  • Page 1 CSI16T User Manual Smart Passive Wideband Combiner SN: ________________ Rev.03 Date: 02 August 2017...

  • Page 2: Safety Instruction

    CSI16T User Manual NTRODUCTION CSI16T is a passive wideband combiner designed to work up to 3W of power. CSI16T communicates with Wisycom transmitter (i.e. MTK952N) through coaxial inputs and allows a smart power management: combiner loss are automatically compensate on Tx side! FEATURES ...

  • Page 3: Front Panel

    CSI16T User Manual Rev.03 EAR AND RONT ANEL input C input A output DC - AC input D input B WARNING: ALL THE UNUSED PORTS related to the selected combination SHOULD TO BE TERMINATED (see example AT 50Ω ❶ ❷...
  • Page 4 ■ BLUE: if power supply is in use* *if both DC and AC power supply are present, the combiner uses the one with higher voltage NOTE: CSI16T works without power supply! It works according to the latest set combiner mode.
  • Page 5 XAMPLES Combiner loss can be automatically recovered from MTK952Ns connected to the smart combiner CSI16T: MTK952Ns raise power accordingly to the loss, while keeping the limit on output port (country based). Example1: Combiner 2x [8:1] configuration with high power transmitters:...
  • Page 6 Rev.03 CSI16T User Manual Example3: Combiner [32:1] configuration with high power transmitters: Country power limit:10mW Enabling external compensation on MTK952Ns, the transmitters raise power of 15dB in order to limit to 10mW the maximum power at the output of CSA121T. Both CSI16Ts are configured at 16->1 with external combiner enabled.

  • Page 7: Technical Specifications

    CSI16T User Manual Rev.03 TECHNICAL SPECIFICATIONS 470 MHz – 800MHz Bandwidth 16 BNC-F, 50 Ω of impedance Input Connectors 6 N-F, 50 Ω of impedance Input Connectors 3W (for each input connector) Max input power approx. 6 dB for 4x...
  • Page 8 Wireless System Communications Via Spin 156  I-36060 Romano d’Ezzelino  Italy Tel. +39 -0424 -382605  Fax +39 - 0424 - 382733 www.wisycom.com  e-mail: sales@wisycom.com...
