- Page 1 Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es INSTALLATION, OPERATION AND MAINTENANCE MANUAL Lug butterfly valve GENEBRE Reference: 2108 – 2108A GENEBRE S.A. LAST UPDATE: 08/02/2017 UPDATE NUMBER: 1...
-
Page 2: Table Of Contents
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es Installation, operation and maintenance instructions 1) PRODUCT DESCRIPTION ....................3 2) EXPLODED DRAWING ...................... 3 2.1) PARTS LIST ..............................4 3) STORAGE ........................... 4 4) INSTALLATION INSTRUCTIONS .................. -
Page 3: Product Description
- www.genebre.es 1) Product description Genebre, S.A. offers a wide range of ball valves (90º turn), designed and assembled to handle and drive fluids in industrial procedures. The compatibility of materials used to build the valves (see technical specifications) and the application of valves to the different industrial processes is at user's risk. -
Page 4: Parts List
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 2.1) Parts list Denominación / Acabado Superficial / Cód. Recambio Material Name Surface Treatment Spare Part Code Cuerpo / Body Fundición / Cast Iron EN-GJL-400... -
Page 5: Assembling
REMARKS: - Lug butterfly valves by Genebre, S.A., ref. 2108 are designed to be assembled between flanges EN 1092 PN16 at a maximum working pressure of 16 bar (until DN150), and between flanges EN 1092 PN10 at a maximum working pressure of 10 bar (from DN200 and bigger sizes). -
Page 6: Operation Instructions
5) Operation instructions 5.1) Usage Valves 2108 / 2108A provide a leakproof seal when used adjusted to the pressure and temperature values for which they have been designed. Seat material for the valve, joints, body, disk and axis has to be fully compatible with the fluid circulating through the valve. -
Page 7: Remote Operation
5977 50:1 12.5 5.3) Remote operation When automation of valves is required, GENEBRE S.A. can provide a great variety of pneumatic actuators, electric actuators, pneumatic positioners and electropneumatic ones to cover a large range of operations. 6) Maintenance operations It is recommended to operate the valve at least once a month. -
Page 8: Disassembling
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 7.1) Disassembling You must remove the valve from installation to repair it. Prepare a clean working area and adequate tools to perform mechanical tasks. -
Page 9: Torques
Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es d.- Finish off by placing the handle, the reducer gear or the actuator as appropriate, taking into account their opening or closing position. - Page 10 Genebre Building. Av. de Joan Carles I, 46-48 08908 L'Hospitalet de Llobregat. Barcelona (Spain) genebre@genebre.es - www.genebre.es 9.2) Before removing a valve from a pipe, check always if the line is completely drained and depressurized. 9.3) Any valve being used by toxic services department needs to obtain a cleanliness certificate before being operated.
