REA 105
5.
12
Arc Protection Module
Operator's Manual

Connections

Connection ports:
X1 Port IN1
X2 Port OUT1
X3 Port IN2
Connector X4:
1 Light common Signal relay of sensor
2 Light /NC
3 Light /NO
4 Not in use
5 Not in use
6 HSO2 -(~)
7 HSO2 +(~)
8 Not in use
9 HSO1 -(~)
10 HSO1 +(~)
Sensor fibre connectors:
Sensor OUT
Sensor IN
Signal relay of sensor
Signal relay of sensor
Heavy-duty high-speed semi-conductor output 2
Heavy-duty high-speed semi-conductor output 2
Heavy-duty high-speed semi-conductor output 1
Heavy-duty high-speed semi-conductor output 1
1MRS 751005-MUM
