Summary of Contents for Airwell KN-24SH
- Page 1 OWNER'S MANUAL INSTALLATION MANUAL AIR CONDITIONER Please read this owner's manual carefully before using the air conditioner and reserve this manual in case of further reference. K INST. MENU...
-
Page 2: Table Of Contents
CONTENTS INSTALLATION...................... 1 REQUIREMENT FOR ELECTRIC SAFETY............2 PARTS NAMES AND THEIR FUNCTION............OPERATION ATTENTION..................4 TEMPORARY OPERATIONS................5 ADJUSTING AIR FLOW DIRECTION..............5 HINTS FOR ECONOMICAL OPERATION............. 6 MAINTENANCE..................... 6 PHENOMENA NOT CONCERNING MALFUNCTIONS........TROUBLES AND CAUSES (concerning the unit)..........9 TROUBLES AND CAUSES (concerning the remote control))........ -
Page 3: Installation
POWER LOCATION INSTALLATION K INST. MENU... - Page 4 CAUTION K INST. MENU...
- Page 5 KN-27SH power supply indicator operation lamp timer indicator heat indicator K INST. MENU...
- Page 6 only cooling model (without heating operation) NOTICE! K INST. MENU...
-
Page 7: Temporary Operations
TEMPORARY OPERATIONS are exhausted.two modes including mandatory HEAT and mandatory COOL can be selected through the TEMPORARY BUTTON on the air inlet grill control box of the indoor unit Once you push this button,the air conditioner will run in such order mandatory HEAT mandatory COOL,OFF,and back to mandatory HEAT. -
Page 8: Hints For Economical Operation
HINTS FOR ECONOMICAL OPERATION MAINTENANCE CAUTION METHOD FOR CLEANING AIR FILTER K INST. MENU... - Page 9 MAINTENANCE CLEANING THE AIR OUTLET AND THE PANEL CAUTIONS THE MAINTENANCE OF THE OUTDOOR UNIT IF YOU DO NOT PLAN TO USE THE UNIT FOR A LONG TIME MAINTENANCE K INST. MENU...
-
Page 10: Phenomena Not Concerning Malfunctions
RESTART AFTER A LONG TIME PHENOMENA NOT CONCERNING MALFUNCTIONS Fox each Mode including Power OFF and SB,a Min time delay of 3min before Comp.restarting, excluding Deicing Mode. K INST. MENU... - Page 11 K INST. MENU...
-
Page 12: Preparation
PREPARATION K INST. MENU... - Page 13 INSTALLATION MANUAL F o r c o r r e c t i n s t a l l a t i o n , r e a d t h i s m a n u a l b e f o r e s t a r t i n g i n s t a l l a t i o n . This manual may be subject to change without notice for purpose of improvement.
- Page 14 CONTENTS PAGE 1. PRECAUTIONS...................1 2. INSTALLATION INFORMATION............2 3. ATTACHED FITTINGS.................3 4. INSTALLATION PLACE...............4 5. INDOOR UNIT INSTALLATION............5 6. OUTDOOR UNIT INSTALLATION............8 7. INSTALL THE CONNECTING PIPE............9 8. CONNECT THE DRAIN PIPE............13 9. WIRING....................15 10. TEST OPERATION................19 K INST. MENU...
-
Page 15: Precautions
PRECAUTIONS PRECAUTIONS SAFETY CONSIDERATIONS Installation and servicing of air conditioning equipment can be hazardous due to system pressure and electric components. Only trained and qualified service personnel should install, repair or service air conditioning equipment. All other operations should be performed by trained service personnel. When working on air conditioning equipment, observe precautions in the literature, tags and labels attached to the unit and other safety precautions that may apply. -
Page 16: Installation Information
NOTE NOTE R emark per E MC Direc tive 89/336/E E C T o prevent flic ker impres s ions during the s tart of the c ompres s or (tec hnic al proc es s ), following ins tallation c onditions do apply. The power connection for the air conditioner has to be done at the main power distribution. -
Page 17: Attached Fittings
ATTACHED FITTINGS Please check whether the following fittings are of full scope. If there are s ome attached fitting free from use, please restore them c arefully. Drainpipe F ittings In sta lla tio n F ittin g s 1. Expansible hook 5. -
Page 18: Installation Place
INSTALLATION PLACE INSTALLATION PLACE CAUTIONS CAUTIONS Location in the following places may cause malfunction of the machine. (If unavoidable, please consult your local dealer) a. There is petrolatum existing. b. There is salty air surrounding (near the coast). c. There is caustic gas (the sulfide, for example) existing in the air (near a hot spring). d. -
Page 19: Indoor Unit Installation
INDOOR UNIT INSTALLATION 1. Install the main body A. The existing ceiling (to be horizontal) Please cut a quadrangular hole of 880X880mm in the ceiling according to the shape of the installation paper board.(Refer to Chart3,4) The center of the hole should be at the same position of that of the air conditioner body. Determine the lengths and outlets of the connecting pipe, drainpipe and cables. - Page 20 Note: 27 Series B=240mm 30/45 Series B=310mm Hook Body Central hole Body Ceiling 880mm panel Chart 4 Installation paper board Body M6X12 Body Chart 7 Ceiling Chart 5 Chart 6 B. New built houses and ceilings In the case of new built house, the hook can be embedded in advance (refer to the A. B mentioned above ). But it should be strong enough to bear the indoor unit and will not become loose because of concrete shrinking.
