SOLERA POWER AWNING COMPONENTS
AC
Support Arm
Measurement
Mount Arm
Part # Description
295742 White Support Arm Assembly (Short, 61")
295743 Black Support Arm Assembly (Short, 61")
260294 White Support Arm Assembly (Pitched, 66
266169 Black Support Arm Assembly (Pitched, 66
362132 White Support Arm Assembly (Short Standard Fixed Pitch, 60
362133 Black Support Arm Assembly (Short Standard Fixed Pitch, 60
281152 White Support Arm Assembly (Flat, 69")
281154 Black Support Arm Assembly (Flat, 69")
280343 Gas Strut; 26"; 124 lbs (for Short and Flat Arm Assemblies)
260282 Gas Strut; 124 - 144 lbs (for Pitched Arm Assemblies)
348108 Screw (#14 - 10 x 1
282484 Star Washer (for Gas Strut)
www.lci1.com/support
AWNINGS
Mount
Arm
Assembly
Based on
1/4")
(Arms-to-Coach)
- Phone: (574) 537-8900 - Email:
A AD
A Ae
1/8
")
1/8
")
1/2
1/2
")
Page 12 of 16
