- Page 1 H110T-SI01 Intel Skylake LGA1151 SoC ® USER’S GUIDE...
- Page 2 ® Version:1.0...
- Page 3 Shielded interconnect cables and a shielded AC power cable must be employed with this equipment to ensure compliance with the pertinent RF emission limits govern- ing this device. Changes or modifications not expressly approved by the system’s manufacturer could void the user’s authority to operate the equipment. H110T-SI01 USER MANUAL...
-
Page 4: Declaration Of Conformity
Provides information on us- page 27 ing the BIOS Setup Utility. Using BIOS Chapter 4 Describes the motherboard page 51 software. Using the Motherboard Software Chapter 5 page 55 Provides basic trouble shoot- Trouble Shooting ing tips. H110T-SI01 USER MANUAL... -
Page 5: Table Of Contents
About the Setup Utility...............27 The Standard Configuration...........27 Entering the Setup Utility............27 Resetting the Default CMOS Values........28 Using BIOS..................28 BIOS Navigation Keys..............29 Main Menu................30 Advanced Menu..............31 Chipset Menu................43 Tweak Menu................46 Security Menu.................47 Boot Menu................48 Exit Menu................49 Updating the BIOS................50 H110T-SI01 USER MANUAL... - Page 6 Chapter 4 Using the Motherboard Software Auto-installing under Windows 7/8..........51 ..Running Setup..............51 Manual Installation................53 Chapter 5 Trouble Shooting Start up problems during assembly..........55 Start up problems after prolong use..........56 Maintenance and care tips..............56 Basic Troubleshooting Flowchart...........57 H110T-SI01 USER MANUAL...
-
Page 7: Introducing The Motherboard
Chapter 1 Introducing the Motherboard Introduction Thank you for choosing the H110T-SI01 motherboard. This motherboard is a high performance, enhanced function motherboard designed to support the LGA1151 ® socket for Intel Skylake processor. ® This motherboard is based on Intel H110 Express Chipset for best desktop platform solution. -
Page 8: Specifications
• 1 x LVDS connetor (For All-In-One Specification) • 1 x LVDS brightness switch header (For All-In-One Specifica- tion) • 1 x Debug Card header (LDC) • 1 x LCD panel select jumper (For All-In-One Specification) H110T-SI01 USER MANUAL... - Page 9 - F7 hot key for boot up devices option - Supports PgUp clear CMOS Hotkey (Has PS2 KB Model only) - Add the function of copying BIOS parameters to USB flash drive Form Factor • Thin Mini ITX Size, 170mm x 170mm H110T-SI01 USER MANUAL...
-
Page 10: Motherboard Components
Motherboard Components H110T-SI01 USER MANUAL... - Page 11 SATA power connector 19. LVDS LVDS connector (For All-In-One Specification) 20. DISP_BRT LVDS brightness control header (For All-In-One Specification) 21. LCD_SEL LCD panel select jumper (For All-In-One Specification) 22. USB_CR_CAM 10-pin USB 2.0 header supports card reader and camera H110T-SI01 USER MANUAL...
-
Page 12: I/O Ports
No data Activity LED Orange blinking Active No link Link LED Green Link LAN Port 7. Line-out (lime) It is used to connect to speakers or headphones. 8. Microphone (pink) It is used to connect to a microphone. H110T-SI01 USER MANUAL... -
Page 13: Installing The Motherboard
Place the motherboard over the mounting brack- ets and secure the motherboard onto the mounting brackets with screws. Do not over-tighten the screws as this can stress the motherboard. H110T-SI01 USER MANUAL... -
Page 14: Checking Jumper Settings
1. LCD_SEL: LCD panel select jumper (For All-In-One Specification) 1.When your panel connects to LVDS, please check LCD_SEL header setting first. 2.Due to the differences of the panel parameters, please follow the above illustration to place the jumper caps. H110T-SI01 USER MANUAL... - Page 15 The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled. To avoid the system instability after clearing CMOS, we recommend users to enter the main BIOS setting page to “Load Default Settings” and then “Save and Exit Setup”. H110T-SI01 USER MANUAL...
