Summary of Contents for RCA DRC69702

  • Page 1 User manual DRC69702 It is important to read this instruction book prior to using your new product for the first time. RCA DRC69702 IB.indd 3 11/25/2008 2:28:49 PM...
  • Page 2: Important Information

    RCA DRC69702 IB.indd 4 WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER SERVICEABLE PARTS INSIDE.
  • Page 3: Important Safety Instructions

    RCA DRC69702 IB.indd 5 UNIT'S AC 11/25/2008 2:28:50 PM...
  • Page 4: Table Of Contents

    Subtitle Selection ... 12 Angle Selection ... 12 Display Function ... 13 Adjust the LCD Screen ... 13 RCA DRC69702 IB.indd 6 Locating a Desired Section ...14 Locating a Specific Title ... 14 Locating a Specific Chapter ... 14 Locating a Specific Time ... 14 DVD Programmable Memory ...14...
  • Page 5: Disc Formats

    Notes on Unauthorized Discs You may not be able to play back some DVDs on this unit if they were purchased from outside your geographic area or made for business purposes. RCA DRC69702 IB.indd 1 Audio CDs [8cm(3")12cm(5") disc] Compatible...
  • Page 6: Accessories

    • Batteries should not be exposed to excessive heat such as sunshine, fire or the like. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. RCA DRC69702 IB.indd 2 Take out the plastic sheet before operating the Remote Control.
  • Page 7: Control Reference Guide

    Repeats a CD track or the entire disc. SETUP Button In stop mode, it brings up the unit’s SETUP menu. RCA DRC69702 IB.indd 3 9) MENU Button Enters and exits the main DVD menu. NEXT Button Moves forward through titles, chapters or tracks on a disc.
  • Page 8: Control Reference Guide

    11) POWER ON Indicator When the ON / OFF switch is in the ON position, the light will illuminate. 12) Stand RCA DRC69702 IB.indd 4 8) AUDIO / VIDEO OUT Jacks 9) DC IN 9V-12V Jack 10) POWER ON Indicator When the STANDBY / ON switch is in the ON position, the light will illuminate.
  • Page 9: Power Supply

    • If the unit is not properly attached to a vehicle, it may become airborne in the event of an accident and cause damage, injury, or death. • Check your local traffic laws for rules governing the use of video devices in vehicles. RCA DRC69702 IB.indd 5 Monitor - left side right side To A/V IN &...
  • Page 10: Connections

    • If your TV does not have Audio/Video inputs, you will need to purchase an RF modulator (sold separately) and follow the instructions included with it to connect the unit to your TV. RCA DRC69702 IB.indd 6 left side AV-DC cable (included) To A/V OUT &...
  • Page 11: Connecting A Stereo Receiver Or Amplifier

    • Make sure to use the correct Audio/Video cable. Connecting the plugs incorrectly may cause a weak signal. • If you have a mono VCR, the volume level from the speakers will be low. Game System / Video Equipment RCA DRC69702 IB.indd 7 DVD player right side Audio cable (not included)
  • Page 12: Connections

    Warning: Excessive sound pressure from earphones and headphones can cause hearing loss. Avoid listening to sound at excessive levels which could be harmful to your ears. RCA DRC69702 IB.indd 8 Monitor - left side right side Connect to Car Power Adapter To A/V IN &...
  • Page 13: Mounting In The Vehicle

    • All passengers should wear seat belts when using this unit in a moving vehicle. • If in doubt, please contact your vehicle manufacturer for further advice. Installation Guide RCA DRC69702 IB.indd 9 Mounting the DVD Player Mounting the Monitor...
  • Page 14: Using The Stand For Desktop Use

    2. The start-up picture will appear on the screens. 3. After use, slide the STANDBY / ON switch on the DVD player to STANDBY (power off). Slide the ON / OFF switch on the monitor to the OFF position. RCA DRC69702 IB.indd 10 11/25/2008 2:28:58 PM...
  • Page 15: Playing A Disc

    NEXT button to advance chapters/tracks/titles. • For audio CDs, use the number buttons on the remote control to jump immediately to the desired track number. RCA DRC69702 IB.indd 11 accompanying the specific DVD in question for more information about the options available on that DVD.
  • Page 16: Audio Selection

    Elapsed Time: Elapsed time from the beginning of the title which is currently playing. Remain Time: Remaining time of the title which is currently playing. RCA DRC69702 IB.indd 12 ” is displayed. ” is displayed. 11/25/2008 2:29:00 PM...
  • Page 17: Adjust The Lcd Screen

    - - -. You should re-enter correct numbers. • Some discs may not respond to this process. • This method of locating a chapter is available only on a DVD that contains chapter numbers. RCA DRC69702 IB.indd 13 11/25/2008 2:29:00 PM...
  • Page 18: Locating A Specific Title

    • If you press the MEMORY button while the display appears on the TV screen, the display disappears. • The programmed selections will be cleared when you open the disc tray or turn off the DVD player. RCA DRC69702 IB.indd 14 , , ) to move the highlighted bar...
  • Page 19: Repeat Playback

    • You can specify a segment only within the current title or track. • There may be a slight difference between point A and the location where playback actually resumes depending on the disc. RCA DRC69702 IB.indd 15 ” indicator displays on ” indicator displays on the ”...
  • Page 20: Viewing Jpg Files

    PREV or • You can press the ANGLE button to rotate direction of the picture by 90°. • Some discs may not permit this operation. RCA DRC69702 IB.indd 16 PLAY STOP button to display a NEXT button to change the picture.
  • Page 21: Play Modes For Cd Or Jpg Disc

    Note: The program will be deleted if the disc door is opened, or selected files are deleted by selecting "Clear program". RCA DRC69702 IB.indd 17 button to navigate between the windows and the , , ) to select "Edit mode" then press the ENTER button.
  • Page 22: Customizing The Functions Settings

    • Some DVDs may not include your pre-selected language. In this case, the DVD player automatically displays disc menus consistent with the disc's initial language setting. RCA DRC69702 IB.indd 18 button to shift and button to select Subtitle. button to shift and button to select Audio.
  • Page 23: Video Setup

    Sides of the picture are cut off. Note: • Depending on the DVD, you may not be able to view the mode as selected. RCA DRC69702 IB.indd 19 button to select Aspect button to shift and button to select View...
  • Page 24: Settings

    • Never use alcohol, benzine, thinner, cleaning fluid or other chemicals. Do NOT use compressed air to remove dust. Important Note • Before transporting the unit, remove any disc from the disc compartment. RCA DRC69702 IB.indd 20 button to select button to button to select...
  • Page 25: Troubleshooting Guide

    • A non-NTSC disc has been inserted, or the disc region number does not match • Condensation may have formed inside the unit due to a sudden change in Specifications and external appearance are subject to change without notice. RCA DRC69702 IB.indd 21 PLAY button. this.
  • Page 26: Limited Warranty

    Important: Also keep your “Bill of Sale” as proof of purchase. Model no..Product name ... Type of set ... Serial no..Invoice no..Date purchased ... Dealer name ... FOR SERVICE AND REPAIR, PLEASE VISIT RCA DRC69702 IB.indd 22 LIMITED WARRANTY www.1800customersupport.com/RCA www.1800customersupport.com/RCA 11/25/2008 2:29:06 PM...
  • Page 27 RCA DRC69702 IB.indd 23 11/25/2008 2:29:06 PM...
  • Page 28 AVC Multimedia Markham, Ontario L3R 1E3 http://www.1800customersupport.com/RCA Printed in China 811-770191W030 RCA DRC69702 IB.indd 2 11/25/2008 2:52:49 PM...
