6 kg vented electro mechanical tumble dryers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Service
Information
© 2008 Reg. Office: Peterborough PE2 9JB. Registered in London: 106725
Indesit Company UK Limited
5407394
Issue 1
6 kg
Vented
Electro
Mechanical
Tumble Dryers
Models
Covered
Hotpoint-Ariston
TVM631EUHA
Ariston
AS600VXFR
AS600VKW
AS600VEX
AS600VXAG
May 2008
Comm.
Code
48890
49613
51893
51891
51896

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TVM631EUHA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hotpoint Ariston TVM631EUHA

Summary of Contents for Hotpoint Ariston TVM631EUHA

  • Page 1: Service Information

    5407394 Issue 1 May 2008 6 kg Vented Electro Mechanical Tumble Dryers Models Comm. Covered Code Hotpoint-Ariston TVM631EUHA 48890 Ariston AS600VXFR 49613 AS600VKW 51893 AS600VEX 51891 AS600VXAG 51896 Service Information Indesit Company UK Limited © 2008 Reg. Office: Peterborough PE2 9JB. Registered in London: 106725...

  • Page 2: Safety Notes & General Servicing Advice

    SAFETY NOTES & GENERAL SERVICING ADVICE 1. This manual is NOT intended as a comprehensive repair/maintenance guide to the appliance. 2. It should ONLY be used by suitably qualified persons having technical competence applicable product knowledge and suitable tools and test equipment. 3.

  • Page 3: Table Of Contents

    Timer Sequence Charts ........18 - 19 Wiring Diagram - Models TVM631EUHA, AS600VEX, AS600VXFR Invensys Timer.

  • Page 4: Technical Specifications

    TECHNICAL SPECIFICATION General All models Polar White Features Reversing - Dual Heat - 140 minutes Programme Timer, Easy Iron (crease removal) and Auto Drying options, 12 hour Delay Timer and End of Programme Alarm (with Switch and Start Switch). Energy Efficiency Noise 69 dB Country of Origin...

  • Page 5: Machine Function

    MACHINE FUNCTION Cold air is drawn into the dryer cabinet interior through louvres in the cabinet base, passes through the large hole in the inner back panel adjacent to the fan and is driven through the element housing on the inner back panel. After passing through the element windings and through holes in the drum back plate into the drum interior, the now warm air is driven through the load to the front of the drum.
  • Page 6 AUTOMATIC DRYING - Fitted to some models only To work correctly High Heat has to be enabled and between 3 kg to 6 kg of Cottons dried. If smaller or delicate loads are dried using the automatic setting, erratic results will be achieved. Automatic Drying Explanation NOTE: - The heat switch must be set to the high position otherwise there will be no circuit to the timer motor or heater when the exhaust thermostat signals that the clothes are dry.

  • Page 7: Console

    CONSOLE Indicator TIMER PROGRAMMES Knob Knob ACTIVE Light ALARM HEAT START Button Button Button Drying Guide The START button begins drying a selected The Drying Guide allows the customer to programme. consult a user friendly table of fabric types and load capacities and shows a guide of the programmes available.

  • Page 8: Programmes

    PROGRAMMES Programme What it does... How to set it... Note: Automatic 1. Select HIGH HEAT ! If you select LOW HEAT, Dries completely: Drying this programme will not dry by pressing the HEAT button. your clothes are ready to be your clothes.

  • Page 9: Component Description

    COMPONENT DESCRIPTION CONSOLE PANEL This panel contains the user controls, which consist of a timer knob, for selecting the timed and sensed drying periods, two push switches for heat selection and buzzer selection and a momentary switch to start the dryer. A Red LED glows to indicate when the dryer is active. TIMER The timer system is made up from up to three timers, two mounted on the console and one on the kickstrip.
  • Page 10 DOOR INTERLOCK RELAY - Models AS600VXFR, AS600VEX, TVM631EUHA The door interlock relay mounts on the rear of the front panel. The relay has double pole isolation which acts as an additional safety feature.
  • Page 11 BUZZER Eco models fitted with the Easy Care timer have a buzzer fitted which, if selected by the buzzer switch, sounds to indicate to the user the end of a programme. The buzzer is mounted on the door interlock relay PCB that is mounted on the rear of the console. DRUM The drum comprises of a zinc-coated front and rear body and two removable plastic lifters.
  • Page 12 DRUM EARTHING As the drum is supported in plastic bearings, it is necessary to provide a means of earthing. The earthing on the drum is achieved by the teardrop shaped bearing fixing screw. the correct screw must always be used. BELT A 9 rib belt has been used in production.