-
Page 16: Installing Hardware
Lift the tail of the load lever and rotate the load plate to fully open position. Grasp the edge of the package substrate. Make sure pin 1 indicator is on your bottom-left side. Aim at the socket and place the package carefully into the socket by purely vertical motion. H110T-SI01 USER MANUAL... - Page 17 Spreader). Engage the load lever while pressing down lightly onto the load plate. Secure the load lever with the hook under retention tab. Then the cover will flick automatically. Please save and replace the cover onto the CPU socket if processor is re- moved. H110T-SI01 USER MANUAL...
-
Page 18: Installing The Cpu Cooler
B. Fasten the cooling fan supporting base onto the CPU socket on the motherboard. And make sure the CPU fan is plugged to the CPU fan connector. C. Connect the CPU cooler power connector to the CPU_FAN connector. H110T-SI01 USER MANUAL... -
Page 19: Installing Memory Modules
Refer to the following to install the memory modules. Install the DIMM module into the slot and press it firmly down until it fits in place. Check that the cutouts on the DIMM module edge connector match the notches in the DIMM slot. SO-DIMM2 SO-DIMM1 H110T-SI01 USER MANUAL... -
Page 20: Installing Add-On Cards
SATA inter- face. Before installing an add-on card, check the documentation for the card carefully. If the card is not Plug and Play, you may have to manually configure the card before installation. H110T-SI01 USER MANUAL... - Page 21 Demount the screw not used according to the length of your M.2 SSD card. Insert the M.2 SSD card into NGFF slot in the fool-proof way. Lock the screw as the following picture shows to make sure the M.2 SSD card is installed in place. H110T-SI01 USER MANUAL...
-
Page 22: Connecting Optional Devices
SATA1~2 connectors are used to support the Serial ATA 6Gb/s device. Simpler disk drive cabling and easier PC assembly. It eliminates limitations of the current Parallel ATA interface. But maintains register compatibility and software compatibility with Parallel ATA. H110T-SI01 USER MANUAL... - Page 23 2. CIR: Consumer infrared header 3. MON_SW: LVDS brightness switch header (For All-In-One Specification) H110T-SI01 USER MANUAL...
- Page 24 2.Due to the chipset limitation, using dual displays LVDS(AIO) + VGA or LVDS(AIO) + HDMI will cause the problem that you may not enter BIOS setup or have the display problem. 5. DISP_BRT: LVDS brightness control header (For All-In-One Specification) H110T-SI01 USER MANUAL...
- Page 25 6 & 11. USB_CR_CAM (10-pin USB 2.0 header supports card reader and camera or other USB 2.0 devices) & USB_TP (5-pin USB 2.0 header supports one USB 2.0 device) Users please note to install the card to the correct header. H110T-SI01 USER MANUAL...
- Page 26 The front panel audio header allows the user to install auxiliary front-oriented mi- crophone and line-out ports for easier access. This header supports HD audio by default. If you want connect an AC’ 97 front panel audio to HD onboard headers, please set as below picture. H110T-SI01 USER MANUAL...
- Page 27 97 Front Panel, please tick off the option of “ Disabled Front Panel Detect ”. If you use HD Audio Front Panel, please don’ t tick off “Disabled Front Panel Detect ” . * For reference only H110T-SI01 USER MANUAL...
- Page 28 This motherboard implements one USB 3.0 header supporting two extra front USB 3.0 ports, which delivers 5Gb/s transfer rate. To avoid the system instability after clearing CMOS, we recommend users to enter the main BIOS setting page to “Load Default Settings” and then “Save and Exit Setup”. H110T-SI01 USER MANUAL...
-
Page 29: Installing A Hard Disk Drive/Optical Disk Drive
Attach the other end of the combo HDD/ODD cable to the SATA port and SATA_PWR connector on the motherboard. Please note that, connect the black cable to the SATA_PWR connector, and connect the orange cable to the SATA port. * For reference only H110T-SI01 USER MANUAL... -
Page 30: Connecting Case Components
Connect the CPU cooling fan cable to CPU_FAN. Connect the system cooling fan connector to SYS_FAN. Users please note that the fan connector supports the CPU cooling fan of 1.1A ~ 2.2A (26.4W max) at +12V. H110T-SI01 USER MANUAL... - Page 31 50 ms to signal the power supply to switch on or off. The time requirement is due to internal de-bounce circuitry. After receiving a power on/off signal, at least two seconds elapses before the power supply recognizes another on/off signal. H110T-SI01 USER MANUAL...
