- Page 1 YSI 5905/5010 BOD Probe Instruction Manual...
-
Page 3: Table Of Contents
Table of Contents ................ 1 NTRODUCTION ............2 PERATING RINCIPALS 5905/5010 BOD P ........3 SING ROBE 2 ......3 HANGING EMBRANE IGURE ................5 3........5 LECTRODE LEANING IGURE ....... 7 PERATING ROCEDURES AND RECAUTIONS ..............9 ROBLEM OLVING .......... -
Page 5: Introduction
The 5905 probe is designed for use with all YSI dissolved oxygen meters, except for the Model 55 or Model 95. It must be used with an adapter (5011) in order to be used on the Model 5000 and 5100. -
Page 6: Operating Principals
PERATING RINCIPALS The 5905/5010 BOD probe is a voltammetric (polarographic) sensor of dissolved oxygen. An oxygen permeable membrane covers an electrolytic cell consisting of a cathode and an anode. This membrane acts as a diffusion barrier and an isolation barrier preventing the fouling of the cathode surface by impurities in the environment. -
Page 7: Using
Note: The 5905 must be plugged into a YSI meter and the stirrer power plug must be plugged into its power adapter. The 5010 must be plugged into a YSI meter only, as it gets its stirring power from the 5000/5100 instrument. -
Page 8: Figure
R e m o v e Stir Paddle Fill M e m b r a n e C a p with Solution Unscrew Cap R e p la c e Stir Paddle Screw Cap o n moderately tight Figure 2 Membrane Installation on the 5905/5010 Probe. -
Page 9: Warm Up
Every time the meter is turned on, the 5905/5010 BOD Probe must be allowed to warm up for about 30 minutes before taking the first reading. This allows the probe to use up all the oxygen retained in the cap. New Probe Break In (Motor Off) For best results, please allow the probe more than the usual 30 minutes to warm-up after the first membrane is installed. - Page 10 matte finish. If the cathode remains tarnished, return the probe for service. Temperature Sensor Anode (Silver) Cathode (Gold) Figure 3 5905/5010 Sensor Silver Anode: It is normal for a dark layer of silver chloride to cover the silver anode. After prolonged use it may become necessary to clean the anode.
-
Page 11: Rocedures And Precautions
PERATING ROCEDURES AND RECAUTIONS IMPORTANT Intended Use The 5905/5010 probe is intended for laboratory use, not field use. It is not waterproof and should never be immersed past the taper on the stem of the probe. Air Calibration When calibrating in air, make sure there are no water droplets on the membrane. - Page 12 average replacement interval is one to two weeks. Probes in constant or heavy use may require more frequent membrane changes. Interferences Hydrogen sulfide, sulfur dioxide, halogens, carbon monoxide, chlorine, nitric oxide, and nitrous oxide can cause the probe to give erroneous readings. If you suspect erroneous readings, it may be necessary to determine if these are the cause.
-
Page 13: Electrode Cleaning
ROBLEM OLVING ROUBLE HOOTING UIDE Below is a quick reference of symptoms with steps to follow to cure these symptoms. Symptoms Actions • Unable to Allow approximately 30 calibrate min. for probe to polarize when first turned on • Change membrane •... - Page 14 Symptoms Actions • Unstable Allow sufficient time for readings temperature and oxygen stabilization • Allow 60 sec for reading to stabilize • Change membrane • Clean probe (see instructions under Electrode Cleaning) • Motor not Check power supply working • Manually turn the stir paddle to help start the motor...
-
Page 15: Servicing
ERVICING The 5905/5010 has four user replaceable parts. The motor assembly can be replaced if it becomes noisy, unbalanced, or malfunctions. The probe assembly, housing assembly, and stir paddle can also be replaced if they become damaged. To disassemble the probe perform the following steps: 1. - Page 16 Housing Assembly Motor Assembly Probe Assembly Stir Paddle Figure 4 Exploded View of 5905/5010 Probe...
-
Page 17: Warranty And Repair
Limitation of Warranty This Warranty does not apply to any YSI product damage or failure caused by (i) failure to install, operate or use the product in accordance with YSI’s written instructions, (ii) abuse or misuse of the product, (iii) failure to maintain the product in accordance with YSI’s written instructions or... - Page 18 AUTHORIZED U.S. SERVICE CENTERS For the nearest authorized service center contact YSI Technical Support • 1725 Brannum Lane • Yellow Springs, Ohio • 45387 • Phone: +1 (937) 767-7241• (800) 897-4151 (US) Fax: +1 (937) 767-9353 • E-Mail: environmental@ysi.com www.ysi.com...
-
Page 19: Cleaning Instructions
Disposition costs will be the responsibility of the sender. When service is required, either at the user's facility or at YSI, the following steps must be taken to insure the safety of our service personnel. -
Page 20: Packing Instructions
4. Any product being returned to the YSI Repair Center, should be packed securely to prevent damage. 5. Cleaning must be completed and certified on any product before returning it to YSI. - Page 21 Cleaning Certificate Organization ________________________________ Department _________________________________ Address ___________________________________ City _______________ State ______ Zip ________ Country __________________ Model No. of Device ______ Lot Number _________ Contaminant (if known) _____________________ Cleaning Agent(s) used _____________________ Radioactive Decontamination Certified? (Answer only if there has been radioactive exposure) ___ Yes ___ No Cleaning Certified By _________________________ Name...
- Page 22 ROBE PECIFICATIONS Cathode: Gold Anode: Silver Membrane: FEP Teflon Dissolved Oxygen Accuracy: ± 0.1 mg/L or ± 2% of reading, whichever is greater Operating Temperature Range: 15° to 35°C Temperature Accuracy: ± 0.2°C Polarizing Voltage: 0.8 volts Response Time: Typical response to a step change in dissolved oxygen at 20°C is 90% of the change in 30 seconds.
- Page 23 PPENDIX The 5905 probe comes in several versions, designed to fit different bottle sizes. 5905 5° taper per side to fit U.S. Standard BOD 5010 bottles. 5905 - J Includes an adapter to fit 5° taper per side 5010 - J smaller bottles with built - in overflow funnels.
- Page 24 PPENDIX...
- Page 25 1725 Brannum Lane Yellow Springs, Ohio 45387 USA 059882 Web 937 767-7241 • 800 765-4974 A59882H Fax 937 767-9353 September 99 Info@YSI.com • www.YSI.com 1997 YSI Incorporated...
