Lifetime 90160 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL N° 90160
OWNER'S MANUAL
Keep this Product ID Number and use when contacting Customer Service:
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 90160 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lifetime 90160

Summary of Contents for Lifetime 90160

  • Page 1 MODEL N° 90160 OWNER’S MANUAL Keep this Product ID Number and use when contacting Customer Service:...
  • Page 2 REGISTER YOUR LIFETIME PRODUCT TODAY! There are benefi ts to registering your Lifetime product. With our new online product registration form, it’s fast and easy! Register with us at www.lifetime.com and enjoy these great benefi ts: as NEW product notifi cations and special closeout promotions! receipt to verify your product purchase date before warranty service will be provided.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS DAMAGE AND WILL VOID WARRANTY. To ensure safety, do not attempt to assemble this product without reading and materials for parts and/or additional instruction material. identify and inventory all parts and hardware using the parts and hardware lists and identifi...
  • Page 4 TOOLS AND PARTS REQUIRED FOR THIS ASSEMBLY 1/2” Wrench 7/16” Wrench 9/16” Wrench Pliers Phillips Screwdriver Electric Drill Rubber Mallet Cement Mix (7 80 lb bags) Tape Measure 1/2” x 3’ Rebar Wood Block (1) Included Shovel *Two adults required to complete assembly* Only adults should set up the product.
  • Page 5 ASSEMBLY GUIDES Refer to the following areas throughout the instructions to assist in the assembly process: This area is located at the top, TOOLS AND HARDWARE REQUIRED FOR THIS PAGE left-hand corner of the page and indicates which tools and hardware are needed to complete the assembly steps on a page.

  • Page 6: Parts List

    PARTS LIST Item Description Top Pole Middle Pole Plastic Guard Inner Channel Outer Tube Channel Stop Handle Trigger Spring Pole Cap Center Frame Pad Corner Frame Pad HARDWARE LIST Item Description Pole Assembly Hardware (1068524)
  • Page 7 HARDWARE LIST Item Description Backboard & Rim Assembly Hardware (1045426) Compression Spring Spring Retainer Plate Backboard to Pole Assembly Hardware (1046466) Handle Assembly Hardware (1046262) Trigger Spring Frame Pad Assembly Hardware (HH00700)

  • Page 8: Parts Identifier

    PARTS IDENTIFIER Parts shown at 10% of Actual Size ” Top Pole Warning Sticker ” Middle Pole ” ” ” 1/16 Corner Frame Pad Center Frame Pad Inner Channel Outer Tube...
  • Page 9 PARTS IDENTIFIER Parts shown at 10% of Actual Size Parts shown at 5% of Actual Size Part shown at 25% of Actual Size Plastic Guard Parts shown at 25% of Actual Size Handle Pole Cap Channel Stop Trigger Spring...

  • Page 10: Hardware Identifier

    HARDWARE IDENTIFIER POLE ASSEMBLY HARDWARE Hardware shown at Actual Size Screw Washer BACKBOARD TO RIM ASSEMBLY HARDWARE Hardware shown at Actual Size Flange Nut...
  • Page 11 HARDWARE IDENTIFIER BACKBOARD TO RIM ASSEMBLY HARDWARE (CONTINUED) Hardware shown at 25% of Actual Size Compression Spring Spring Retainer Plate BACKBOARD TO POLE ASSEMBLY HARDWARE Hardware shown at Actual Size 7 1/8” 1/2” Center (Not actual length) HANDLE ASSEMBLY HARDWARE Hardware shown at Actual Size 7”...
  • Page 12 HARDWARE IDENTIFIER HANDLE ASSEMBLY HARDWARE (CONTINUED) Hardware shown at Actual Size 7 1/16” (Not actual length) Screw Trigger Spring Hardware shown at Actual Size (Only eight of the 10 Screws will be used)

  • Page 13: Ground Preparation

    GROUND PREPARATION HARDWARE REQUIRED PARTS REQUIRED Part shown at 10% of Actual Size TOOLS REQUIRED 1/2” x 36” Rebar Tape Measure Cement Mix Level Shovel...
  • Page 14 fl ush with the edge of the playing surface. fi lled to the level of the playing surface. 18” Note: A Ground Sleeve is available as an alternative to cementing the Pole into the ground. Please contact Customer Service or visit Lifetime.com online for more information.
  • Page 15 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Bottom Pole (ALE) (do not scratch the powder coating). Slide the dimpled end of the Bottom Pole (ALE) into the cement up to...
  • Page 16 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE The slots in the Bottom Pole (ALE) must be parallel to the playing surface. parallel to the playing surface. Playing Surface Note: Use a Level to make sure the Bottom Pole is standing vertical. Form the cement into a downward slope away from the pole to allow water runoff.
  • Page 17 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” x 36” Rebar Bottom Pole (ALE) Rebar Note: Allow 1-4 hours for the concrete to set before continuing.
  • Page 18 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Bottom Pole (ALE) with the pole. Allow the concrete to set for at least 72 hours before installing the rest of the system onto the Bottom Pole. Cement Level Inside Pole Rebar Note: STOP HERE! The concrete must cure for at least 72 hours (3 days) before installing the rest of the system.