- Page 32 4. SPKR: 2 Channel audio speaker header (For All-In-One Specification) Connect the case speaker cable to SPKR. 5. SATA_PWR: SATA power connector This concludes Chapter 2. The next chapter covers the BIOS. H110T-SI01 USER MANUAL...
-
Page 33: Using Bios
When you power on the system, BIOS enters the Power-On Self Test (POST) routines. POST is a series of built-in diagnostics performed by the BIOS. After the POST routines are completed, the following message appears: Press DEL to enter SETUP H110T-SI01 USER MANUAL... -
Page 34: Resetting The Default Cmos Values
Other options lead to dialog boxes that prompt you for informa- tion. Some options (marked with an icon ) lead to submenus that enable you to change the values for the option. Use the cursor arrow keys to scroll through the items in the submenu. H110T-SI01 USER MANUAL... -
Page 35: Bios Navigation Keys
Select the default icon and press <Enter> or double click the left key of the mouse to display the screen. Then you can load optimized defaults or not. Advanced Select the advanced icon and press <Enter> or double click the left key of the mouse to display the screen. H110T-SI01 USER MANUAL... -
Page 36: Main Menu
The Date and Time items show the current date and time on the computer. If you are running a Windows OS, these items are automatically updated whenever you make changes to the Windows Date and Time Properties utility. H110T-SI01 USER MANUAL... -
Page 37: Advanced Menu
: Select Screen Super IO Configuration /Click: Select Item Trusted Computing Enter/Dbl Click : Select +/- : Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC/Right Click: Exit H110T-SI01 USER MANUAL... -
Page 38: Lan Configuration
F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save & Exit ESC/Right Click: Exit Onboard LAN Controller (Enabled) Use this item to enable or disable the Onboard LAN. Press <Esc> to return to the Advanced Menu page. H110T-SI01 USER MANUAL... -
Page 39: Pc Health Status
System temperature, CPU & DIMM voltage, CPU & System fan speed... etc. • CPU Temperature (DTS) • System Temperature • CPU Fan Speed • System Fan Speed • Core Voltage • DIMM Voltage • +12V • • +VCC Press <Esc> to return to the Advanced Menu page. H110T-SI01 USER MANUAL... -
Page 40: Power Management Setup
EUP Function (Enabled) This item allows user to enable or disable EUP support. Power LED Type (Dual Color LED) This item shows the type of the power LED. Press <Esc> to return to the Advanced Menu page. H110T-SI01 USER MANUAL... -
Page 41: Acpi Settings
F4: Save & Exit ESC/Right Click: Exit ACPI Sleep State [S3(Suspend to RAM)] This item allows user to enter the ACPI S3 (Suspend to RAM) Sleep State (default). Press <Esc> to return to the Advanced Menu page. H110T-SI01 USER MANUAL... -
Page 42: Cpu Configuration
This item shows the computer not support Intel HT Technology or not. Intel VT-x Technology (Supported) This item shows the computer support Intel VT-x Technology or not. Active Processor Cores (All) Use this item to control the number of active processor cores. H110T-SI01 USER MANUAL... - Page 43 Use this item to enable the CPU energy-saving function when the system is not running. HardWare P states (HWP) (Disabled) Use this item to enable or disable the hardware P states. Press <Esc> to return to the Advanced Menu page. H110T-SI01 USER MANUAL...
