GRUNDFOS PRODUCT GUIDE
S pumps, range 58
34 to 42 hp
60 Hz ANSI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 97632133 and is the answer not in the manual?

Questions and answers

Related Manuals for Grundfos 97632133

Summary of Contents for Grundfos 97632133

  • Page 1 S_Range_58-60Hz.book Page 1 Thursday, July 8, 2010 2:30 PM GRUNDFOS PRODUCT GUIDE S pumps, range 58 34 to 42 hp 60 Hz ANSI...

  • Page 2: Table Of Contents

    S_Range_58-60Hz.book Page 2 Thursday, July 8, 2010 2:30 PM Contents Introduction Performance curves Technical data Introduction Applications S 58 extra-low pressure, 6-pole Main constructional features S 58 low pressure, 4-pole S 58 low pressure, 4-pole Performance range S 58 medium pressure, 4-pole S 58 high pressure, 4-pole Performance range, S pumps Performance range, S pumps, range 58...

  • Page 3: Introduction

    S pumps, range 58 Introduction The pumps are available for: • submerged installation on auto-coupling system This product guide deals with Grundfos heavy-duty sewage pumps called S pumps, range 58. • submerged installation, free-standing • dry-pit installation, vertical This product guide was printed in July 2010. A newer version might be available from Grundfos WebCAPS.

  • Page 4: Main Constructional Features

    S_Range_58-60Hz.book Page 4 Thursday, July 8, 2010 2:30 PM Introduction S pumps, range 58 Main constructional features • leak-proof connections via the Grundfos SmartSeal gasket system • double mechanical shaft seal system for reliable sealing between pumped liquid and motor •...

  • Page 5: Performance Range

    S_Range_58-60Hz.book Page 5 Thursday, July 8, 2010 2:30 PM Performance range S pumps, range 58 Performance range, S pumps [ m ] [ f t ] 6 0 H z 3 0 0 2 0 0 1 5 0 1 0 0 1 0 1 0 1 0 0 1 5 0 2 0 0...

  • Page 6: Identification

    .A50 .420 4 .58H .307 .G .N Pump type: Grundfos sewage and wastewater pump Multi-channel impeller pump installed in a column pipe Impeller type: Single-channel impeller SuperVortex (free-flow) impeller Pump passage: Maximum solids size = Code number from type designation/10 [inch]...

  • Page 7: Pump Nameplate

    S_Range_58-60Hz.book Page 7 Thursday, July 8, 2010 2:30 PM Identification S pumps, range 58 Pump nameplate FM approval plate Fig. 3 Ex approval plate Fig. 2 Pump nameplate The approval plate gives the following details: Pos. Description Type designation FM symbol SAP code Equipment group (II = non-mining) Serial number...

  • Page 8: Selection Of Product

    Controller The following controllers are available: Pump Product no Grundfos Dedicated Controls (DC). S1.30.A50.420.4.58H.C.307.G.N.D 97632138 • Pump as specified in the type key • 50 ft (15 m) cable • Paint: Graphic grey, NCS S8005-R80B, thickness 150 μ...

  • Page 9: Product Range

    Standard range Accessories To be ordered separately Pump type Pump *** Horizontal base Vertical base ** Auto-coupling * Ring stand for stand stand system portable use S1.30.A50.340.4.58H.S.290.G.N.D 97632133 97626242 96856262 S1.30.A50.340.4.58H.C.290.G.N.D 97632134 97626242 96856262 S1.30.A50.340.4.58H.D.290.G.N.D 97632135 96308238 S1.30.A50.340.4.58H.H.290.G.N.D 97632136 96782930 S1.30.A50.420.4.58H.S.307.G.N.D...
  • Page 10 S_Range_58-60Hz.book Page 10 Thursday, July 8, 2010 2:30 PM Product range S pumps, range 58 Standart range with stainless steel impeller Accessories To be ordered separately Pump type Pump *** Horizontal base Vertical base ** Auto-coupling * Ring stand for stand stand system...

  • Page 11: Explosion-Proof Range

    S_Range_58-60Hz.book Page 11 Thursday, July 8, 2010 2:30 PM Product range S pumps, range 58 Explosion-proof range Accessories To be ordered separately Pump type Pump *** Horizontal base Vertical base ** Auto-coupling * Ring stand for stand stand system portable use S1.30.A50.340.4.58H.S.290.G.Ex.D 97660672 97626242...

