Minuteman 957740 Manual

AC Input:
DC Output:
Connections:
PLEASE SAVE THESE IMPORTANT SAFETY AND OPERATING INSTRUCTIONS
For correct operation of the equipment, it is important to read and be familiar
with this entire manual before installing and operating the charger.
LOOK FOR THIS SYMBOL TO POINT OUT SAFETY PRECAUTIONS. IT MEANS:
BECOME ALERT—YOUR SAFETY IS INVOLVED. IF YOU DO NOT FOLLOW THESE
SAFETY INSTRUCTIONS, INJURY OR PROPERTY DAMAGE CAN OCCUR.
• Patented electronic timer monitors battery state of charge while charging and automatically turns charger off as battery
reaches full charge
• Compensates automatically for AC input line voltage variation by high reliability ferroresonant transformer design. Supply
voltage variation + 10% from nominal, + 1% maximum battery charger voltage variation, decreasing to + ½% at finish rate
with constant electrolyte temperature. No taps or rate controls to set.
• Automatic decrease of charge rate for superior battery life through good equalization of cells and low water use rate.
• Silicon diodes with inherent surge protection operated at a conservation percentage of their rating.
• Convection-cooled design for maximum reliability and minimum maintenance.
INTRODUCTION
This automatic battery charger is designed to
recharge deep-cycle,
ferroresonant transformer is used to provide a highly
reliable, line compensating unit with a minimum of
moving parts, designed for long, trouble-free service.
A patented electronic timer turns the charger on and
off automatically. This electronic timer determines
full charge of the batteries by measuring the rate at
which the battery voltage increases during charge.
When the voltage stops rising, the battery is full
charged and the charger turns off.
www.minutemanintl.com
36 VOLT AUTOMATIC
BATTERY CHARGER
PART NO. 957740
108-128 Volts AC, 15 Amp, 60 Hertz, single-phase
36 Volts DC, 36 Amp
6- or 9-ft. AC input cord with NEMA 5-15 grounded plug
8½- or 10-ft. DC output cord with polarized connector
DO NOT DISCARD THIS MANUAL AFTER READING.
lead-acid batteries.
Specifications
Features
INITIAL INSTALLATION
The AC line to which the charger is to be connected
A
must be capable of supply 15 amperes to this
charger.
CAUTION:
PROVIDED WITH A MAXIMUM OF 20 AMP
(15 AMP
PROTECTION IN ACCORDANCE WITH THE
NATIONAL ELECTRICAL CODE ANSI/NFPA 70
AND ALL LOCAL CODES AND ORDINANCES.
IMPROPER CIRCUIT PROTECTION MAY RESULT
IN A FIRE.
1

Š
USE ONLY
IN CANADA) BRANCH
ON CIRCUITS
CIRCUIT
31218C
