TECHNICAL SPECIFICATIONS

Bandwidth
Input Connectors
Input Connectors
Max input power
Combiner loss
Port separation
Power supply
Temperature range
Case
Weight
Dimensions
* Ports terminated at 50Ω (2Watt)
CSI16T User Manual
470 MHz – 800MHz
16 BNC-F, 50 Ω of impedance
6 N-F, 50 Ω of impedance
3W (for each input connector)
approx. 6 dB for 4x [4:1]*
approx. 9 dB for 2x [8:1]
approx. 12dB for [16:1] *
30 dB (typical)
AC connector 90÷264Vac /47÷63Hz, (fuse protected)
T2A-50W max
DC connector 10÷ 28 Vdc
-25 ÷ +55 °C
Aluminum, black varnish
4,60 Kg
19"/1U 483 x 398 x 44 mm (WxDxH) with brackets
*