  • Page 12: Explosion Proof Range With Stainless Steel Impeller

    S_Range_58-60Hz.book Page 12 Thursday, July 8, 2010 2:30 PM Product range S pumps, range 58 Explosion proof range with stainless steel impeller Accessories To be ordered separately Pump type Pump *** Horizontal base Vertical base ** Auto-coupling * Ring stand for stand stand system...

  • Page 13: Variants

    ISO 9906 grade 1 tolerances Different test standard Efficiency guaranteed by Grundfos ISO 9906 grade 2 tolerances Vibration test (incl. report) According to Grundfos factory quality standard Performance test on dry test stand Not yet available NPSHr test Not yet available...

  • Page 14: Construction

    S_Range_58-60Hz.book Page 14 Thursday, July 8, 2010 2:30 PM Construction S pumps, range 58 Sectional drawings, motors Fig. 4 Non-explosion-proof motor without cooling jacket...
  • Page 15 S_Range_58-60Hz.book Page 15 Thursday, July 8, 2010 2:30 PM Construction S pumps, range 58 Fig. 5 Non-explosion-proof motor with cooling jacket...
  • Page 16 S_Range_58-60Hz.book Page 16 Thursday, July 8, 2010 2:30 PM Construction S pumps, range 58 Fig. 6 Explosion-proof motor without cooling jacket...
  • Page 17 S_Range_58-60Hz.book Page 17 Thursday, July 8, 2010 2:30 PM Construction S pumps, range 58 Fig. 7 Explosion-proof motor with cooling jacket...

  • Page 18: Sectional Drawings, Pumps

    S_Range_58-60Hz.book Page 18 Thursday, July 8, 2010 2:30 PM Construction S pumps, range 58 Sectional drawings, pumps Fig. 8 S1 pump...
  • Page 19 S_Range_58-60Hz.book Page 19 Thursday, July 8, 2010 2:30 PM Construction S pumps, range 58 Fig. 9 SV pump...
  • Page 20 S_Range_58-60Hz.book Page 20 Thursday, July 8, 2010 2:30 PM Construction S pumps, range 58 Fig. 10 S1 pump with DN 2 > DN 400...
  • Page 21 S_Range_58-60Hz.book Page 21 Thursday, July 8, 2010 2:30 PM Construction S pumps, range 58 Fig. 11 Installation type S and C pump on auto coupling...
  • Page 22 S_Range_58-60Hz.book Page 22 Thursday, July 8, 2010 2:30 PM Construction S pumps, range 58 Fig. 12 Installation type D pump...
  • Page 23 S_Range_58-60Hz.book Page 23 Thursday, July 8, 2010 2:30 PM Construction S pumps, range 58 Fig. 13 S1 pump, installation type H Fig. 14 SV pump, installation type H...

  • Page 24: Components And Material Specification

    S_Range_58-60Hz.book Page 24 Thursday, July 8, 2010 2:30 PM Construction S pumps, range 58 Components and material specification Motor Pos. Component Material (AISI/DIN W.-Nr.) Pos. Component Material (AISI/DIN W.-Nr.) Rubber seal Rivet Stainless steel (316/1.4436) Screw Stainless steel (316/1.4436) Screw Stainless steel (316/1.4436) 250a Cable entry...

  • Page 25: Product Description

    B: Without impeller clearance adjustment system EMC cable SmartSeal Outer cable diameter Bending Cable type [inch (mm)] radius For pumps with 10" discharge or larger, the Grundfos min. max. [inch (mm)] SmartSeal auto-coupling gasket mounted on the pump 3 x 6 0.54 (13.6) 0.6 (15.2)

  • Page 26: Operating Conditions

    (alarm). The sensor is fitted in a stainless steel tube for mechanical protection. Liquid temperature: 32 °F - 104 °F (0 °C - +40 °C) The WIO sensor is connected to the Grundfos When pumping liquids with a density and/or a kinematic IO 111 module.

  • Page 27: Explosion-Proof Pumps

    S_Range_58-60Hz.book Page 27 Thursday, July 8, 2010 2:30 PM Product description S pumps, range 58 Explosion-proof pumps Pump controllers S pumps, range 58, can be controlled by Grundfos Approval standards Dedicated Controls (DC). These pumps are approved by FM according to FM3600, FM3615 and FM3615.80.

