Summary of Contents for Lifetime 90192

  • Page 1 MODEL N° 90192 OWNER’S MANUAL Keep this Product ID Number and use when contacting Customer Service:...
  • Page 2 Maintaining your privacy is our long-standing policy at Lifetime. And you can rest as- sured that Lifetime will not sell or provide your personal data to other third parties, or allow them to use your personal data for their own purposes.
  • Page 3 SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS To ensure safety, do not attempt to assemble this product without reading and To ensure safety, do not attempt to assemble this product without reading and following all instructions carefully. Check the entire box and inside all packing following all instructions carefully.
  • Page 4 TOOLS AND PARTS REQUIRED FOR THIS ASSEMBLY Pliers Phillips Screwdriver Electric Drill Rubber Mallet Sand (375 lb) (2, included) *Two adults required to complete assembly*...
  • Page 5 ASSEMBLY GUIDES Refer to the following areas throughout the instructions to assist in the assembly process: This area is located at the top, TOOLS AND HARDWARE REQUIRED FOR THIS PAGE left-hand corner of the page and indicates which tools and hardware are needed to on a page.

  • Page 6: Table Of Contents

    PARTS LIST Item Description Top Pole Middle Pole Bottom Pole Right Backboard Bracket Backboard Corner Frame Guard Center Frame Guard Short Extension Arm Inner Channel Outer Tube Handle Grips Handle Brace Base Pole Brace Wheel 1/2” x 21 3/4” Axle Height Sticker Warning Sticker (Applied to Middle Pole) Front Adjust Parts Kit...

  • Page 7: Backboard To Pole Assembly Hardware (1046466

    HARDWARE LIST Item Description Pole to Base Assembly Hardware (1080080) 1/4” Barrel Nut 5/16” x 1” Hex Bolt 5/16” Nylock Nut 1/4” x 3 1/2” Shoulder Bolt 5/16” Washer 3/16” Allen Wrench Backboard & Rim Assembly Hardware (1045426) 1/4” x 2 3/4” Hex Bolt 1/2”...

  • Page 8: Top Pole

    PARTS IDENTIFIER Parts shown at 10% of Actual Size ” ALH (x1) Top Pole ” (x1) Middle Pole ” ALI (x2) ALE (x1) Pole Brace Bottom Pole 38” ” (x1) (x1) 1/2” x 21 3/4” Axle Right Backboard Bracket ” (x1) AKC (x2) Short Extension Arm...
  • Page 9 PARTS IDENTIFIER Parts shown at 10% of Actual Size (x1) AKZ (x1) Parts shown at 5% of Actual Size (x1) Backboard (x1) Base...

