Hardware Installation

Front Panel

The front panel provides LED's for device status. Refer to the
following table for the meaning of each feature.
PWR Power status of the SOHO AP Router. A steady
LED indicates the power is applied to the unit.
WLAN The WLAN LED will be ON when AP function
enable, at this time Wireless clients are able to
connect to the AP.
WAN Wide Area Network status. WAN LED is
illuminated when there is a good connection to
the 10 BaseT mode Ethernet port.
LAN Local Area Network status. LED will be on when
1,2,3,4 Ethernet port is connected.

Rear Panel

The rear panel features 4 LAN ports, 1 WAN port and Factory
Reset button. Refer to the following table for the meaning of each
feature.
Power Used to connect to the power outlet. Only use the
(DC 5v) power adapter provided with the device. Use of an
unauthorized power adapter may cause damage to
your device and violate your warranty.
Internet The RJ-45 Ethernet port is used to connect your
(WAN) SOHO AP Router to your xDSL.
Reset Resets the configuration to default settings.
LAN The RJ-45 Ethernet ports used to connect your PC
(1,2,3,4) or HUB. The Ethernet Cable used can be normal
Ethernet cables or even Crossover Cable.
The device has internal Auto - Crossover detection
circuits to automatic identify them.