- Page 21 (3) Install the panel Align the swing motor on the panel to the tubing joints of the body properly. (Refer to chart11) Fix hooks of the panel at swing motor and its opposite sides to the hooks of corresponding water receiver. (Refer to chart 11 ) Then hang the other two panel hooks onto corresponding hangers of the body.
-
Page 22: Outdoor Unit Installation
OUTDOOR UNIT INSTALLATION CAUTIONS CAUTIONS Keep this unit away from direct radiation of the sun or other heaters. If unavoidable, please cover it with a shelter. In places hear coast or with a high attitude where the wind is violent, please install the outdoor unit against the wall to ensure normal performance. -
Page 23: Install The Connecting Pipe
INSTALL THE CONNECTING PIPE CAUTIONS CAUTIONS Check whether the height drop between the indoor unit and outdoor unit, the length of refrigerant pipe, and the number of the bends meet the following requirements: The max height drop ........................20m (If the height drop is more than 10m, you had better put the outdoor unit over above the indoor unit.) The length of refrigerant pipe ..................less than 30m The number of bends ......................less than 15 CAUTIONS... - Page 24 Use the market brass pipe Be sure to use the same insulating materials when you buy the brass pipe. 2. Locate The Pipes Drill a hole in the wall (suitable just for the size of the wall conduit, 50, 53, 71 series diameter is M90mm, and 120 series diameter is M105mm in general), then set on the fittings such as the wall conduit and its cover.
- Page 25 EXPEL THE AIR EXPEL THE AIR Select the measure of expelling the air by the following table The length of the connecting pipe (one way) The measure of expelling the air Use the refrigerant in the outdoor unit Less than 8m Use Vacuum Pump or refrigerant container 8-15m If you want to move the air conditioner to another place, be sure to use a vacuum pump or refrigerant container...
- Page 26 Disassemble the charge hose from the repair-mouth of stop value A, and fasten the unit. Manifold value Multi-meter Pressure meter Outdoor -76cmHg Indoor unit Gas-side Hi-lever Unit M16mm Lo-lever Charge hose Charge hose M9.53mm Vacuum pump Liquid side Pipe joint Trap Lo-lever Chart 25...
-
Page 27: Connect The Drain Pipe
INSULATION INSULATION Be sure to with insulating materials cover all the exposed parts of the flare pipe joints and refrigerant pipe on the liquid-side and the gas-side. Ensure that there is no gap between them. Incomplete insulation may cause water condensation. CONNECT THE DRAIN PIPE 1. - Page 28 2. Drainage test Check whether the drainpipe is unhindered New built house should have this test done before paving the ceiling. (Refer to Chart 32) Pump joint Test cover Test mouth Body Stow tube Water-receiver Drain plug Chart 32 2)Turn on the power and operate the air conditioner under COOLING mode. Listen to the sound of the drain pump.check whether the water is dis charged well (a long of 1 min is according to the length of the drain pipe), and check whether...
-
Page 29: Wiring
WIRING WIR ING CAUTION C A UT ION The air conditioner should use separate power supply with rated voltage. The external power supply to the air conditioner should have ground wiring, which is linked to the ground wiring of the indoor and outdoor unit. The wiring work should be done by qualified persons according to circuit drawing. - Page 30 INDOOR 3-CORE Cable 3X1.5mm2 5-CORE Cable YZW-300/500 5X1.5mm2 5-CORE Cable RW-300/500 5X1.5mm2 Power:380V～50HZ Note:The cooling only type withoout the link listed by broken line KN-30/36/45 AIR CONDINTIONER LINK CIRCUIT Chart 35 K INST. MENU...
- Page 31 INDOOR 3-CORE Cable 3X1.5mm2 3-CORE Cable YZW-300/500 3X1.5mm2 5-CORE Cable RW-300/500 5X1.5mm2 Power:380V～50HZ Note:The cooling only type withoout the link listed by broken line KN-27/30 AIR CONDINTIONER LINK CIRCUIT Chart 36 K INST. MENU...
- Page 32 INDOOR 3-CORE Cable 3X2.5mm2 Power 220-240V~50HZ 5-CORE Cable 5X2.5mm2 Note:The cooling only type withoout the link listed by broken line KN-24/27 AIR CONDINTIONER LINK CIRCUIT Chart 37 K INST. MENU...
-
Page 33: Test Operation
TEST OPERATION The test operation must be carried out after the entire installation has been completed. Please confirm the following points before the test operation. The indoor unit and outdoor unit are installed properly. Tubing and wiring are correctly completed. The refrigerant pipe system is leakage-checked. - Page 34 K INST. MENU...
- Page 35 FAX: (09) 820 0332 517A Rosebank Road Avondale, Auckland NZ NZ Tech Support Freecall TEL: 0800 180 094 www.airwell.com.au WITH A CONCERN FOR A CONSTANT IMPROVEMENT, OUR PRODUCTS CAN BE MODIFIED WITHOUT NOTICE. PHOTOS NON CONTRACTUAL. © Copyright 2003 K INST. MENU...
