Operating instructions
Safe AS-i output module
UK
AC030S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC030S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for IFM Electronic AC030S

  • Page 1 Operating instructions Safe AS-i output module AC030S...
  • Page 2: Table Of Contents

    Contents 1 Safety instructions ������������������������������������������������������������������������������������������������3 2 Installation / Set-up �����������������������������������������������������������������������������������������������4 3 Operating and display elements ���������������������������������������������������������������������������6 4 Installation ������������������������������������������������������������������������������������������������������������6 5 Electrical connection���������������������������������������������������������������������������������������������6 6 Response times ����������������������������������������������������������������������������������������������������9 7 Consideration of the residual error probability to IEC 61508 ������������������������������10 8 Addressing ���������������������������������������������������������������������������������������������������������� 11 9 Programming ������������������������������������������������������������������������������������������������������...
  • Page 3: Safety Instructions

    1 Safety instructions Follow the operating instructions� Non-observance of the instructions, operation which is not in accordance with use as prescribed below, wrong installation or handling can affect the safety of people and machinery� For installation and prescribed use of the unit the notes in the operating instructions must be carefully observed and the applicable technical standards relevant for the application have to be considered�...
  • Page 4: Installation / Set

    2 Installation / Set-up Applications The safe AS-i relay output module with conventional inputs is a decentralised output module for safe triggering of actuators in the AS-Interface Safety at Work system� For this purpose, a code table with 7 x 4 bits is transmitted via the AS-i system; sent by the AS-i safety monitor (e�g�...
  • Page 5 Important note: The products described herein are designed to be components of a safety- oriented machine or control system� A complete safety-related system normally includes sensors, evaluation units, actuators and signalling components� It is the responsibility of each manufacturer of a machine or installation to ensure a correct functioning of the whole system�...
  • Page 6: Operating And Display Elements

    3 Operating and display elements ���� � � � Slide switch R/P Addressing plug Combicon connector with screw terminals (option) 4 Installation Install the safe AS-i output module on a 35 mm raised rail� The protection rating of the unit is IP 20, therefore it should be mounted in a protected location (e�g� control cabinet)�...
  • Page 7 Wiring AS-i + AS-i - �� �� �� �� sensor supply from AS-i �� �� �� ���� (+24 V output) �� �� �� �� I-:: sensor supply from AS-i (0 V) ������ I1���I3 / 1�Y1: non-safe switching inputs ������ 13-14 / 23-24: safe relay output ���...
  • Page 8 Data bits Data bit In/Out 1�Y1 I-2 / O-2 I-1 / O-1 Activated inputs Bit D3-D0 XXX1 XX1X X1XX 1�Y1 1XXX Activated alarm output Bit D3-D0 XXX1 Activated process output Bit D3-D0 XX1X X = random Parameter bits Parameter bit default: Parameter bit Description 1: input I1...
  • Page 9: Response Times

    Note: safe relay output The safe relay output is implemented with two positively driven relay contacts� If one of the two internal relays does not switch (e�g� due to fusing of the contacts), this is detected in the safe output module� The relay contacts 13-14 and 23-24 are potential-free normally open contacts�...
  • Page 10: Consideration Of The Residual Error Probability To Iec 61508

    7 Consideration of the residual error probability to IEC 61508 To calculate the PFH (probability of a dangerous failure per hour) of a safety-rela- ted function the PFH values of all components used in this function must be taken into account� The probability of failure on demand (PFD) is 2�0 x 10 �...
  • Page 11: Addressing

    8 Addressing The safe AS-i output module can be addressed, when mounted and wired, via the addressing unit AC1144 with the cable (EVC076); the address is set to 0 at the factory� A special feature of the safe AS-i output module are the two types of AS-i addresses: •...
  • Page 12: Operation

    Programming of the non safety-related AS-i address This address can be programmed in the R position of the switch with the addressing unit or the AS-i master (green release LED flashes)� 10 Operation Check whether the unit operates correctly� Display by LEDs: •...
  • Page 13: Technical Data

    11 Technical data 4 non-safe inputs / Electrical design 2 non-safe LED outputs / 1 safe relay output 26�5 ��� 31�6 V DC Operating voltage „supply class 2“ to cULus Current consumption ≤ 200 mA Inputs Wiring DC PNP Input voltage range sensor 18���30 V DC Voltage supply via AS-i...
  • Page 14: Approvals

    EN 50295 Housing materials Dimensions (H x W x D) 108 x 25 x 105 mm Additional technical specification for AC030S in context with cULus approval (UL508) Operating voltage 30 V, 9 W External protection An isolated source with a secondary open circuit voltage <...
  • Page 15: Scale Drawing

    13 Scale drawing �� ���...
