WisyCom MTP30 Quick User Manual

WIRELESS MICROPHONE SYSTEMS
MTP30
Ultra-lite Wireless Professional Transmitters
Main Features
U
⇒ Up to 96 MHz bandwidth in 470/870 MHz range
⇒ Enhanced robustness against inter-modulation and antenna
performances:
RF part with pass-band filter and circulator (option)
⇒ Miniature design with flexible pcb (no connectors)
for extended reliability
⇒ Ultra-light metal alloy body (80g without batteries)
⇒ ENR compander system
⇒ Battery:
- 2 AA Alkaline or rechargeable NiMH
⇒ Autonomy:
> 10h @ 50mW output power
> 14h @ 10mW output power
⇒ Infrared interface for management and firmware update
Easy and quick to setup thru an Oled display gain/freq button and a
⇒
joggle selector
Extended regulation on Mic input gain: 80dB in 2dB step
⇒
Max input level 26dBu (15.5 V clipping) to connect directly to mixers
⇒
and instruments

General Description

U
"MTP30 is an extremely small and light pocket
transmitters especially designed for professional
wireless microphone applications"
Very easy and quick to use thanks to OLED display and gain/freq
button and an easy joggle selector.
MTP30 benefits also of the latest Wisycom RF technology along with
an enhanced robustness against noise and inter-modulation
(available also with the RF circulator option).
