Texmate leopard Series Manual

Transmitter and controller
Hide thumbs Also See for leopard Series:

Advertisement

Quick Links

General Features
External transmitters or signal conditioners can be eliminated
by direct connection of the sensor output to more than
38 Plug-in Input Signal Conditioners that include:
- AC/DC Current
- Pressure
- AC/DC Voltage
- Process
- Load Cell
- Prototype
*See models TLH for higher accuracy digitally linearized thermocou-
ple and RTD
Isolated 16 bit analog output. User or factory scalable to 4 to 20 mA,
0 to 20 mA or 0 to 10 V across any desired
digital span from ± one count to the full scale range of - 1999 to 9999
(12000 counts).
Auto-sensing AC/DC power supply. For voltages between
85-265 V AC / 95-300 V DC (PS1) or 15-48 V AC / 10-72 V DC
(PS2).
24 V DC excitation is available to power external transmitters
and 5 or 10 V DC excitation is available for resistance bridge type
sensors such as Load Cells and Pressure Transducers.
Automatic intelligent averaging smooths noisy signals, while
providing a fast display response to real level changes.
Remote Diplay Option only.
Software Features
• Three-button programming from the optional remote display
(UP, DOWN and PROGRAM buttons).
• Front panel selectable four-level brightness control of digital dis-
play, and setpoint LEDs when diplay is used.
• Two programmable setpoints.
• Relay activation can be selected to occur above (HI) or below
(LO) each setpoint.
• Hysteresis, Delay on make and delay on break for both set-
points.
• Peak and Valley. View and Reset.(only when diplsya is used)
Case Dimensions . . . . . . . . . . . 12
Connector Pinouts . . . . . . . . . . . . .7
Controls and Indicators . . . . . . . . .2
Digital Calibration Mode . . . . . . . .4
TL_manual (d0007)
LEOPARD FAMILY
An economically smart programmable transmitter relay with
isolated 4 to 20 mA retransmission or control loop output
- Resistance
- *Temperature
- 4 to 20 mA
Range Output . . . . . . . . . . . . . . . .5
Functional Diagram . . . . . . . . . . . .7
General Features. . . . . . . . . . . . . .1
Glossary of Prog. Symbols . . . . . .2
Input Module Analog Cal. . . . . 11-12
Input Module Comp. Glossary. . . .11
Input Module Compatibility . . . . . .1
Texmate, Inc. Tel. (760) 598-9899 • www.texmate.com
transmitter and Controller
capability for measurementand control applications.
Input Module Compatibility
LEOPARD FAMILY:
ent Plug-in I-Series Input Signal Conditioners
are approved for Texmate's Leopard Family of
meters. Some examples are shown on pages 8-10.
See www.texmate.com for an up to date listing.
Specifications
Input Specs: ..............Depends on Input signal conditioner
A/D Converter: ..........14 bit single slope
Accuracy: ..................±(0.05% of reading + 2 counts)
Temp. Coeff.: .............100 ppm/°C (Typical)
Warm up time: ...........2 minutes
Conversion Rate: ......5 conversions per second (Typical)
Remote Display: .......4 digit 0.56" Red LED Remote dis-
Polarity: .....................Assumed positive. Displays - negative
Decimal Selection: ....Front panel button selectable, X•X•X•X•
Positive Overrange: ..Top segments of digital display flash
Negative Overrange: .Bottom segments of digital display flash
Relay Output: ............Two 9 Amp Form C relays.
Analog Output: .........Isolated 16 bit user scalable mA or V
AIC (mA out) ...........4-20 mA @ 0 to 500Ω max loop resistance
AIV (volts out) .......... 0-10 V DC @ 500 Ω or higher resistance
Power Supply: ...........AC/DC Auto sensing wide range supply
PS1 (std) ................85-265 VAC 50-400Hz / 95-300 VDC @ 3.5W
PS2 .........................15-48 VAC 50-400Hz / 10-72 VDC @ 3.5W
Operating Temp.: ......0 to 50 °C
Storage Temp: ...........-20 °C to 70 °C.
Relative Humidity: ....95% (non condensing)
Case Dimensions: ....DIN Rail Mount
Weight: .......................7.5 oz., 9.0 oz when packed
Index
I-Series Input Signal Conditioning
Modules . . . . . . . . . . . . . . . . . . 8-10
Installation Guidelines . . . . . . . . 13
Ordering Information . . . . . . . . . 14
Select Input Range and Analog
output . . . . . . . . . . . . . . . . . . . . . 13
tl
leopard Series
More than 38 differ-
play. (Optional)
Range -1999 to 9999 counts.
22.5mm x 102.4mm x 128.7mm
(Width x Height x Depth)
Plus 11.8 mm (0.47") for Right-angled
connectors.
Setpoint Setting & RelayConfiguration
Mode. . . . . . . . . . . . . . . . . . . . . . . .6
Software Features . . . . . . . . . . . . .1
Software Logic Tree. . . . . . . . . . . .3
Specifications. . . . . . . . . . . . . . . . .1
Two Point Analog Output
Range Setting and Calibration . . .5
LEOPARD
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the leopard Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Texmate leopard Series

