Page 1: P380
P380 Wi-Fi Inter-Building Router User’ s Guide ．Wireless Broadband Anywhere ．Wireless Broadband Anywhere．Wireless Broadband Anywhere．... -
Page 2: Table Of Contents
P380 Users guide Contents P380 ___________________________________________________________1 User’ s Guide _________________________________________________________ 1 Overview________________________________________________________4 Wireless Networking System ____________________________________________ 4 Features ________________________________________________________5 3 Operating Modes _______________________________________________6 Starting Up ______________________________________________________8 Device Status page ______________________________________________ 10 Setup Wizard ___________________________________________________ 11 Operation Mode Settings Page _________________________________________ 11... - Page 3 P380 Users guide Administration _______________________________________________________ 37 Glossary _______________________________________________________ 39...
-
Page 4: Overview
Wireless Networking System, which provides miscellaneous WAN access. Wireless Networking System P380 is part of the Wireless Internet Service Provision System. It provides access for locally connected computers to WAN, such as the Internet. In Figure 1 shown below, P380 client devices are connected to P380 access points (please refer to P380 specification). -
Page 5: Features
P380 Users guide Features P380 is based on indoor architecture. An indoor unit with 2.4 GHz antennas is placed on the mast or the ceiling of the construction elements. It is connected to a UTP cable. An individual computer or an entire local network can gain access to the Internet by simply connecting the P380 indoor unit to the switch/hub. -
Page 6: Operating Modes
3 Operating Modes The P380 Router supports 3 different kind of operating modes: AP-Router, AP and Bridge. AP-Router Mode In this mode, the P380 wireless unit plays the roles of the wireless network Access point and a router. Firewall Wireless... - Page 7 P380 Users guide Bridge Mode When operating in this mode, one P380 device can connect with another P380 device and form wireless “bridge” interconnecting two or more local networks. Note that all these devices must work in the same frequency channel and must have the same SSID string.
-
Page 8: Starting Up
1. Launch a standard web browser on a computer connected to the network. 2. Enter the P380 IP address given to you from the ISP into the URL field of your web browser (the default setting is 192.168.2.2). P380 device provides SSL (Secure Sockets Layer) feature, so use https://192.168.2.2... - Page 9 P380 Users guide Figure 5: Welcome screen Click on the “Setup Wizard” button on the menu bar to begin P380 device configuration (described in the following section).
-
Page 10: Device Status Page
Figure 6: Device Status table The Device Status page is divided into to four parts: System Status table - This table shows P380 software version, system uptime (after last reboot), average load, memory usage and radio signal strength (RSSI). System service and interfaces status is shown in “Service/Interface Status” table - This table shows wireless interface and system services state. -
Page 11: Setup Wizard
Network statistics are shown in separate table - This table contains statistics for both interfaces of the P380 – wired and wireless. The wired interface is called LAN, and the wireless interface is called WLAN. Each column corresponds to the statistics value of the interfaces: TxData –... -
Page 12: General Configuration Settings Page
System Identification – free form system identification code for easier device identification by the service staff. Serial Number – A unique serial number of the P380 device. Users should not change this number. Address – The location of the device. -
Page 13: Network Configuration Settings Page
Network Configuration Settings page v Router Mode In Router mode, LAN (Local Area Network) and WAN (Wide Area Network – For P380, this can be the enterprise networks on the Internet) configurations can be modified using the LAN Settings and the WAN Settings tables shown as followed: Figure 9: Network Configuration Settings page -1 (Router mode) WAN settings must be set up according to the information provided by the ISP. -
Page 14: Wireless Configuration Settings Page
172.16.0.0/12 and 192.168.0.0/16) . v AP Mode In AP and Bridge mode, P380 does not require an active LAN (Local Area Network) interface, so the “LAN Interface Settings” table is not displayed. Figure 10: Network Configuration Settings page -2 (non-Router mode) Click on the “Back”... - Page 15 P380 Users guide Figure 11: Wireless Configuration Settings page At lease two essential parameters are required to setup :...
