Summary of Contents for DAPAudio ACX-2
- Page 1 MANUAL ENGLISH ACX-2 Ordercode: D1905 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
ACX-2 Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Connection with the mains............................4 Return Procedure ................................4 Claims ....................................4 Description of the device ..............................5 Overview ..................................5 Frontside..................................6 Backside ..................................7 Installation ................................... -
Page 3: Warning
Save the carton and all packing materials. In the event that a device must be returned to the factory, it is important that the device is returned in the original factory box and packing. Your shipment includes: • DAP Audio ACX-2 • 1,5m IEC Powercable •... -
Page 4: Operating Determinations
ACX-2 Do not insert objects into air vents. Do not switch the system on and off in short intervals, as this would reduce the system’s life. Do not open the device and do not modify the device. -
Page 5: Connection With The Mains
ACX-2 Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER PHASE BLUE BLACK... -
Page 6: Description Of The Device
Description of the device Features The DAP ACX-2 is a stereo 2-way or mono 3-way active crossover. The standard 19" rugged rack mountable housing and high quality finish, good selection of high end components and great sound characteristics results in a road proof active crossover. -
Page 7: Frontside
ACX-2 Frontside Fig. 02 Power switch ON/OFF Press the button to switch the device ON/OFF. Mute button High gain (Channel 1 / 2) This button will mute the High frequency band. If you mute the High frequency band, you will only hear the Low frequency band. -
Page 8: Backside
ACX-2 Backside Fig. 03 Channel 1 input ( jack 6,3 mm) Balanced input jack 6,3 mm for the mixer in stereo mode (Channel 1). In the mono mode this is an input jack 6,3 mm mono for the mixer. Channel 1 input (XLR) Balanced input XLR for the mixer in stereo mode (Channel 1). -
Page 9: Installation
Connect the device to the appropriate power supply. Installation Remove all packing materials from the ACX-2. Check if all foam and plastic padding is removed. Secure the equipment into a 19" rack if preferred. Connect all cables. Always disconnect from electric mains power supply before cleaning or servicing. -
Page 10: Connection Modes
Stereo connection example Fig. 04 Note: Switch the ACX-2 in the stereo mode as indicated in the figure above. Link all the cables before connecting electric power. First plug the ACX-2 into a proper electric power supply, then the amplifiers. -
Page 11: Mono Connection Example
Mono connection example Fig. 05 Note: Switch the ACX-2 in the mono mode as indicated in the figure above. Link all the cables before connecting electric power. First plug the ACX-2 into a proper electric power supply, then the amplifiers. -
Page 12: Connection Cables
ACX-2 Connection Cables Take care of your cables, always holding them by the connectors and avoiding knots and twists when coiling them: This gives the advantage of increasing their life and reliability. Periodically check your cables. A great number of problems (faulty contacts, ground hum, discharges, etc.) are caused entirely by using unsuitable or faulty cables. -
Page 13: Maintenance
ACX-2 Maintenance The DAP ACX-2 requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Do not use alcohol or solvents. -
Page 14: Product Specifications
ACX-2 Product Specifications Model: DAP Audio ACX-2 Power supply: 230V AC, 50 Hz Power connection: IEC power connector Rated power consumption: 8,5W Fuse: T100 mAL/250V Dimensions: 483 x 192 x 44 mm (LxWxH) 19” x 1HE (LxH) Weight: 2,66 kg Inputs &... -
Page 15: Dimensions
ACX-2 Dimensions Ordercode: D1905... - Page 16 ©2016 DAP Audio...
