- Page 1 SERVICE MANUAL SERVICE MANUAL Vertical axis Washing Machine Model: LSA 1300 Caution :In this Manual, some parts/technical specification can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to Spare parts list in service information.
- Page 2 SERVICE MANUAL INTEX VERTICAL AXIS WASHING MACHINE SERVICE MANUAL 1. TOP LOAD WASHING MACHINE…………………………………03 2. WASHER SPECIFICATION……………………………………………04 3. PARTS LIST BY ASS’Y…………………………………………………..05 4. CONTROLS PART FUNCTION SPECIFICATION………………24 5. PROGRAM Vs TIME CHART…......……………29 6. SEQUENCE CHART………………………………………………………30 7. WIRING DIAGRAM………………………………………………………32 Page | 2...
- Page 3 The new iconic 'S' pattern design in the drum makes sure that the clothes are handled with gentle care while enhancing soil removal for a better wash. True care for your clothes. *Applicable only for the Model: LSA 1300. Page | 3...
- Page 4 SERVICE MANUAL PRODUCT SPECIFICATION Model LSA 1300 Dimension (mm) 620 X 670 X1090 Maximum Mass Of Textile(kg) 13 Kg Dry Linen Machine Weight(kg) 44.2 Power supply 220V AC, 60Hz Spin Speed(RPM) 720-740 Operating Water Pressure 0.2 to 8 bar Page | 4...
- Page 5 SERVICE MANUAL FULL MACHINE ASSEMBLY Page | 5...
- Page 6 FULL MACHINE ASSEMBLY SERVICE MANUAL Sl. No Description CABINET TOP AND LID WASH UNIT DRIVE SYSTEM CABINET-ENCLOSURE HYDRAULIC INLET SYSTEM UI-CONTROLS HYDRAULIC SYSTEM OUTLET Page | 6...
- Page 7 SERVICE MANUAL CABINET ASSEMBLY BRIDGE PLATE GUSSET Page | 7...
- Page 8 SERVICE MANUAL CABINET ASSEMBLY Sl. No Part No Description W10623606 FRONT STIFFNER, G62 W10564603 DAMPER PAD EPE WITH ADHESIVE,G62 W10617104 CABINET & BRIDGE PLATE ASM-GRAPHITE,G62 W10499964 CABINET & BRIDGE PLATE ASM-WHITE,G62 W10564582 UNDERBASE-CHARCOAL GREY,G62 W10625389 UNDERBASE-WHITE, G62 W10626453 REAR SPLIT FRAME, G62 P01882114 DAMPER PAD - EPE WITH ADHESIVE W10499895...
- Page 9 SERVICE MANUAL TOP AND LID ASSEMBLY Page | 9...
- Page 10 SERVICE MANUAL TOP AND LID ASSEMBLY Sl. No Part No Description W10481494 MV-ENCLOSURE LID,G62 P01881021 PLUG LEFT - VARI P01881022 PLUG RIGHT - VARI W10503683 TOP FRAME - VARI P01886028 HINGE PIN - VARI S01132015 SCREW ST 4.2 X 13-C P01883006 BRACKET LID SWITCH 24"...
- Page 11 SERVICE MANUAL WASH UNIT WRAPPER-SS-BASKET,G62 BALANCE RING BASE LOWER-BASKET,G62 WIRE ROUTING CLAMP - 24 INCH Sl. No Part No Description W10564583 BASKET ASSY WITH LINT FILTER,G62 W10482284 MVA-SUSPENSION ASSEMBLY,G62 W10462155 WASH UNIT TUB ASM,G62 Page | 11...
- Page 12 SERVICE MANUAL BASKET ASSEMBLY WITH LINT FILTER BASKET ASSY WITH LINT FILTER, G62 Sl. No Part No Description W10564589 SCREW -HEX HEAD & INTG WASHER 6 X 24 W10402178 RETAINER - DRIVEBLOCK W10482299 DRIVEBLOCK MACHINED-BASKET,G62 Page | 12...
- Page 13 SERVICE MANUAL PUMPING TOWER AND LINT FILTER ASSEMBLY Sl. No Part No Description W10564606 TOP-PUMPING TOWER-LF-GLOBAL WHITE,G62 W10564590 PUMPING TOWER-BASKET,G62 W10492527 LINT FILTER ASSY-CHARCOAL GREY,G62 S01132094 SCREW ST 3.5x10-F,SPAN;SS-PHILIPS-BT-CUT W10402061 COUNTERSUNK SCREW W10564601 SPONGE SEAL-PUMPING TOWER,G62 Page | 13...
- Page 14 AGITATOR ASSEMBLY SERVICE MANUAL Sl. No Part No Description W10679590 CAP-AGITATOR-DARK GREY,G62 W10679585 SOFTENER CUP-DARK GREY,G62 S01132096 SCREW ST 4.2x13-F,PHILIPS STEEL W10679588 SOFTENER BASE-DARK GREY,G62 W10481370 SCREW - M6x33 - SS W10646687 AGITATOR,WHITE,G62 Page | 14...
- Page 15 TUB ASSEMBLY SERVICE MANUAL Sl. No Part No Description W10675216 TUB RING-GLOBAL WHITE,G62 BALL UPPER SUSPENSION 24 INCH P018807010A S0113206300 SCREW-ST3.5X10-F,SPAN; STAINLESS STEE W10499930 FILTER PUMP-DRAIN,G62 Page | 15...
- Page 16 SERVICE MANUAL DRIVE ASSEMBLY Page | 16...