-
Page 16: Redirection Service
You may desire additional security on your wireless network, which can be achieved by using WEP (Wired Equivalent Privacy) encryption. P380 offers 64/128 bit WEP securities on wireless transmissions. Encryption keys are combined by 5 (for 64 bit WEP) or 13 (for 128 bit WEP) pairs of hexadecimal digit and separated by colon (e.g.,... - Page 17 The IP of the local connected computer must change to the same subnet of the new site (168.20.1.x/24) first. And then re-click the redirection message above or re-enter the new IP of P380 into URL field of browser, to reconnect to the site.
-
Page 18: Advanced Settings
Main firewall page view is shown as followed: Figure 13: IP Firewall Settings page Note: In AP and Bridge mode P380 has no active LAN (Local Area Network) interface, so the “Firewall configuration” page is not displayed... - Page 19 P380 Users guide This page shows service state and firewall rules list. Rules are divided in two parts – Input rules, which apply to the incoming packets, and the Output rules, which apply to the outgoing packets. User can change these rule lists by editing existing rules, deleting unnecessary ones, and adding new rules.
- Page 20 P380 Users guide Destination IP Address – specified the same as Source IP Destination Netmask – specified the same as Source Netmask Destination port(s) – specified the same as Source port Network protocol – network protocol which the rule affects. Can be specified as one of TCP/UDP/ICMP or any i Hint: If an exact port is specified, use of “any”...
-
Page 21: Acl Configuring
P380 Users guide ACL Configuring All clients MAC are set by acceptable as default in Access Control List function. To deny the MAC address, just click “Add New Rule” button to add the new record. Access Control List setting is shown below:... - Page 22 This page provides a user static route list (present on the system), and ability to edit, delete and add routes. Rule editing and adding is done in the following page: Note: In AP and Bridge mode P380 has no active LAN (Local Area Network) interface, so the “Static Routes” page is not displayed...
-
Page 23: Dhcp Service Configuration
If the server detects that some computers already have addresses from the defined range, the address is not given to the computers. Note: In AP and Bridge mode P380 has no active LAN (Local Area Network) interface, so “DHCP Settings” page is not displayed. - Page 24 Figure 19: Port Forwarding Settings table Note: In AP and Bridge mode P380 has no active LAN (Local Area Network) interface, so the “Port Forwarding Settings” page is not displayed From this page, administrator can modify port forwarding rule list by adding new, delete and edit existing rules.
-
Page 25: Setting Up Administrator Password
Figure 20: Port Forwarding Rule editing table As shown in Figure 20, a port forwarding rule consists of protocol specification – UDP or TCP protocol, port on the P380 needed for application, the local IP address and port to which arriving data will be redirected. -
Page 26: System Tools
Be sure to remember this password (or write it down at a safe location) to access the P380 management administration features in the future. Default factory password setting is “pass” (password is case-sensitive). -
Page 27: Loopback Test
110 corresponds to 11Mbits, 55 correspond to 5.5Mbits and so on. Loopback Test Figure 23: Loopback Test page Loopback test is used for wireless link diagnostics. This page shows data transfer rate between P380 and endpoint device (PC running endpoint program). This transfer rate is... - Page 28 P380 Users guide measured by sending ICMP (Internet diagnostics protocol) stream to the end point device. Data is refreshed every second. To start loopback testing, enter endpoint IP address in the “Endpoint IP address” field and click on the “Start” button in the lower right corner of the page. Status line will show last measured data transfer rate, and the time when this data was received from the endpoint.