  • Page 10: Outer Tube

    PARTS IDENTIFIER Parts shown at 25% of Actual Size (x1) (x1) Base Cap Channel Stop ALL (x1) Pole Bracket (x2) ALD (x1) ALM (x1) Counterbalance Spring Plastic Guard Pole Cap (x1) (x1) AKI (x2) Outer Tube AMN (x2) Handle Grips Bushing Trigger (x1)
  • Page 11 HARDWARE IDENTIFIER Hardware shown at Actual Size ABE (x2) 3/8” x 4” Hex Bolt ABB (x2) ABR (x2) 3/8” Centerlock Nut 1/2” x 3.41” Spacer CIH (x2) ADS (x2) ABZ (x2) (x2) Domed Counter 1/4” x 3/4” Screw 3/8” Washer sink Washer Hardware shown at Actual Size BZP (x1)
  • Page 12 HARDWARE IDENTIFIER Hardware shown at Actual Size AAV (x2) AAB (x2) 5/16”Jam Nut (x2) 1/4” Center 5/16” x 2 1/2” Tap Bolt lock Nut ACS (x2) ABS (x2) .38” x 1” Steel Spacer 1/2” x 2 5/16” Galvanized Spacer ABK (x6) (x2) (x2) ABD (x2)
  • Page 13 HARDWARE IDENTIFIER Hardware shown at Actual Size 7 1/16” (Not actual length) (x4) AAD (x4) 1/2” Center lock Nut 1/2” x 7 1/16” Hex Bolt ABL (x4) ABN (x4) .69” x .59” Black Spacer 1/2” x 1/8” Spacer Hardware shown at Actual Size 7”...
  • Page 14 HARDWARE IDENTIFIER Hardware shown at Actual Size AAC (x1) 5/16” x 1 3/4” Hex Bolt CNE (x1) CNI (x4) 5/16” x 1” Pan Head Screw AQH (x2) Trigger Spring (x4) (x1) 1/2” Centerlock Nut Hardware shown at Actual Size ADP (x10)
  • Page 15 POLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size ABE (x2) ABB (x2) 3/8” x 4” Hex Bolt lock Nut ABR (x2) 1/2” x 3.41” Spacer ABZ (x2) CIH (x2) (x2) ADS (x2) Tapping Screw 3/8” Washer 1/4” x 3/4” Screw sink Washer PARTS REQUIRED Parts shown at 10% of Actual Size...
  • Page 16 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ABE (x2) (x2) ABR (x2) Insert the with the into the as shown. Then slide the onto the Hex Bolts. Large Holes Small Holes...
  • Page 17 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 9/16" (x2) ABB (x2) Place the onto the , and attach it to the with the hardware shown.
  • Page 18 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ADS (x1) CIH (x1) Align the hole in the Top Pole (ALH) with the slot in the slide the Top Pole over the Middle Pole. Insert a through a and the small hole in the Top Pole and into the slot in the Middle Pole as shown.
  • Page 19 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ADS (x1) CIH (x1) Align the hole in the with the slot in the Bottom Pole (ALE) and slide the Middle Pole over the Bottom Pole. Insert a through the small hole in the Middle Pole and into the slot in the Bottom Pole using the hardware shown.
  • Page 20 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ATTENTION: THIS STEP CANNOT BE REVERSED! In order to seat the Poles, strike each end of the Pole very hard fi ve to six times on a piece of scrap wood or cardboard. This must be done even if the Poles cover the slots before seating has occurred.
  • Page 21 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ABZ (x2) After the Poles have been seated, insert two (ABZ) into the back of the Pole as shown. Note: Chuck the #14 x 1” Self-Tapping Screw (ABZ) directly into an Electric Drill for easy installation, or use a 3/8” Hex Driver.