  • Page 19: Pole Assembly

    POLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size Screw *Only one of the Domed Countersink Washers (CIH), Screws (ADS) will be used in this section. The remaining hardware will be used later in the assembly. PARTS REQUIRED Parts shown at 10% of Actual Size Top Pole ”...
  • Page 20 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Insert the with the into the as shown. Then slide the onto Large Holes Small Holes Warning Sticker...
  • Page 21 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 9/16" Place the Pole Bracket (ALL) onto the , and attach it to the with the hardware shown.
  • Page 22 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Align the hole in the Top Pole (ALH) with the slot in the slide the Top Pole over the Middle Pole. Insert a through a Domed Countersink Washer (CIH), into the small hole in the Top Pole, and into the slot in the Middle Pole as shown.
  • Page 23 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Wood Block ATTENTION: THIS STEP CANNOT BE REVERSED! times on a piece of scrap wood or cardboard. This must be done even if the Poles cover the slots before seating has occurred. If the Top Pole (ALH) does not completely cover the slots on the Middle Pole after seating, DO NOT COMPLETE ASSEMBLY.
  • Page 24 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE After the Poles have been seated, insert a (ABZ) Note: Chuck the #14 x 1” Self-Drilling Screw (ABZ) directly into an Electric Drill for easy installation, or use a 3/8” Hex Driver.
  • Page 25 BACKBOARD TO RIM ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size Hardware shown at 25% of Actual Size Compression Spring Spring Retainer Plate...
  • Page 26 BACKBOARD TO RIM ASSEMBLY PARTS REQUIRED Parts shown at 10% of Actual Size Part shown at 5% of Actual Size Part shown at 25% of Actual Size Plastic Guard TOOLS REQUIRED 1/2” Wrench 7/16” Wrench Pliers...
  • Page 27 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7/16” (Not to scale) Slide the through the as shown. Notch Hex Bolts (AAS), two 1/2” x 2 5/16” Galvanized Spacers (ABS), and two Centerlock Nuts (AAB). Note: Tighten the hardware securely now.
  • Page 28 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” Insert two 5/16” x 2 1/2” Tap Bolts (ABG) with the 5/16” Washers (ABD) and the as shown, and secure the hardware with two Note: Make sure that the 5/16” x 2 1/2” Tap Bolts are positioned on the outside edge of the holes as shown.
  • Page 29 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” Insert the through the upper part of the opening on the as shown. Connect the and Plastic Guard (ALD) to the with the hardware shown. Thread the all the way down on the .38”...
  • Page 30 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” (Not to scale) (Not to scale) Slide the onto the , and place the Spring Retainer Plate (AOW) over the Compression Springs. Tighten the until the does not wobble to complete this step. Note: DO NOT COMPLETELY TIGHTEN THE 5/16”...
  • Page 31 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” Slide a into the crimped slot in each Note: Tighten the 5/16” Nylock Flange Nuts (ABK) until they are fl ush with the ends of the Bolts.
  • Page 32 BACKBOARD TO POLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size 7 1/8” (Not actual length) PARTS REQUIRED Parts shown at 10% of Actual Size ” ” 1/16 TOOLS REQUIRED Rubber Mallet...
  • Page 33 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7 1/8” (Not actual length) Secure the Short Extension Arms (AKC) location shown with the hardware indicated. Note: Tighten the 1/2” Centerlock Nut (AAX) until it is fl ush with the end of the Bolt.
  • Page 34 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7 1/16” (Not actual length) Secure the ends of the Long Extension Arms (AKB) that only have one hardware indicated. Note: Tighten the 1/2” Centerlock Nut (AAX) until it is fl ush with the end of the Bolt.
  • Page 35 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7 1/8” (Not actual length) CAUTION: HAVE ONE ADULT HOLD THE BACKBOARD IN PLACE UNTIL ASSEMBLY HAS BEEN COMPLETED! Rim on cardboard to prevent scratching. Then secure the Short and Long Extension Arms (AKC & AKB) to the Top Pole (ALH) with the hardware shown. Note: Tighten the 1/2”...

