Summary of Contents for Abus TVHD50000
- Page 1 Day & Night HD-SDI 1080p Standard Camera TVHD50000 TVHD50500 Version 05/2012 Original operating instructions in German. Retain for future reference!
- Page 2 ABUS Security-Center is not liable or responsible for direct or indirect damages resulting from the equipment, performance and use of this product. No forms of guarantee are accepted for the...
- Page 3 Important Safety Information All guarantee claims are invalid in the event of damage caused by non-compliance with these operating instructions. We cannot be held liable for resulting damages. In the event of material or personal damage caused by improper operation or non- compliance with the safety notes, we cannot be held liable.
-
Page 4: Table Of Contents
Contents INTENDED USE ......................23 EXPLANATION OF SYMBOLS .................. 23 SCOPE OF DELIVERY ....................23 FEATURES AND FUNCTIONS ................... 23 DEVICE DESCRIPTION ....................24 5.1 O – M ..................24 VERVIEW ODEL NUMBERS 5.2 U ....................24 NPACKING THE DEVICE INSTALLATION ...................... -
Page 5: Intended Use
Day & night HD-SDI 1080p standard camera C-mount lens adapter ring Base for camera mount incl. screws Connection cable for the 12 VDC power supply (TVHD50000) Operating instructions 4. Features and functions HD-SDI – High-Definition Serial Digital Interface Full HD resolution (1080p, 2.0 MPx) Transmission via conventional CCTV infrastructure (coaxial cable) Day &... -
Page 6: Device Description
TVHD50000 TVHD50500 TVHD50000 is equipped with a 12 V DC/24 V AC power supply. If you use a DC power supply, the polarity is not important. In order to connect a plug-in power supply unit (DC connection 5.5 mm x 2.1 mm) to the camera, the adapter included with the camera must first be installed. -
Page 7: Mounting A Lens
6.2 Mounting a lens The camera is intended for use with CS-mount lenses. A C-mount lens can be mounted using the lens adapter ring included. Before mounting a C-mount lens, ensure that the adapter ring is in place on the camera. -
Page 8: Rear View Of The Camera
7. Rear view of the camera MONITOR MONITOR POWER POWER HD-SDI HD-SDI 12VDC 110~240VAC 24VAC 12 V DC/24 V AC version 110~240 V AC version (1) OSD buttons (2) Power supply connection (12 V DC/24 V AC or 110 – 240 V AC) (3) Status LED (active when voltage present) (4) BNC test monitor output (MONITOR) (5) BNC HD-SDI video output (HD-SDI) -
Page 9: Osd Menu
8. OSD Menu Function Description QUICK INSTALL Quick setup of the most important camera parameters ADVANCED MENU Detailed explanation of all camera parameters EXIT Exit menu QUICK INSTALL The "QUICK INSTALL" function has been implemented for simple configuration of the camera. - Page 10 Function Description Standard value EXPOSURE DC / AES Settings for the lens in use DC: Setting for the electronically-controlled AI lens AES: Setting for lens with manual lens aperture SHUTTER Exposure control settings AUTO SHUTTER Automatic or manual setting for the exposure time Exposure control settings Wide Dynamic Range function inactive =...
- Page 11 ADVANCED MENU ADVANCED MENU EXPOSURE DC .. WHITE BALANCE ENHANCE AUTO .. MISCELLANEOUS RESTORE DEFAULT EXIT Function Description EXPOSURE Exposure control settings WHITE BALANCE White balance settings ENHANCE Image optimization settings Day/night settings MISCELLANEOUS Settings for image mirroring, masking, camera name and live picture verification RESTORE DEFAULT Restore settings...
- Page 12 WHITE BALANCE Function Description White balance settings AWB: Auto White Balance White balance calculations are dynamically and continuously performed in the 2700~9500K range. ATW: Auto White Balance White balance calculations are dynamically and continuously performed in the 1800~10500K range. PTL: Push-To-Lock White balance is performed after pressing the "Enter"...
- Page 13 D/N – Day/Night Function Description Day/night settings AUTO: Switching between day and night mode occurs automatically and is regulated by the light sensor on the front of the camera. DELAY TIME (5~60): Delay time before switching takes place. NIGHT CHROMA: Settings for color display in night mode.
- Page 14 Enter : Select character Left : Navigate one place to the left Right : Navigate one place to the right Delete : Delete character WINKER Live picture verification The "winker" function enables live picture verification. A flashing symbol is shown in the camera image. Off : Live picture verification deactivated On : Live picture verification activated RESTORE DEFAULT...
-
Page 15: Maintenance And Cleaning
9. Maintenance and cleaning 9.1 Function test Regularly check the technical safety of the product, e.g. check the housing for damage. If safe operation is no longer possible, cease operating the product and safeguard it against accidental operation. Safe operation is no longer possible in the following circumstances: The device shows visible damage. -
Page 16: Technical Data
Technical data TVHD50000 TVHD50500 Image sensor 1/2.8" progressive scan Sony Exmore CMOS Sony IT-N Camera type HD-SDI standard camera 1080p Resolution Pixels (total) 2000 x 1241 Pixels (effective) 1920 x 1080 Lens mount CS, C Lens control Day/night switching IR swivel filter (ICR), color / B/W...