- Page 17 DRIVE ASSEMBLY SERVICE MANUAL S.NO Part No Description w10678783 TUB SUPPORT ASSY 24",G62 W10678379 SELF TAPPING SCREW ST 6.3x36-F-ASSY,G62 w10564588 BRAKE BAND & ARM ASM,G62 S01132010 SCREW - ST 3.5 X 14.0 - F W10499921 CAPACITOR BRACKET,G62 W10488531 15 uF Capacitor (P0) with 130uH W10508762 DRAIN MOTOR ASSEMBLY w10678780...
- Page 18 CONTROLS AND UI CONSOLE ASSEMBLY SERVICE MANUAL PRESSURE SENSOR TUBE Page | 18...
- Page 19 CONTROLS AND UI CONSOLE ASSEMBLY SERVICE MANUAL Sl. No Part No Description W10633409 PRESSURE SENSOR - SAPPHIRE G62 IND/SEA W10481486 MV-UI CONSOLE,G62 W10617108 UI ASSY-SAPPHIRE G62 - PHILLIPINNES W10556540 HARNESS LEFT-IND A,B/SEA/AUS A,B S01132010 SCREW - ST 3.5 X 14.0 - F W10553136 HARNESS RIGHT- PHL W10553138...
- Page 20 SERVICE MANUAL HYDRAULIC SYSTEM - INLET ASSEMBLY Page | 20...
- Page 21 HYDRAULIC SYSTEM - INLET SERVICE MANUAL ASSEMBLY Sl. No Part No Description S01132010 SCREW - ST 3.5 X 14.0 - F W10524448 BRACKET-INLET VALVE W10585801 Water valve single outlet Assm Export W1067909 HOUSING DISPENSER ASM,G62 W10402061 COUNTERSUNK SCREW W10564586 COVER-SPRAY DISPENSER-GRAPHITE,G62 Page | 21...
- Page 22 SERVICE MANUAL HYDRALIC SYSTEM – OUTLET Page | 22...
- Page 23 SERVICE MANUAL HYDRALIC SYSTEM – OUTLET Sl. No Part No Description W10496763 OVERFLOW HOSE, G-62 P01159008 DRAIN BEND - EXPORT P011000010B DRAIN HOSE HOLDER,G62 W10514458 DRAIN HOSE,EXT,G62 W10492553 THROUGH CAB CONNECTOR,G62 W10496763 OVERFLOW HOSE, G-62 W10499941 CLAMP DIA.33 CLOSED ENDS W10492546 HOSE ASSY-TUB TO DUMP VALVE,G62 W10482244...
- Page 24 CONTROL COMPONENTS AND SPECIFICATION SERVICE MANUAL S.no COMPONENT NAME PART NUMBER COMPONENT SPECIFICATION Nominal voltage : 220/230V AC INLET Single In Single W10530891 Nominal frequency : 50/60 Hz VALVE Nominal current : 0.02A Nominal power : 7w Nominal Voltage : 5±0.5 V DC PRESSURE SENSOR W10633409 Output Freq : 25.80 - 21 KHz...
- Page 25 CONTROL COMPONENTS AND SPECIFICATION AND SPECIFICATION SERVICE MANUAL RID#1 Main Function RID#1 .1 LOAD SENSING Load Sensing Animation Load Sensing Animation 1) Decides the Required W Required Water level with respect to the Mass of Cloth Load to the Mass of Cloth Load a) Evaluates Evaluates the water level with dry laundry at the of wash wash process...
- Page 26 SERVICE MANUAL CONTROL COMPONENTS AND SPECIFICATION AND SPECIFICATION RID#1 .5 EXTRA RINSE 1) Extra Rinse selection will be Extra Rinse selection will be improving the Rinseability performance whenever the improving the Rinseability performance whenever the laundry requires 2) 2X/3X selection will result in 2 selection will result in 2 / 3 Rinse Phases of a selected cycle cycle RID#1 .6 SUPERSOAK...
- Page 27 SERVICE MANUAL CONTROL COMPONENTS AND SPECIFICATION AND SPECIFICATION b) Ensure that Ensure that Torque Motor is turning ON during drain process and if not check is turning ON during drain process and if not check for Torque Motor Torque Motor operation & its connections from PCB to drain pump. operation &...
- Page 28 CONTROL COMPONENTS AND SPECIFICATION AND SPECIFICATION SERVICE MANUAL b) 2 & 3 detection, system waits for consumer intervention to open the Lid detection, system waits for consumer intervention to open the Lid detection, system waits for consumer intervention to open the Lid distribute the cloths and then to press start key distribute the cloths and then to press start key c) 4...
- Page 29 PROGRAM Vs TIME CHART SERVICE MANUAL Times in Mins PROGRAMS WATER LEVEL Super Soak 2X Extra Rinse 3X Extra Rinse 2X-ExtraRinse/Super soak 3X-ExtraRinse/Super soak P1 - Daily Wash P2 - Quick Wash P3 - Delicates P4 - Easy Iron P5 - Wool P6 - Bed Linen P7 - Stain Wash P8 - Colors...
- Page 30 SEQUENCE CHART SERVICE MANUAL SAPPHIRE -G62, PHILIPPINES - AGITATOR MODEL. TIMING CHART Program Water level Load sensing Wash duration Rinse duration Spin duration Total cycle time Total cycle time & Fill duration (including inbuilt (In minutes) (In minutes) (In minutes) With Super Soak (In minutes) soak) -In minutes...
- Page 31 SERVICE MANUAL LSA1300 - AGITATOR PROGRAM - FEATURE MATRIX PROGRAM REMARKS Tap Cold(Default) Water level - Auto sense Daily Wash Tap Cold (Default)v Water level - Low water level (Default) Quick Wash Cold + (Default) Water level - Delicate High water level (Default) Tap Cold (Default) Water level - Auto sense Easy Iron for Low &...
- Page 32 SERVICE MANUAL WIRING DIAGRAM Page | 32...
