Specification
Board format
Connectors
Power Consumption HLink-Optical
Operating
temperature
Storage
temperature
Relative humidity
Warranty
We are continuously developing the technology used within our product ranges delivering outstanding innovative solutions, therefore the
specification may change from time to time.
HLink-Optical
•
PCI Express x8 plug-in card, 150mm x 70mm (half height and full height
bracket options)
SLink-Optical
•
Half length PICMG 1.3, 168mm x 85mm
HLink-Optical
•
2 x Optical Interface connector (up to PCI Express 8 lane, each optical
connector provides a x4 link)
SLink-Optical
•
2 x Optical Interface connector (up to PCI Express 8 lane)
ExCable-Optical
•
Optical fibre with two integrated Quad (4-channel) Small Form-factor
Pluggable (QSFP) connected modules
•
10 watts
SLink-Optical
•
5 watts (max) chassis ON, 3 watts (max) chassis OFF
0 to 35 deg C / 32 to 96 deg F
-20 to 70 deg C / -4 to 158 deg F
5% to 90% non-condensing
3 years
11