-
Page 44: Sata Configuration
Spin Up Device (Disabled) Use this item to enable or disable the spin up device. External SATA (Disabled) Use this item to enable or disable the external SATA. Press <Esc> to return to the Advanced Menu page. H110T-SI01 USER MANUAL... -
Page 45: Usb Configuration
All USB Devices (Enabled) Use this item to enable or disable all USB devices. Legacy USB Support (Enabled) Use this item to enable or disable support for legacy USB devices. Press <Esc> to return to the Advanced Menu page. H110T-SI01 USER MANUAL... -
Page 46: Super Io Configuration
This item shows the information of the device settings. Change Settings (Auto) Use this item to change device settings. Press <Esc> to return to the Super IO Configuration page. Press <Esc> to return to the Advanced Menu page. H110T-SI01 USER MANUAL... -
Page 47: Trusted Computing
TPM 1.2 will restrict support to TPM 1.2 devices, TPM 2.0 will restrict support to TPM 2.0 devices, Auto will support both with default set to TPM 2.0 devices if not found, TPM 1.2 devices will be enumerated. Press <Esc> to return to the Advanced Menu page. H110T-SI01 USER MANUAL... -
Page 48: Chipset Menu
DVMT Memory (256M) When set to Fixed Mode, the graphics driver will reserve a fixed position of the system memory as graphics memory, according to system and graphics requirements. Press <Esc> to return to the Chipset Menu page. H110T-SI01 USER MANUAL... -
Page 49: Chipset Menu
This item enables your computer to automatically restart or return to its operating status. Audio Configuration This item shows the information of the audio configuration. Azalia HD Audio (Enabled) This item enables or disables Azalia HD audio. Press <Esc> to return to the Chipset Menu page. H110T-SI01 USER MANUAL... - Page 50 F4: Save & Exit ESC/Right Click: Exit ME Control (Enabled) Use this item to enable or disable the ME Firmware. ME FW Version (11.0.0.1205) This item shows the ME FW version. Press <Esc> to return to the Chipset Menu page. H110T-SI01 USER MANUAL...
-
Page 51: Tweak Menu
Total Memory (4096 MB) This item shows the total memory. EIST (Enabled) This item allows you to enable or disable the EIST (Enhanced Intel SpeedStep Technology). Turbo Boost (Enabled) This item allows you to enable or disable the Turbo Boost. H110T-SI01 USER MANUAL... -
Page 52: Security Menu
Secure Boot (Enabled) This item is used to control the secure boot flow, it is possible only if system runs in User Mode. Secure Boot Mode (Standard) This item is used to select the secure boot mode. H110T-SI01 USER MANUAL... -
Page 53: Boot Menu
Boot Option #1 /2 /3 /4 /5 /6 /7 Use these items to set the system boot order. UEFI USB Flash Drive Priorities This item enables you to specify the sequence of loading the operating system. Press <Enter> to see the submenu. H110T-SI01 USER MANUAL... -
Page 54: Exit Menu
This item enables you to save the changes that you have made as user defaults. Restore User Defaults This item enables you to restore user defaults to all the setup options. Boot Override Use this item to select the boot device. H110T-SI01 USER MANUAL... -
Page 55: Updating The Bios
BIOS jumper, reset the jumper to protect the newly installed BIOS from being overwritten. The computer will restart automatically. This concludes Chapter 3. Refer to the next chapter for information on the software supplied with the motherboard. H110T-SI01 USER MANUAL... - Page 56 Memo H110T-SI01 USER MANUAL...
-
Page 57: Using The Motherboard Software
Click Setup. The installation program begins: The following screens are examples only. The screens and driver lists will be different according to the motherboard you are installing. The motherboard identification is located in the upper left-hand corner. H110T-SI01 USER MANUAL... - Page 58 Windows 10 will show the following screen after system restart, you must select “Desktop” in the bottom left to install the next driver. H110T-SI01 USER MANUAL...
-
Page 59: Manual Installation
If the driver you want to install does not have a setup program, browse to the operating system subfolder and locate the readme text file (README.TXT or README.DOC) for information on installing the driver or software for your operating system. H110T-SI01 USER MANUAL... - Page 60 Memo H110T-SI01 USER MANUAL...
-
Page 61: Trouble Shooting
CPU heatsink. Check if the CPU fan is working properly while the system is running. 2. From the BIOS setting, try to disable the Smartfan function to let the fan run at default speed. Doing a Load Optimised Default will also disable the Smartfan. H110T-SI01 USER MANUAL... -
Page 62: Start Up Problems After Prolong Use
6. If possible, ensure the power cord has an earth ground pin directly from the wall outlet. This will reduce voltage fluctuation that may damage sensitive devices. H110T-SI01 USER MANUAL... - Page 64 Memo H110T-SI01 USER MANUAL...
