- Page 1 PLATINUM II ZONE CONTROL SYSTEM INSTALLATION MANUAL...
-
Page 3: Table Of Contents
7. Mounting the Touch Screen 8. Configuring for Multiple Systems 9. Manual System Setup 10. Detect Components 11. Name Zones 12. Zone Set Up 13. Accessing System Set Up 14. Reset Defaults 15. Adding a Zone 16. Warranty 17. Troubleshooting PLATINUM II... -
Page 4: Precautions
PRECAUTIONS 1. Precautions Refer to these installation instructions before commencing the installation or service of this product. WARNING This product should be installed and setup by qualified personnel. To reduce the risk of fire, electric shock or product damage: DO NOT expose to rain or moisture of any kind DO NOT place articles filled with water on or near this appliance DO NOT remove covers –... -
Page 5: Components Supplied
COMPONENTS SUPPLIED 3. Components Supplied Touch Screen Control Box 240V AC Power Cord Low Voltage Coms Cable (15m) 2 x Instruction Manuals 4. Optional Components Secondary Touch Screen with Low Voltage Coms Cable (30m) PLATINUM II... -
Page 6: Mounting The Control Box
MOUNTING THE CONTROL BOX 5. Mounting the Control Box ŸMount the Control Box in the roof space in a location central to all of the Zone Dampers, ideally near a ceiling access panel. ŸMount in a well ventilated area. ŸThe Control Box should be screwed to the roof structure at a level to provide easy access for the connection of wires. -
Page 7: Mounting The Touch Screen
Mounting Plate is completely clear Plug Coms Cable into socket on the back of the Touch Screen, then simply push onto the Mounting Plate so it clips into place Coms Cable Ø25 Mounting Screw Mounting Plate Touch Screen PLATINUM II... -
Page 8: Configuring For Multiple Systems
MULTIPLE SYSTEMS 8. Configuring for Multiple Systems Two Touch Screens can be linked to one Control Box - this is particularly useful for 2-storey building applications. Simply plug the additional Coms cable and Touch Screen into the Control Box. Two Control Boxes can also be linked to create a maximum 16 zone system, using one or two Touch Screens. -
Page 9: Manual System Setup
When the Touch Screen is first powered up, the system will check the installed components during the initialization process. (This will also occur following a power interruption.) Once the initialization process is complete, the System Set Up screen is displayed. 10. Detect Components PLATINUM II... - Page 10 SYSTEM SET UP If the Zone Dampers have been installed correctly, all Zone Damper detections should be indicated with a green light. If there is a problem with a Zone Damper or it cannot be detected, it will be indicated with a red light.
-
Page 11: Name Zones
SYSTEM SET UP 11. Name Zones PLATINUM II... - Page 12 SYSTEM SET UP Alternatively for a custom name: When all Zones have been named, press the 'Esc' icon to exit screen and continue. INSTALLATION MANUAL...
-
Page 13: Zone Set Up
SYSTEM SET UP 12. Zone Set Up It is important to set the diameter of each Zone Damper to ensure the Relief Zones function correctly. To set Relief Zones, press the relevant icon(s) that well serve as Relief Zones. PLATINUM II... - Page 14 SYSTEM SET UP Once all Zones have been configured press the 'Esc' icon to exit screen and continue. If no Relief Zones have been set a warning screen will display. Pressing 'Esc' will return the display to the previous Zone Set Up screen so Relief Zones can be set.
- Page 15 Zone Settings and adding Favourites. 13. Accessing System Set After initial installation, access to System Set Up functionality can be obtained by pressing the icon in the top right corner and will require a 4-digit installer code. PLATINUM II...
-
Page 16: Accessing System Set Up
SYSTEM SET UP Access to System Version and Diagnostic information are also available from this screen. This information may be useful in the event of a service call. INSTALLATION MANUAL... -
Page 17: Reset Defaults
14. Reset Defaults This will remove all user/installer saved information and return the system to its original factory settings. Pressing 'OK' will reinitialize the system then return to the System Setup screen as shown during an initial set up. PLATINUM II... -
Page 18: Adding A Zone
SYSTEM SET UP 15. Adding a Zone To add a Zone to the system, once the new Zone Damper has been installed, access the System Set Up screen and press Detect Components button. Press ‘Recheck’ to prompt the system to search for components. - Page 19 SYSTEM SET UP If the component is detected successfully, a new Zone should appear with the Damper indicated by a green light. Follow the previous procedure for naming the Zone and configuring the size. PLATINUM II...
-
Page 20: Warranty
WARRANTY 16. Warranty Subject to the conditions below, this product is guaranteed against any defects in materials or workmanship under conditions of normal use for a period of 12 months from date of purchase. The benefits conferred by this warranty are in addition to other warranties and remedies that are implied under the Trade Practices Act and similar State and Territory laws. -
Page 21: Troubleshooting
TROUBLESHOOTING 17. Troubleshooting All service to the Platinum II system must be carried out by an approved Air Diffusion Agencies service technician, and must not be done by unqualified personnel. Repairs carried out by unqualified personnel will void warranty. Problem... - Page 22 ZONE RECORD SHEET Zone Room Zone Ø Relief Sensor ID INSTALLATION MANUAL...
