Izip VIA MEZZA Assembly Manual page 4

Seatpost
11.
Unpack the saddle and seatpost. Open the quick-release lever on
the bicycle's seat tube, then insert the seatpost into the seat tube.
Set the saddle to a comfortable height, then close the seat tube quick
release (photo K), referring to the appendix to this guide on quick release
clamps.
Pedals
12.
Find the pedals in your parts box. Grease the threads
them securely into the crank arms using a 15mm open-end
wrench (Photo L). Note that the pedals have opposite thread directions
and must go on a specific side of the bicycle. The pedal meant for the
drive-side (the side of the bicycle with the chain and gears) has a standard
thread, which is tightened clockwise. The non-drive-side pedal has a
reverse, non-standard thread. It must be turned counter-clockwise to be
screwed in. The pedals are marked 'R' and 'L' for "Right" and "Left."
1-800-377-4532
Currie Technologies
Technical and Customer Service
and thread
F L
13.
Install the front fender using the three bolts already attached to the fork; see diagram
M & photo N. Make sure the fender does not rub against the wheel or interfere with the
front brake.
14.
Adjust your front and rear brakes.
the factory; refer to your owner's manual for detailed instructions on brake adjustment
or consult a professional bike mechanic if you are not comfortable making these
M
adjustments yourself. Do not attempt to ride your bicycle without properly adjusting
the brakes!
Thin Thick
washer
washer
Bicycle
fork bridge
Fender
10mm
bracket
Thin
nut
washer
Fender
Front of bicycle
Fenders
Your brakes may not be fully adjusted from
Bolt
N
Fender bolts