  • Page 36: Handle Assembly

    HANDLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size 7” (Not actual length) 7 1/8” (Not actual length) Screw Trigger Spring...
  • Page 37 HANDLE ASSEMBLY PARTS REQUIRED Parts shown at 10% of Actual Size Inner Channel Outer Tube Parts shown at 25% of Actual Size Spring Channel Stop Trigger Handle TOOLS REQUIRED Phillips Screwdriver 1/2” Wrench 9/16” Wrench...
  • Page 38 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Attach the Lock Tab (APS) to the Trigger (AMN) with the hardware shown, and slide the Trigger Spring (AQI) onto the Trigger in the location shown. Insert the Trigger Assembly into the Handle (AKI) as shown. The Lock Tab (APS) will fi...
  • Page 39 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Attach the Handle Assembly to the Outer Tube (ALB) with the hardware shown. The Lock Tab (APS) will fi t into the notch on the Outer Tube. Notch Note: Make sure that the Inner Channel (AKQ) has been removed from the Outer Tube before performing this step.
  • Page 40 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Trigger (AMN), insert the notched end of the Inner Channel (AKQ) into the Outer Tube (ALB) as shown. Slide the Inner 10’ Insert the into the top of the Outer Tube (ALB) as shown.
  • Page 41 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” Attach the Inner Channel (AKQ) to the Pole Bracket (ALL) with the hardware shown. WARNING Do not overtighten the Cap Nut. If the end of...
  • Page 42 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7 1/8” (Not actual length) Secure the Outer Tube (ALB) to the Long Extension Arms (AKB) with the hardware shown. Note: Tighten the 1/2” Centerlock Nut (AAX) until it is fl ush with the end of the Bolt.
  • Page 43 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7” 9/16” (Not actual length) Insert the 3/8” x 7” Hex Bolt (AAZ) through the holes in the Short Extension Arms (AKC) 3/8” Centerlock Nut (ABB). Note: Tighten the 3/8” Centerlock Nut until it is fl ush with the end of the Bolt.
  • Page 44 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Wrench into the #2 hole on the Left as shown. 5.10 Note: Repeat this step to hook the end of the other Spring into the #2 hole in the Right Backboard Bracket (AJK). Using the closed end of a Wrench, stretch the up and over the 3/8”...
  • Page 45 HARDWARE REQUIRED Hardware shown at Actual Size (Only eight of the 10 Screws will be used) Hardware shown at Actual Size *Take this hardware from Section 2 PARTS REQUIRED Parts shown at 10% of Actual Size Center Frame Pad Part shown at 25% of Actual Size Corner Frame Pad Pole Cap...
  • Page 46 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Remove the plastic fi lm from the , and attach the Attach the to the in the locations shown with the hardware indicated.
  • Page 47 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE AT LEAST THREE ADULTS ARE REQUIRED. DO NOT THAN THREE ADULTS AND THREE LADDERS. It is critical that the instructions in the following steps are followed . Failure to properly orient and align the pole sections will render the pole unusable.
  • Page 48 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE While two people continue to hold the assembly in place, set the Wood Block (AMW) a hammer or mallet. You must have wood on top of the Pole before hitting it with a hammer to prevent scratching the powder coating. If the does not completely cover the slots on the Bottom Pole (ALE) after seating, DO NOT COMPLETE ASSEMBLY.
  • Page 49 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Assembly), measure 1” up from the bottom of the Use the Electric Drill to install the shown. Note: Chuck the #14 x 1” Self-Drilling Screw (ABZ) directly into an Electric Drill for easy installation, or use a 3/8” Hex Driver.
  • Page 50 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Press the Pole Cap (ALM) onto the top of the Pole Assembly. Attach the Net (AKZ) to the Note: If a replacement Net is needed, please call our Customer Service Department. Our Nets are shorter than average to reduce the risk of entanglement.
  • Page 51 OPERATION OF HEIGHT ADJUSTMENT SYSTEM To Adjust the Height of the Hoop: POLE CARE AND SYSTEM MAINTENANCE tears that could let water in the Pole. Contact our Customer Service Department for replacement parts. are present, do the following: Use an emery cloth to completely remove any rust or chipped paint. Clean the area with a damp cloth and allow it to dry.
  • Page 54 ® ENHANCE YOUR LIFETIME PURCHASE BY ADDING ACCESSORIES OR OTHER GREAT PRODUCTS: To purchase accessories or other Lifetime Products, visit us at: www.lifetime.com Or call: 1-800-424-3865...
  • Page 55 à l’anneau, au panneau ni aux leviers sous aro, el tablero ni los brazos de elevación, ya que esto puede dañar el sistema y anular la garantía. peine d’endommager l’équipement et d’annuler la garantie. www.lifetime.com #FS16500 10/12/2004...

  • Page 56: Warranty Information

    ALL WARRANTY CLAIMS MUST BE ACCOMPANIED BY A SALES RECEIPT. **Call or visit our Web site for Saturday hours** Please include your dated sales receipt and photographs of damaged parts. To register the product, visit our Web site at www.lifetime.com www.lifetime.com...
