Simplicity 2691127-0 Operator's Manual page 27

Mower Deck (52 Inch)
Removing the Mower Deck
WARNING
Engage parking brake, disengage PTO, stop
engine and remove key before attempting to install or
remove the mower.
1. Park tractor on a hard, level surface such as a concrete
floor. Engage parking brake, disengage PTO, and stop
engine.
2. Place attachment lift in the UP position, then remove
springs from hanger brackets (see Figure 14).
en
3. Place wooden 2x4's under the rear of mower deck on
both sides.
4. Place attachment lift in the DOWN position, then adjust
height-of-cut (as needed) and remove chains from lift
hooks (see Figure 15).
5. Place attachment lift in the UP position.
6. Place mower in the highest cutting position, then remove
wooden 2x4's from under the rear of mower deck.
7. Move idler arm (A, Figure 16) to remove belt tension,
then remove belt from PTO pulley (A).
15
Figure 14
Figure 15
