc-9007 Corner Adapter With Wall Mount Bracket And Dome Housing

    Installation of FC-9007 Corner Adapter with Wall Mount Bracket and Dome housing FC-9007 Exterior Angle 90° FC-9007 Exterior Angle 90° Corner Join FC-9007 Part1 and Part2 Corner Adapter Part1 Adapter Part2 together Tighten Hex Head Cap screws Then fix whole FC-9007 Exterior Angle Fix Wall Mount Bracket on FC-9007 clockwise 90°...
  • Page 19: Installation Of Fc-9008 Corner Adapter With Wall Mount Bracket And Dome Housing

    Installation of FC-9008 Corner Adapter with Wall Mount Bracket and Dome housing 10-1 10-2 10-3 FC-9008 Interior Angle 90° Corner FC-9008 Interior Angle 90° Corner Join FC-9008 Part1 and Part2 Adapter Part1 Adapter Part2 together 10-4 10-5 10-6 Tighten Hex Head Cap screws Then fix whole FC-9008 Interior Fix Wall Mount Bracket on FC-9008 clockwise...
  • Page 20: Installation Of Fc-9009N Wall Mount Bracket And Dome Housing

    Installation of FC-9009N Wall Mount Bracket and Dome housing 11-1 11-2 11-3 FC-9009N Wall Mount Bracket Put cables through bracket Fix bracket on wall 11-4 11-5 11-6 Assemble the dome housing and the Fix camera to dome housing and Use Hex Head Cap nut to fix cover bracket, and use Allen Key to fix connect the cables and dome housing...
  • Page 21: Installation Of Fc-9009 Wall Mount Bracket And Dome Housing

    Installation of FC-9009 Wall Mount Bracket and Dome housing 12-1 12-2 12-3 Fix mounting holder to the Dome Put cables through the bracket. Assemble the Dome housing and the housing. bracket. 12-4 12-5 12-6 Fix camera to dome housing and Use Hex Head Cap nut to fix cover Fix the power box to the wall or to the connect the cables...
  • Page 22: Installation Of Fc-9011 Ceil Mount Bracket And Dome Housing

    Installation of FC-9011 Ceil Mount Bracket and Dome housing 13-1 13-2 13-3 Twist and Tighten the Pole to the Fix FC-9011 on Ceil Insert cables through FC-9011 Top of FC-9011 13-4 13-5 13-6 Fix dome housing with FC-9011 Fix camera to dome housing and Use Hex Head Cap nut to fix cover bracket connect the cables...
  • Page 23: Dimensions

    Dimensions 14-1 14-2 14-3 FC-29W 9” housing Internal FC-9005 Pendant Mount Bracket FC-9002 Pole Mount Bracket dimensions 14-4 14-5 14-6 FC-9006-30 30cm Pendant Mount FC-9007 Exterior Angle 90° Corner FC-9009N or FC-9009 Wall Mount Bracket dimensions Adapter dimensions Bracket dimensions...
  • Page 24: Important Safeguards

    IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS Read Instructions – All the safety and operating instructions CAUTION should be read before operating the unit. RISK OF Retain Instructions – The safety and operating instructions ELECTRIC SHOCK! should be retained for future reference. CAUTION: TO REDUCE THE RISK OF Heed Warnings –...
