- Page 1 Wi-Fi Ethernet Client T-316 User’s Guide Revision 1.2 February 18, 2003 Copyright © 2002, 2003 Gemtek Systems Holding BV www.gemtek-systems.com...
-
Page 2: Copyright
This user’s guide and the software described in it are copyrighted with all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written permission of Gemtek Systems Holding BV. -
Page 3: Table Of Contents
Prerequisite Skills and Knowledge ..................5 Conventions Used in this Document ..................5 Help Us to Provide Quality Documentation ................5 Gemtek Systems Technical Support ..................5 CHAPTER 1 – INTRODUCTION................... 6 CHAPTER 2 – WIRELESS LAN BASICS ................7 CHAPTER 3 – CONFIGURING THE WI-FI ETHERNET CLIENT ......... 8 3.1 Overview ........................8... -
Page 4: About This Guide
Gemtek Systems Technical Support Having problems, please visit our online technical support @ http://www.gemtek-systems.com. The site offers: The latest software, user documentation and product updates Frequently Asked Questions (FAQ) Direct contact to the Gemtek Systems support centers Gemtek Systems Page 5... -
Page 5: Chapter 1 - Introduction
T-316 User’s Guide Chapter 1 – Introduction Thank you for purchasing the Gemtek Systems Wi-Fi Ethernet Client. This manual will assist you with the installation procedure. The package you have received should contain the following items: T-316 Wi-Fi Ethernet Client... -
Page 6: Chapter 2 - Wireless Lan Basics
T-316 User’s Guide Chapter 2 – Wireless LAN Basics Wireless LAN (Local Area Networks) systems offer a great number of advantages over traditional, wired systems. Wireless LANs (WLANs) are more flexible, easier to set up and manage and often more cost effective than their wired equivalents. Using radio frequency (RF) technology, WLANs transmit and receive data using only the air as a medium, minimizing the need for wired connections. -
Page 7: Chapter 3 - Configuring The Wi-Fi Ethernet Client
The following section will assist in installing the wireless LAN Adapter successfully. You will connect the T-316 Ethernet Client to your system, then set the appropriate networking parameters. The Gemtek Systems Ethernet Client eliminates the need to install drivers and for setting the network properties. -
Page 8: Connecting The Ethernet Client
4. Plug the Ethernet cable into the Ethernet connector (RJ45) on your system’s Ethernet port. There are three LED indicators on the front of the T-316: Activity (ACT), Power (POWER) and Link Status (LINK). The Power indicator should be on continuously (green), the Link Status (yellow) and Activity (green) will blink indicating activity on the wired and wireless networks respectively. -
Page 9: Configuring The Network Connection
T-316 User’s Guide 3.3 Configuring the Network Connection The T-316 has a default IP Address of 192.168.5.99 with a subnet mask of 255.255.255.0. The computer that you are using for initial configuration must have its IP Address set within the same range, i.e., 192.168.5.xxx, where xxx is any number between 001 and 254, excluding 099. -
Page 10: Information
T-316 User’s Guide 3.3.1 Information The Information window displays the current setup status. Figure 3.3 – Information page Current Communications Quality Indicates the measured Communications Quality of the Basic Service Set to which the station is currently connected. The value in this field is based on signal and noise level measurements. -
Page 11: Wireless Configuration
Access Point. SSID (default is blank) The SSID (Service Set ID) is the name given to the wireless network that the T-316 is associated with. Only Wireless Ethernet Clients and clients that share the same SSID are able to communicate with each other. -
Page 12: Security (Part Of The Wireless Page)
T-316 User’s Guide 3.3.3 Security (part of the Wireless page) Figure 3.5 – Security page WEP Enabled (default is unchecked) Encryption (WEP)—additional measure of security on your wireless network which can be achieved by using WEP (Wired Equivalent Privacy) encryption. When an encrypted frame is received it will only be accepted if it decrypts correctly. -
Page 13: Server Configuration
T-316 User’s Guide 3.3.4 Server Configuration Selecting the IP Addr tab brings this page. Figure 3.6 – Server configuration page Static (default=selected) Select Static (recommended) to assign the IP, Subnet Mask and Gateway Address. DHCP (default=not selected) If the Wireless Ethernet Client is part of a network with a DHCP server, the DHCP server will assign the IP settings to the Wireless Ethernet Client automatically. -
Page 14: Stations
T-316 User’s Guide 3.3.5 Stations Selecting the Stations tab brings this page. It shows the device that is bridging with the Ethernet Client. Figure 3.7 – Stations page Gemtek Systems Page 15... -
Page 15: Administration
Change Username and Password (default is blank) A password can be used to prevent unauthorized access to the configuration of the T-316. However, should you choose to use a password, it must be 15 characters in length or less. Re-enter the password in the next field to verify that it is correct, and click Change Password for the change to take effect. -
Page 16: Help
T-316 User’s Guide 3.3.7 Help This is reserved for future use. Figure 3.10 – Help page Gemtek Systems Page 17... -
Page 17: Chapter 4 - Troubleshooting
Check to see that the Access Point the T-316 is associating with is working and within range (300’ maximum with no obstructions) Check the settings of the T-316 to see that it is capable of associating with the AP • DHCP client must be enabled unless the network administrator states otherwise •... -
Page 18: Chapter 5 - Technical Specifications
T-316 User’s Guide Chapter 5 – Technical Specifications T-316 Technical Specification Standards supported IEEE 802.11 standard for Wireless LAN All major networking standards (including IP, IPX) Environmental Operating temperature (ambient): -10 ~ 50°C Humidity: Max. 95% Non-condensing Power specifications DC power supply - Input : DC 100-240 50-60 Hz 2A - Output: 5V DC 2A converter incl. -
Page 19: Chapter 6 - Glossary
T-316 User’s Guide Chapter 6 – Glossary 802.11: 802.11 is a family of specifications for wireless local area networks (WLANs) developed by a working group of the Institute of Electrical and Electronics Engineers (IEEE). The original specification provides for an Ethernet Media Access Controller (MAC) and several physical layer (PHY) options, the most popular of which uses GFSK modulation at 2.4GHz, enabling data rates of 1 or 2Mbps. - Page 20 T-316 User’s Guide IP: The Internet Protocol (IP) is the method or protocol by which data is sent from one computer to another on the Internet. Each computer (known as a host) on the Internet has at least one IP address that uniquely identifies it from all other computers on the Internet.
- Page 21 T-316 User’s Guide SNMP is described formally in the Internet Engineering Task Force (IETF) Request for Comment (RFC) 1157 and in a number of other related RFCs. SSL: The Secure Sockets Layer (SSL) is a commonly-used protocol for managing the security of a message transmission on the Internet.
- Page 22 T-316 User’s Guide Wi-Fi: Wi-Fi is short for wireless fidelity and is another name for IEEE 802.11b. It is a trade term promulgated by the Wireless Ethernet Compatibility Alliance (WECA). "Wi-Fi" is used in place of 802.11b in the same way that "Ethernet" is used in place of IEEE 802.3. Products certified as Wi-Fi by WECA are interoperable with each other even if they are from different manufacturers.