  • Page 1: Table Of Contents

    Texmate’s Leopard Family of – AC/DC Current – Pressure – Resistance meters. Some examples are shown on pages 8-10. See www.texmate.com for an up to date listing. – AC/DC Voltage – Process – *Temperature LEOPARD – Load Cell –...
  • Page 2: Controls And Indicators

    If the display is shown with XXXX it means the value displayed will be the previously set value. When a number is shown it indicates the initial factory default setting or a specific “example number”. Page 2 Texmate, Inc. Tel. (760) 598-9899 • www.texmate.com TL_manual (d0007)
  • Page 3 [rLYS] L or H (h) High for SP1 the relay energizes when the setpoint is exceeded L or H (L) Low for SP2 the relay energizes below the setpoint. TL_manual (d0007) Texmate, Inc. Tel. (760) 598-9899 • www.texmate.com Page 3...
  • Page 4: Decimal Point & Brightness Selection

    (positive and negative values are allowed). See Page 5 2) The scaling requirement exceeded the capability of the meter (–1999 to 9999). Decimal Point 3) No input signal present, or incorrect connections. (dp) Page 4 Texmate, Inc. Tel. (760) 598-9899 • www.texmate.com TL_manual (d0007)
  • Page 5: Digital Span Selection For Analog Range Output

    20-4 mA output. The span of the digital scale can be as small as two counts however small spans cause the 16 bit D to A to increment in stair case steps. TL_manual (d0007) Texmate, Inc. Tel. (760) 598-9899 • www.texmate.com Page 5...
  • Page 6 STEP L L or H for SP2 The transmitter exits the setpoint mode and return to the operational display. Operational Display The Setpoint Relay programming mode is now complete. Page 6 Texmate, Inc. Tel. (760) 598-9899 • www.texmate.com TL_manual (d0007)
  • Page 7: Functional Diagram

    Fuse for LO Voltage +18 VDC ISO Connector Pinouts Connector Pinouts Standard plug-in screw terminal connectors provided by Texmate: Pinout Diagram The Top and Bottom View of the trnsmitter diagram shows the transmitter with the relay configuration: Two 9 Amp Form C. An analog output module is also shown as installed.
  • Page 8 Where appropriate, all the standard ranges shown are designed to be header selectable by the user, and Texmate's unique SPAN ADJUST Header facilitates scaling to almost any required engineering unit.
  • Page 9 Offset TIGER < Decrease Zero Increase > PIN 2 LEOPARD Common External Loop Supply < Decrease Span Increase > LYNX Fully User Scalable IP07: Universal Process Input 2V/5V/10V/20V/200V/2mA/20mA/Custom 224D TL_manual (d0007) Texmate, Inc. Tel. (760) 598-9899 • www.texmate.com Page 9...
  • Page 10 Compensated by Module LYNX IS07: Pressure/Load Cell Ext Exc. High Impedance, 20/2mV/V, 4/6–wire 277A For multiple pressure transducers Pressure Hi Impedance ZERO TIGER LEOPARD External Power Supply 5V or 10V Page 10 Texmate, Inc. Tel. (760) 598-9899 • www.texmate.com TL_manual (d0007)
  • Page 11 To the of the SPAN pot (as viewed from the rear of the Left Rear Texmate’s unique SPAN ADJUST and SPAN RANGE Headers meter). Typically it enables the input signal to be ZERO provide the circuit equivalent of an ultra-precision one megohm 75 Turn Clockwise to offset ±5% of full scale (-100 to +100 counts).
  • Page 12 ZERO OFFSET RANGE Headers. mA signal span. Texmate’s unique ZERO OFFSET RANGE Header enables the 2 To scale down the Signal Span to 62.5% select the (Hi Range) use of a simple two step scaling and calibration procedure for those Position on the Span Range Header and the 70% Signal Span process signals that require large offsets.
  • Page 13 3. Insert the board back to the main board B. Move jumper to select Input Range for applicable input modules (see Input module suppliment z87 on our website.) TL_manual (d0007) Texmate, Inc. Tel. (760) 598-9899 • www.texmate.com Texmate, Inc. Tel. (760) 598-9899 • www.texmate.com Page 13...
  • Page 14: Modules

    OIC . . Isolated 16 Bit Current Output, 4-20mA OIV . . Isolated 16 Bit Voltage Output, 0-10VDC TL . . . . . . . Standard Leopard Series Transmitter and Controller 4relAy outPut R11 .