  • Page 13: Dismantling Instructions

    DISMANTLING INSTRUCTIONS SAFETY NOTES 1. Ensure that the machine is unplugged before commencing any work. 2. Beware of sharp edges on metal panels and pressed parts. Top Cover Remove the 2 screws securing the top cover to the back panel. Slide the top cover back and lift clear of the console.
  • Page 14 Side Panels Remove the top cover as in (A). Remove the plinth by pulling forward. Remove the screw behind the plinth. Remove the screw securing the side panel to the front panel. Remove the 4 screws securing the side panel to the rear panel. Pull the side panel backward to disengage from the lugs on the base panel.
  • Page 15 Door Open the door and remove the 4 screws securing the door assembly to the front panel. Remove the complete door from the front panel. Remove 1 screw securing the door latch to the door. Remove the screw behind the door latch, securing the door handle to the door. Remove the 6 screws securing the two halves of the door assembly.
  • Page 16 Drum Assembly Remove the top cover as in (A) Remove the console as in (B) Remove the front panel as in (G). Remove the right hand panel to make drum removal easier. Remove the rear bearing cover - 2 screws. Remove one Earth strip fixing screw, slacken the other, and turn the Earth strip to allow access to the drive pin.
  • Page 17 Rear Seal Remove the drum as in (Q). Remove the rear seal and clean any remnants of the seal and adhesive from the inner face of the inner back panel. Fit the new seal using adhesive Part No 981027. Heating Assembly & Thermostats Remove the right hand side panel as in (F).

  • Page 18: Timer Sequence Charts

    SWITCH RATINGS ECO TIMER CONTACT / TERMINAL RATING COMPONENT MAX. SWITCHED CURRENT Invensys EC ELBI 5000 C3 - C2 C3 - C4 16(4)A TIMER MOTOR <1A C3 - C1 C3 - C5 16(4)A TIMER MOTOR <1A A1 - A3/A4 B3 - B4 16(4)A MOTOR &...

  • Page 19: Timer Sequence Charts

    REVERSING TIMER SEQUENCE CHART FOR ECO MODELS switch switch 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 1 to 2 secs - >...

  • Page 20: Invensys Timer

    WIRING DIAGRAM - MODELS TVM631EUHA, AS600VEX, AS600VXFR Invensys Timer = INSULATOR 16002229407 M = MALE TAB PB = PIGGY BACK EC Timer GREY/BLUE WHITE GREY / BLUE WIRING DIAGRAM BROWN ** UPPER STAT POSITION IS NEXT TO FRONT TO BACK TUBE.

  • Page 21: Elbi Timer

    WIRING DIAGRAM - MODELS TVM631EUHA, AS600VEX, AS600VXFR Elbi Timer = INSULATOR 16002229407 M = MALE TAB PB = PIGGY BACK Elbi 5000 WHITE GREY/BLUE F = FLAG WIRING DIAGRAM ** UPPER STAT POSITION IS NEXT TO FRONT TO BACK TUBE.

  • Page 22: Invensys Timer

    WIRING DIAGRAM - MODELS AS600VXAG, AS600VKW Invensys Timer = INSULATOR M = MALE TAB GREY/BLUE WHITE PB = PIGGY BACK 16002212003 EC TIMER WIRING DIAGRAM BLUE BLACK/WHITE ** UPPER STAT POSITION IS NEXT TO FRONT TO BACK TUBE. VOGUE IV PHD ECO CYCLING BROWN GREY/BLUE...

  • Page 23: Elbi Timer

    WIRING DIAGRAM - MODELS AS600VXAG, AS600VKW Elbi Timer = INSULATOR M = MALE TAB WHITE GREY/BLUE PB = PIGGY BACK 16002212003 ELBI 5000 WIRING DIAGRAM ** UPPER STAT POSITION IS NEXT TO FRONT TO BACK TUBE. BLUE BLACK/WHITE VOGUE V PHD ECO CYCLING STAT WITH DELAY...