  • Page 28: Wiring Diagrams

    S_Range_58-60Hz.book Page 28 Thursday, July 8, 2010 2:30 PM Product description S pumps, range 58 Wiring diagrams Fig. 15 Wiring diagrams, Y-connected (460 V)

  • Page 29: Curve Charts/Technical Data

    S_Range_58-60Hz.book Page 29 Thursday, July 8, 2010 2:30 PM Curve charts/ S pumps, range 58 Technical data The following many pages are divided into sections: Pages 29 and 30 A brief explanation of how to read the curve charts, the curve conditions, etc. Performance curves and technical data: Page 34 Extra-low pressure...

  • Page 30: Curve Conditions

    ISO 9906. The witness test is not a certificate and will not result in a written statement from Grundfos. The witness itself is total stat the only guarantee that everything is carried out as pre- scribed in the testing procedure.
  • Page 31 S_Range_58-60Hz.book Page 31 Thursday, July 8, 2010 2:30 PM...

  • Page 32: Performance Curves Technical Data

    S_Range_58-60Hz.book Page 32 Thursday, July 8, 2010 2:30 PM Performance curves S pumps, range 58 Technical data S 58 extra-low pressure, 6-pole S2.40.A120.340 [ m ] [ f t ] 5 8 E . S S 2 . 4 0 . A 1 2 0 . 3 4 0 . 6 . 6 0 H z I S O 9 9 0 6 A n n e x A N P S H...
  • Page 33 S_Range_58-60Hz.book Page 33 Thursday, July 8, 2010 2:30 PM Performance curves S pumps, range 58 Technical data Electrical data η Cos ϕ Moment of Breakdown start motor No. of Starting inertia torque M Pump type [kW] [hp] poles method [lbft2 (kgm [lbf*ft (Nm)] S2.40.A120.340.6.58E 1160...

  • Page 34: S 58 Low Pressure, 4-Pole

    S_Range_58-60Hz.book Page 34 Thursday, July 8, 2010 2:30 PM Performance curves S pumps, range 58 Technical data S 58 low pressure, 4-pole S1.45.A80.420 [ m ] [ f t ] 5 8 L . S 6 0 H z S 1 . 4 5 .
  • Page 35 S_Range_58-60Hz.book Page 35 Thursday, July 8, 2010 2:30 PM Performance curves S pumps, range 58 Technical data Electrical data η Cos ϕ Moment of Breakdown start motor No. of Starting inertia torque M Pump type [kW] [hp] poles method [lbft2 (kgm [lbf*ft (Nm)] S1.45.A80.420.4.58L 1749...

  • Page 36: S 58 Low Pressure, 4-Pole

    S_Range_58-60Hz.book Page 36 Thursday, July 8, 2010 2:30 PM Performance curves S pumps, range 58 Technical data S 58 low pressure, 4-pole S2.40.A80.420 [ m ] [ f t ] 5 8 L . S 6 0 H z S 2 . 4 0 . A 8 0 . 4 2 0 . 4 . I S O 9 9 0 6 A n n e x A N P S H [ f t ]...
  • Page 37 S_Range_58-60Hz.book Page 37 Thursday, July 8, 2010 2:30 PM Performance curves S pumps, range 58 Technical data Electrical data η Cos ϕ Moment of Breakdown start motor No. of Starting inertia torque M Pump type [kW] [hp] poles method [lbft2 (kgm [lbf*ft (Nm)] S2.40.A80.420.4.58L 1749...

  • Page 38: S 58 Medium Pressure, 4-Pole

    S_Range_58-60Hz.book Page 38 Thursday, July 8, 2010 2:30 PM Performance curves S pumps, range 58 Technical data S 58 medium pressure, 4-pole S1.40.A50.420 [ m ] [ f t ] S 1 . 4 0 . A 5 0 . 4 2 0 . 4 . 5 8 M .
  • Page 39 S_Range_58-60Hz.book Page 39 Thursday, July 8, 2010 2:30 PM Performance curves S pumps, range 58 Technical data Electrical data η Cos ϕ Moment of Breakdown start motor No. of Starting inertia torque M Pump type [kW] [hp] poles method [lbft2 (kgm [lbf*ft (Nm)] S1.40.A50.420.4.58M 1749...

