  • Page 1 Operating instructions IO-Link master CabinetLine AL19xx...

  • Page 2: Preliminary Note

    1 Preliminary note Technical data, approvals, accessories and further information at www.ifm.com. 2 Safety instructions • Read this document before setting up the product and keep it during the entire service life. • The product must be suitable for the corresponding applications and environ- mental conditions without any restrictions.

  • Page 3: Installation

    4.1 Warnings used WARNING Warning of serious personal injury. Death or serious irreversible injuries may result. 4.2 Safety symbols on the device General warning on the device. When this symbol appears, consider the corresponding section in the operating instructions. 5 Installation ►...

  • Page 4: Electrical Connection

    6 Electrical connection The unit must be connected by a qualified electrician. The national and international regulations for the installation of electrical equipment must be adhered to. The communication interfaces are insulated among each other and from the device supply (according to EN60950-1, basic insulation as secondary circuit max. 30 V DC, SELV).
  • Page 5 6.2 Interfaces LEDs AL1900 AL1920 AL1930 Voltage supply Voltage supply Voltage supply 8 IO-Link A ports 8 IO-Link A ports 8 IO-Link A ports PROFINET-IO EtherNet/IP EtherCAT IoT port IoT port IoT port (Internet of Things) (Internet of Things) (Internet of Things)

  • Page 6: Factory Settings

    7 Factory settings AL1900 AL1920 AL19xx PROFINET EtherNet/IP IoT (Internet of Things) IP address 0.0.0.0 192.168.1.250 169.254.X.X IP addressing static DCP, DHCP, Auto IP IP address Subnet mask 0.0.0.0 255.255.255.0 255.255.0.0 Gateway IP address 0.0.0.0 0.0.0.0 0.0.0.0 MAC address see type label see type label see type label 8 Parameter setting...

  • Page 7: 10 Scale Drawing

    10 Scale drawing 105,3 100,6...
