- Page 1 5407366 Issue 1 May 2007 (only for UK Market) ARISTON FREESTANDING LARDER FRIDGES Model Comm. Covered Code Energy Band 'A' Models SD1511 44302 SD1513 44303 SD1711 44308 SD1711V 47201 SD1712V 47203 Energy Band 'A+' Models SD1521 44301 SD1522 47204 SD1721...
-
Page 2: Health & Safety
Indesit Company HEALTH AND SAFETY "(only for UK Market)" For the servicing of refrigeration products, containing Isobutane R600a refrigerant. These instructions are in addition to any other Company procedures already published. Published primarily for Indesit Company engineers working in the UK or Southern Ireland, for which these instructions are MANDATORY. -
Page 3: Thermostat Replacement
Indesit Company HEALTH AND SAFETY "(only for UK Market)" 19. Working with a naked flame i.e. soldering or brazing is forbidden. Unless otherwise stated, pipework connections must only be made using the Lokring coupling system. 20. Electronic leak detectors with high voltage tips must NOT be used with any Isobutane (R600a). 21. -
Page 4: Table Of Contents
Indesit Company CONTENTS Health & Safety ........... . .2 - 3 Index &... -
Page 5: Introduction
Indesit Company MODEL INTRODUCTION The models included in this publication are 1500 and 1700 mm high larder fridges, introduced in March 2007. All models are similar with regard to the furniture design, but there are variations for energy-banding (A and A+), exterior colour and 'V' models that have an air circulation fan. For banding and colour information, refer to the Front Cover and/or Specifications page. -
Page 6: Specifications
Indesit Company SPECIFICATIONS Colours Introduction Date - March 2007 Polar White SD1511 SD1521 SD1711 SD1711V SD1721 SD1746 Argento Vivo SD1513 SD1723 Inox SD1522 SD1712V SD1722J 'V' = Ventilation Fan 'J' = Joining models – SD & UP1722J GENERAL: Manufactured in... - Page 7 Indesit Company TECHNICAL DATA: Power Supply Voltage: 220/240 V Power Supply Frequency: 50 Hz Absorption Current: Normal Operation 0.8 Amps COMPRESSOR WINDING Ω: Manufacturer: ACC/ZEM TECUMSEH Type I/D: HTK55AA-2 THG1340MKS Winding Resistance Ω Start: 30.3 28.4 Run: 31.9 25.9 Refrigerant/ Grams: R600a - Refer to the appliance rating plate ENERGY: Model:...
-
Page 8: Product Description With Image
Indesit Company DESCRIPTION OF APPLIANCE: Control de temperatura Balda extraíble con tapa y huevera Baldas extraíbles multiusos Baldas Balda para botellas Cesta para frutas y verduras Patas de nivelación Service Manual UK English 8 of 15... - Page 9 Indesit Company NOTES Service Manual UK English 9 of 15...
-
Page 10: Door Reversal Instructions
Indesit Company REVERSING THE DOORS (All models except SD1722J) Important Notes for Guidance: Before commencing any work refer to the Safety Notes at the beginning of this manual. Read the instructions on the next page fully and refer to the diagrams below before carrying out the door reversal. - Page 11 Indesit Company REVERSING THE DOORS (All models except SD1722J) Fig 1: Removing the Door and Top Hinge fittings Open the door and ease the hinge cover strip out from above the door seal; starting from the area nearest to the hinge. Also remove the plastic plug button above the hinge pin at the top of the door. Remove the hinge pin, whilst supporting the door.
-
Page 12: J' Models ~ Joining Kit Instructions
Indesit Company JOINING KIT - 'J' MODELS ONLY Freezer Supplied ~ LH door hinging – Fridge Supplied ~ RH door hinging Before attempting to join the two appliances together, it is important to level each appliance separately in the position it will stand. If this is not done properly it will be more difficult to join the appliances together and undue stresses may be introduced into the cabinets over time. - Page 13 Indesit Company JOINING KIT - 'J' MODELS ONLY Remove the base moulding from the fridge and insert the multiple hole 'hinge fixing plate' in the slot behind the lower left hand hinge position. Affix the tapping plate using the screws provided. See image below.
-
Page 14: Wiring Connection Information
Indesit Company WIRING CONNECTION CHART CONTROL HARNESS PLUG CONTROL HARNESS SOCKET Front View Rear View Foamed in Place PLUG & SOCKET Used in “V models only: For other models, see thermostat connections 1 ~ Not used 1 ~ Rear Link to Light only 2 ~ Black ~ Thermostat 3 2 ~ Black ~ Compressor Black ~ Ventilator... -
Page 15: Theoretical Wiring Diagram
Indesit Company THEORETICAL WIRING DIAGRAM ELECTROLUX - (ACC/ZEM) & TECUMSEH COMPRESSORS COMPRESSOR CAPACITOR THERMOSTAT (if fitted) VENTILATOR - ‘V’ MODELS LIGHT LIGHT SWITCH 5407366wd.pdf SD1511-SD1746 Service Manual UK English 15 of 15...