  • Page 22: Pole Brace

    POLE TO BASE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size AAO (x2) BTS (x1) AAE (x2) 5/16” Nylock Nut 1/4” Barrel Nut ABD (x4) 5/16” x 1” Hex Bolt 5/16” Washer BZP (x1) 1/4” x 3 1/2” Shoulder Bolt PARTS REQUIRED Part shown at 5% of Actual Size Parts shown at 25% of Actual Size...
  • Page 23 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Screw the onto the as shown. Note: Make sure the Rubber Gasket is inside the Base Cap. Slide the through one of the and into as shown. Then have one adult position the Bottom Pole (ALE) within the Base as shown with the lip at the bottom of the pole facing outward.
  • Page 24 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2" (x2) BZP (x1) 3/16" (x2) AAO (x2) BTS (x1) ABD (x4) AAE (x2) Attach the fl attened end of the Pole Brace (ALI) to the with the hardware shown. Only fi nger tighten the hardware. Note: Repeat this step to install the other Pole Brace to the other side of the Base.
  • Page 25 BACKBOARD TO RIM ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size AAS (x2) ABC (x2) 1/4” x 2 3/4” Hex Bolt 5/16” x 1 1/4” Carriage Bolt ACS (x2) AAB (x2) .38” x 1” Steel Spacer 1/4” Centerlock Nut ABD (x2) (x2) 5/16”...
  • Page 26 BACKBOARD TO RIM ASSEMBLY PARTS REQUIRED Parts shown at 10% of Actual Size (x1) (x1) (x1) Right Backboard Bracket Part shown at 5% of Actual Size Part shown at 25% of Actual Size ALD (x1) Plastic Guard (x1) Backboard TOOLS REQUIRED (x2) Pliers...
  • Page 27 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7/16” (x2) AAS (x2) AOU (x1) ABS (x2) AAB (x2) (Not to scale) Slide the through the as shown. Notch Connect the Backboard Brackets together using two Hex Bolts (AAS), two , and two Note: Tighten the hardware securely now.
  • Page 28 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” (x2) (x2) ABD (x2) (x2) Insert two with the and the through the bottom holes in the back of the Rim as shown, and secure the hardware with two Note: Make sure that the 5/16” x 2 1/2” Tap Bolts are positioned on the outside edge of the holes as shown.
  • Page 29 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” ACS (x2) AAV (x2) ABK (x2) Insert the through the upper part of the opening on the backside of the as shown. Connect the to the with the hardware shown. Thread the all the way down on the .
  • Page 30 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE (x1) (x2) 1/2” (Not to scale) (Not to scale) ABK (x2) Slide the onto the , and place the over the Compression Springs. Tighten the until the does not wobble to complete this step. Note: DO NOT COMPLETELY TIGHTEN THE 5/16”...
  • Page 31 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” ABC (x2) ABK (x2) Slide a into the crimped slot in each Backboard Channel as shown. Bend the Backboard Brackets outward by hand and gently lift them over . Then securely fasten the Backboard Brackets to the Backboard Channels with the hardware shown.
  • Page 32 BACKBOARD TO POLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size ABL (x4) (x4) ABN (x4) .69” x .59” Black Spacer 1/2” Centerlock Nut 1/2” x 1/8” Spacer 7 1/16” (Not actual length) AAD (x4) 1/2” x 7 1/16” Hex Bolt PARTS REQUIRED Parts shown at 10% of Actual Size ”...
  • Page 33 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7 1/16” (x2) AAD (x1) (Not actual length) (x1) ABL (x2) Secure the Short Extension Arms (AKC) to the Backboard Brackets in the location shown with the hardware indicated. Note: Tighten the 1/2” Centerlock Nut (AAX) until it is fl ush with the end of the Bolt.
  • Page 34 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7 1/16” (x2) AAD (x1) (Not actual length) (x1) ABL (x2) Secure the ends of the Long Extension Arms (AKB) that only have one hole to the Backboard Brackets in the location shown with the hardware indicated.
  • Page 35 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7 1/16” (x2) ABN (x4) AAD (x2) (Not actual length) (x2) CAUTION: HAVE ONE ADULT HOLD THE BACKBOARD IN PLACE UNTIL ASSEMBLY HAS BEEN COMPLETED! Rim on cardboard to prevent scratching. Then secure the Short and Long Extension Arms (AKC &...
  • Page 36 HANDLE ASSEMBLY HARDWARE REQUIRED Hardware shown at Actual Size 7” (Not actual length) CNI (x4) AAZ (x1) 5/16” x 1” Pan Head Screw 3/8” x 7” Hex Bolt 7 1/16” (Not actual length) ABO (x2) AAD (x1) 1/2” x 1” Poly Spacer 1/2”...
  • Page 37 HANDLE ASSEMBLY PARTS REQUIRED Parts shown at 10% of Actual Size ALB (x1) Outer Tube AKQ (x1) Inner Channel Parts shown at 25% of Actual Size (x1) (x2) AMN (x2) Outer Tube Counterbalance Spring Trigger Bushing (x1) Channel Stop (x1) AKI (x2) Handle Grip (x1)