-
Page 29: Configuring Snmp Management
Community strings are used for SNMP authentication purposes. It is possible to allow or deny IP address groups from accessing P380 using SNMP. IP address and netmask combination 0.0.0.0/32 means “ANY” IP address. It could be setup by a specified IP, ex 192.168.2.100/32, or by a group, ex 192.168.2.0/24. -
Page 30: Site Survey Page
Hint : Because wireless card is scanning through all radio frequency channels, the page loading time is much longer when compared to the other P380 management pages. Use the rescan button to check signal/noise levels when deploying new Access Points in the existing wireless network. -
Page 31: Upgrade Page
~ Important! When clicking on the “Upgrade button” in the main menu, a warning message box will pop up. Do not enter this page if there is no need to upgrade P380. Simply click on the “Reset” button, if no upgrade is necessary. - Page 32 Hint: Because upgrade is done using the WEB management screen, all management pages still work, so it is still possible to configure P380 before rebooting it. Figure 27: Upgrade page P380 firmware is upgraded using the “Upgrade” page. In this page, the current firmware version is shown.
- Page 33 Write down all configuration settings to be preserved, and set up them, when P380 starts after firmware upgrade. Initial P380 setup is described in the “Starting Up” chapter of this manual.
-
Page 34: Upgrade Utility
When executing the program, the following screen should appear: Figure 30: Upgrade utility In the Host address field, enter the P380 IP address for which the firmware is to be upgraded. Enter the root password and choose Full upgrade. Specify the P380 station firmware file, before clicking on the “Upgrade”... -
Page 35: Reset Page
Reset page To reset the P380 device to the factory setting, click on the “Reset” button. A waiting & redirection message should be shown as below (for the redirection service, please refer to the redirection service section for detail): ~Note: All customized P380 configuration settings will be reset to the default values. -
Page 36: Hardware Reset
~Note: All custom P380 configuration settings will be reset to the default values. Write down any configuration settings, which should be preserved, and set up them, when P380 starts after reset. Initial P380 setup is described in the “Starting Up” chapter of this manual. -
Page 37: Specifications
P380 Users guide Specifications Hardware ETRAX-100LX 16 MB Flash Memory 4 MB Ethernet 10/100 Mbit Wireless IEEE 802.11b Operating system Linux version 2.4.14. Network Subsystem TCP/IP protocol suite Firewall Packet filtering Masquerading (NAT) Port forwarding DHCP DHCP server for one interface (Ethernet) SNMP 802.11 MIB support (read write) - Page 38 P380 Users guide Telnet All console features Scripting User script support (available on the Pro version) SNMP 802.11 MIB support (read write) MIB-I, MIB-II support (read only) Separate community strings for read and write support, standard SNMP trap support.
- Page 39 P380 Users guide Glossary Symbols: 10BaseT 10 Mbps/baseband/twisted pair. The IEEE standard for twisted pair Ethernet. IEEE 802.11b The IEEE standards for the definition of the Wireless high speed (11Mbit) protocol for wireless communication. Authorization the process of determining what types of activities a user is permitted to undertake.
- Page 40 P380 Users guide Ethernet A common, 10Mbps local area network technology invented by Xerox Corporation at the Palo Alto Research Center. Ethernet is a best-effort delivery system that uses CSMA/CD technology. Ethernet can be run over thinwire coaxial cable (10BASE2), thickwire coaxial cable (10BASE5), twisted pair cable (10BASET), or fibre optic cable.
- Page 41 P380 Users guide Internet A collection of networks interconnected by a set of routers, which allow them to function as a single, large virtual network. Internet (note the capital “I”) The largest internet in the world consisting of large national backbone networks (such as MILNET, NSFNET, and CREN) and a myriad of regional and local campus networks all over the world.
- Page 42 P380 Users guide necessary IP address translations. NAT is used for two main tasks – to provide a type of firewall by hiding internal IP addresses and enable a company to use more internal IP addresses. Since they're used internally only, there's no possibility of conflict with IP addresses used by other companies and organizations.
- Page 43 P380 Users guide Route table A table listing information about routes to other hosts or networks, such as the remote network or host address, the interface down which the route exists, the distance to the remote address and the cost of sending data over the route.
- Page 44 P380 Users guide Topology A network topology shows the computers and the links between them. A network layer must know the current network topology to be able to route packets to their final destination. UDP User Datagram Protocol. A transport layer protocol in the TCP/IP suite of protocols.
- Page 45 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
