Barska WINBEST Surveyor 300 User Manual

User's Manual for Surveyor 300
Hand Held Metal Detector
Thank you for choosing this pinpoint metal detector. The
unique sealed design allows detecting in any
environment including grass, mud, dirt, sand,
black sand, or even 3 meters under water.
Read all instructions before using this metal detector
Parts Of The Metal Detector
A
A. LED Light
B. Low Battery Indicator
C. LCD
C
D. Power Button
E. Battery Compartment
D
BC814
Features
Vibration, Sound & Light
When a target is located the detector alarms with pulses
of vibration or sounds from buzzer, or both sound and
vibration.
LCD
Displays the detected target signal and battery condition.
Target Distancing
As you get closer to the target, the target signal on LCD,
vibration, sound will increase in quantity.
Target Indication
There are four types of target indication: LCD, sound,
vibration, sound & vibration.
LED Light
In dark places you can turn on the light for better
detection. With two short presses on power button you
can turn on or off the light.
Automatic Tuning
Requires no adjustment.
Memory
The detector memorizes the current setting when power
turns off.
Waterproof
Sealed design allows hunting in the rain or up to 3
B
meters under water.
Battery Installation
To open the battery
compartment, rotate the
battery cover
counter-clockwise.
Connect a standard 9volt
alkaline battery to the
battery connector and
insert the battery into the
detector making sure the
polarity is matched correctly. Then turn the battery cover
clockwise until hand tight to assure a water-tight seal.
E
Operating Instructions
Turn On The Detector
Press power button to turn on the detector. Then, the
detector sounds and vibrates, LED lights. A steady light
indicates unit is ready for operation.
Turn Off The Detector
After use, press the power button holding for about two
seconds to turn off the detector.
Note:
- If no button is pressed or no metal is detected within
about 10 minutes, the detector will automatically
turn off.
- The detector memorizes the current setting when power
turns off.
Low Battery Indication
If the unit sounds and vibrates, also LED flashes
continuously for about 10 seconds, this indicates that the
battery is low. You have to replace the battery.
Detecting A Target
After turning on the detector, you can start detection.
First you can select one type of target indication by
pressing power button. Press power button first time to
get sound indication. When target is located, the detector
indicates with sound and LCD display.
Press power button the second time to get vibration
indication. When target is located, the detector indicates
with vibration and LCD display.
Press power button the third time to get both sound and
vibration indication. When target is located, the detector
indicates with both sound and vibration. Meanwhile LCD
displays the target signal. Signal on LCD, sound and
pulses of vibration increase in quantity as the closer the
detector is to a detected target. The quantity of pulses is
proportional to the target size and distance. The bigger
the target, or the closer the detector is to the target, the
higher the pulse counts.
See reverse side for more information