  • Page 38 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ADR (x4) AQH (x2) Attach the to the Triggers (AMN) with the hardware shown, and slide the Trigger Spring (AQH) onto the Triggers in the locations shown. Position the Trigger Assembly onto the as shown.
  • Page 39 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE CNH (x2) CNI (x4) 7/16” AZP (x2) (x4) Secure the Handle Grips to the Handle Assembly with the hardware shown. Attach the Handle Assembly to the Outer Tube (ALB) with the hardware shown. Fit the into the notch on the Outer Tube.
  • Page 40 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE CNE (x1) Attach the to the Outer Tube (ALB). Slide the Two-Head Snap Button (CNE) into the hole at the top of the Inner Channel (AKQ). Orient the as shown and place it within with the edge of the Inner Channel.
  • Page 41 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE While squeezing both Triggers (AMN), insert the notched end of the Inner Channel (AKQ) into the Outer Tube (ALB) as shown. Slide the Inner Channel into the Outer Tube until the 10’ mark has been reached. Then release the Trigger so it clicks into place.
  • Page 42 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 1/2” (x2) AAC (x1) AAN (x1) Attach the Inner Channel (AKQ) to the with the hardware shown. Do not overtighten the Cap Nut. If the end of the Bolt breaks through the plastic cap, call our Customer Service Department.
  • Page 43 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7 1/16” (x2) AAD (x1) (Not actual length) (x1) ABO (x2) Secure the Outer Tube (ALB) to the Long Extension Arms (AKB) with the hardware shown. If needed, use a Rubber Mallet to tap the hardware into place. 5.10 Note: Tighten the 1/2”...
  • Page 44 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7” 9/16” (x2) (Not actual length) AAZ (x1) ABB (x1) Insert the 3/8” x 7” Hex Bolt (AAZ) through the holes in the Short Extension Arms (AKC) that are closest to the Pole. Secure the 3/8” x 7” Hex Bolt to 5.11 the Short Extension Arms with the Note: Tighten the 3/8”...
  • Page 45 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Hook one of the ends of a into the #3 hole on the as shown. 5.12 Note: Repeat this step to hook the end of the other Spring into the #3 hole in the Right Backboard Bracket (AJK). Using the closed end of a Wrench, stretch the up and over the 3/8”...
  • Page 46 HARDWARE REQUIRED Hardware shown at Actual Size ADP (x10) PARTS REQUIRED Parts shown at 10% of Actual Size AKZ (x1) (x2) Corner Frame Guard (x1) Center Frame Guard TOOLS REQUIRED Sand (375 lb) Electric Drill...
  • Page 47 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ADP (x8) Remove the plastic fi lm from the , and attach the to the Backboard in the location shown with the hardware indicated. Make sure that the Center Frame Pad is centered on the metal piece of the Backboard as shown. Attach the to the in the locations...
  • Page 48 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE (375 lb) (416 lb of sand required) a. Fill the with sand. b. Screw the onto the fi ll hole. c. Using two adults, stand the Base up on a smooth surface. For safety reasons, we recommend that sand be used instead of water to fi...
  • Page 49 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE a. Add cold water up to the fi ll hole, leaving two inches of space at the top for expansion. b. Add one tablespoon of chlorine bleach to the water to prevent algae formation. c.
  • Page 50 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE Attach Net (AKZ) to the Note: If a replacement Net is needed, please call our Customer Service Department. Our Nets are shorter than average to reduce the risk of entanglement.

  • Page 51: Pole Cap

    OPERATION OF HEIGHT ADJUSTMENT SYSTEM The basketball system may be adjusted from 7 1/2 feet to 10 feet. Hold the Handle tightly and squeeze the Trigger. Raise the Handle to lower the Backboard, or lower the Handle to raise the Backboard. MOVING THE SYSTEM The system must only be moved by people capable of handling its weight.
  • Page 52 NOTES...
  • Page 53 NOTES...
  • Page 54 ® ENHANCE YOUR LIFETIME PURCHASE BY ADDING ACCESSORIES OR OTHER GREAT PRODUCTS: To purchase accessories or other Lifetime Products, visit us at: www.lifetime.com Or call: 1-800-424-3865...
  • Page 55 No cuelgue nada de la dañar el sistema y anular la garantía. www.lifetime.com #FS16400 10/12/2004...

  • Page 56: Warranty Information
