4–VXLAN Configuration with the QLogic 3400/8400/45000 Series Adapters
VXLAN Configurations

Verify VXLAN Ports on Network and Compute Nodes

To verify VXLAN ports on the Network, Compute1, and Compute2 nodes:
1. Ensure that the Network node tunneling bridge output and associated
VXLAN ports are configured correctly by issuing the following command:
# ovs-vsctl show
Following is a sample output.
Bridge br-tun
local_ip="10.0.1.81", out_key=flow, remote_ip="10.0.1.92"}
local_ip="10.0.1.81", out_key=flow, remote_ip="10.0.1.91"}
2. Ensure that the Compute1 and Compute2 nodes' tunneling bridge output
and associated VXLAN ports are configured correctly by issuing the
following command:
ovs-vsctl show
Port br-tun
Interface br-tun
type: internal
Port patch-int
Interface patch-int
type: patch
options: {peer=patch-tun}
Port "vxlan-0a00015c"
Interface "vxlan-0a00015c"
type: vxlan
options: {df_default="true", in_key=flow,
Port "vxlan-0a00015b"
Interface "vxlan-0a00015b"
type: vxlan
options: {df_default="true", in_key=flow,
9 83840-546-03 B
