Minuteman 957732 User Manual

AC Input:
DC Output:
Battery Type:
PLEASE SAVE THESE IMPORTANT SAFETY AND OPERATING INSTRUCTIONS
For correct operation of the equipment, it is important to read and be familiar
with this entire manual before installing and operating the charger.
LOOK FOR THIS SYMBOL TO POINT OUT SAFETY PRECAUTIONS.
BECOME ALERT—YOUR SAFETY IS INVOLVED. IF YOU DO NOT FOLLOW THESE
SAFETY INSTRUCTIONS, INJURY OR PROPERTY DAMAGE CAN OCCUR.
IMPORTANT SAFETY INSTRUCTIONS
1. SAVE THESE INSTRUCTIONS - This manual
contains important
instructions for battery charger Model 957732.
2. Before using battery
instructions and cautionary markings on battery
charger, battery, and product using battery.
CAUTION: TO REDUCE RISK OF INJURY,
CHARGE ONLY LIQUID ELECTROLYTE (WET)
LEAD ACID RECHARGEABLE
OTHER TYPES OF BATTERIES MAY BURST
CAUSING PERSONAL INJURY AND DAMAGE.
3. Do not expose charger to rain or snow.
4. Use of an attachment not recommended or sold
by the battery charger manufacturer may result
in a risk of fire, electric shock, or injury to
persons.
5. To reduce risk of damage to electric plug and
cord, pull by plug rather than cord when
disconnecting charger.
Operating Instructions
24 VOLT AUTOMATIC
BATTERY CHARGER
PART NO. 957732
230 volts, 50 hertz, 3.5 amps, single-phase
24 volts, 20 amps initially tapering to 6 amps
24 volt, 12 cell, 168 to 275 amp-hour, liquid electrolyte (wet) lead-acid batteries
DO NOT DISCARD THIS MANUAL AFTER READING.
safety and operating
charger, read
BATTERIES.
Specifications
6. Make sure cord is located so that it will not be
stepped on, tripped over, or otherwise subjected
to damage or stress.
7. An extension cord should not be used unless
absolutely
all
extension cord could result in a risk of fire and
electric shock. If extension cord must be used,
make sure:
a. Pins on plug of extension cord are the same
number, size, and shape as those of plug on
charger;
b. Extension cord is properly wired and in good
electrical condition;
c. Wire size is large enough for AC ampere
rating of charger.
8. Do not operate charger with damaged cord or
plug; replace it immediately.
9. Do not operate charger if it has received a sharp
blow, been dropped, or otherwise damaged in
any way; take it to a qualified service center.
10. Do not disassemble charger; take it to a
qualified service center when service or repair is
1
®
IT MEANS:
necessary. Use of improper
01367F