  • Page 40: S 58 High Pressure, 4-Pole

    S_Range_58-60Hz.book Page 40 Thursday, July 8, 2010 2:30 PM Performance curves S pumps, range 58 Technical data S 58 high pressure, 4-pole S1.30.A50.340 [ m ] [ f t ] S 1 . 3 0 . A 5 0 . 4 1 8 0 5 8 H .
  • Page 41 S_Range_58-60Hz.book Page 41 Thursday, July 8, 2010 2:30 PM Performance curves S pumps, range 58 Technical data Electrical data η Cos ϕ Moment of Breakdown start motor No. of Starting inertia torque M Pump type [kW] [hp] poles method [lbft2 (kgm [lbf*ft (Nm)] S1.30.A50.340.4.58H 1752...

  • Page 42: Accessories (For Installation)

    For guide rails longer than 19.5 feet (6 m) NPS 8" / NPS 24" 17.6 (8) 96255842 (DN 200/DN 600) Guide rails Standard pipes. Not supplied by Grundfos Stand/pump discharge - hose NPS 4" / NPS3" 96856259 (DN 100 / DN 80) Cast iron, epoxy-coated ring stand.

  • Page 43: Other Accessories

    S_Range_58-60Hz.book Page 43 Thursday, July 8, 2010 2:30 PM Accessories S pumps, range 58 Other accessories Product Pictures Description Dimensions number 13 ft (4 m) galvanised lifting chain with lifting link and safety hook. 96735550 With certificates. 20 ft (6 m) galvanised lifting chain with lifting link and safety hook. 96735553 With certificates.

  • Page 44: Dimensions

    S_Range_58-60Hz.book Page 44 Thursday, July 8, 2010 2:30 PM Dimensions S pumps, range 58 Installation on auto coupling TM04 2417 2508...
  • Page 45 S_Range_58-60Hz.book Page 45 Thursday, July 8, 2010 2:30 PM Dimensions S pumps, range 58...
  • Page 46 S_Range_58-60Hz.book Page 46 Thursday, July 8, 2010 2:30 PM Dimensions S pumps, range 58 TM04 2416 2508...
  • Page 47 S_Range_58-60Hz.book Page 47 Thursday, July 8, 2010 2:30 PM Dimensions S pumps, range 58...

  • Page 48: Installation On Ring Stand

    S_Range_58-60Hz.book Page 48 Thursday, July 8, 2010 2:30 PM Dimensions S pumps, range 58 Installation on ring stand TM04 2420 2508...
  • Page 49 S_Range_58-60Hz.book Page 49 Thursday, July 8, 2010 2:30 PM Dimensions S pumps, range 58...

  • Page 50: Dry Pit, Vertical Installation

    S_Range_58-60Hz.book Page 50 Thursday, July 8, 2010 2:30 PM Dimensions S pumps, range 58 Dry pit, vertical installation TM04 2422 2508...
  • Page 51 S_Range_58-60Hz.book Page 51 Thursday, July 8, 2010 2:30 PM Dimensions S pumps, range 58...

  • Page 52: Dry Pit, Horisontal Installation

    S_Range_58-60Hz.book Page 52 Thursday, July 8, 2010 2:30 PM Dimensions S pumps, range 58 Dry pit, horisontal installation TM04 2414 2508...
  • Page 53 S_Range_58-60Hz.book Page 53 Thursday, July 8, 2010 2:30 PM Dimensions S pumps, range 58...

  • Page 54: Further Product Documentation

    WebCAPS is a Web-based Computer Aided Product Selection program available on www.grundfos.com. WebCAPS contains detailed information on more than 185,000 Grundfos products in more than 20 languages. In WebCAPS, all information is divided into 6 sections: • Catalogue • Literature •...

  • Page 55: Wincaps

    Based on an easy step-by-step guide, you can compare Grund- fos pumps with the one you have installed on your site. When you have specified the installed pump, the guide will suggest a number of Grundfos pumps which can improve both comfort and efficiency. CAD drawings In this section it is possible to download 2-dimensional (2D) and 3-dimensional (3D) CAD drawings of most Grundfos pumps.
