Caution
- Do not force the plug or you could damage it.
- To disconnect the cable, put out the plug. Do not pull on the cable.
Batteries
The battery compartment is located on the
underside of the control box.
1. Carefully remove two battery
compartment covers by pressing the
release clips.
2. Insert 8-AA size batteries into two
compartments as indicated by
the polarity symbols and marked inside
the compartment.
3. Replace the two battery compartment covers until battery covers
snaps into place.
Caution:
- If LCD displays "LOW BATT" at the right lower corner, replace
the batteries.
- Only use fresh batteries of the required size and type. Do not mix the
old and fresh batteries different types of batteries.
- If you do not plan to use the detector for a long time, remove
the batteries.
- Dispose of old batteries promptly and properly. Never bury or
burn them.
Using the Headphones
1. If necessary set the volume to a low setting before using the
headphones
2. Insert the headphones 3.5mm plug into the PHONE jack. At this time
the internal speaker disconnects.
3. Adjust the VOL to a comfortable level
By using headphones you can extend the life of the batteries
Listening Safely
To protect your hearing, follow these guidelines when using headphones.
4
w ww.ba r ska . co m
- DO NOT wear headphones while operating your detector near high-
traffic areas. Pay attention to traffic safety.
- After you begin listening, adjust the volume to a comfortable level.
- Do not listen at extremely high volume levels. Extended high volume
listening can lead to permanent hearing loss.
- Once you set the volume, do not increase it. Over time, your ears
adapt to the volume level, so a volume level that does not cause
discomfort might still damage your hearing.
FUNCTIONS AND INDICATIONS
A Quick Look at the Detector
Displays
The LCD displays are located at the top of the control housing. They
can indicate coins of different type, gold, silver. When the detector
detects an object, an arrow will appear below at the target icon of
the probable type of metal being detected.
The five ellipses in the middle of LCD will effect when pressing the SET
touch pad, by which time two SENS symbols (one on the left side of
LCD and the other on the right side) will light as well. The ellipses
function as the indication of the sensitivity level at this time: if the search
coil detects a coin-sized target, the SENS symbol at right side will
w ww. b a r s k a . c o m
5
