CALIBRATION PROCEDURE
NI 9265
4-Channel, 0-20 mA, 16-Bit Analog Current Output Module
This document contains the verification and adjustment procedures for the National Instruments
9265. For more information on calibration solutions, visit
Contents
Software.................................................................................................................................... 1
Documentation.......................................................................................................................... 2
Test Equipment......................................................................................................................... 3
Test Conditions......................................................................................................................... 3
Initial Setup............................................................................................................................... 3
Verification ............................................................................................................................... 4
Accuracy Verification....................................................................................................... 4
Adjustment................................................................................................................................ 5
Accuracy Adjustment ....................................................................................................... 5
EEPROM Update ..................................................................................................................... 6
Reverification ........................................................................................................................... 6
Accuracy Under Calibration Conditions .................................................................................. 6
Worldwide Support and Services ............................................................................................. 7

Software

Calibrating the NI 9265 requires the installation of NI-DAQmx 9.6 or later on the calibration
system. You can download NI-DAQmx from
LabVIEW, LabWindows
need to install support for the application software that you intend to use.
™
™
/CVI
, ANSI C, and .NET. When you install NI-DAQmx, you only
ni.com/calibration
ni.com/downloads
.
. NI-DAQmx supports

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NI 9265 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for National Instruments NI 9265

Summary of Contents for National Instruments NI 9265

  • Page 1 Reverification ........................... 6 Accuracy Under Calibration Conditions .................. 6 Worldwide Support and Services ..................... 7 Software Calibrating the NI 9265 requires the installation of NI-DAQmx 9.6 or later on the calibration system. You can download NI-DAQmx from . NI-DAQmx supports ni.com/downloads ™...

  • Page 2: Documentation

    Documentation Consult the following documents for information about the NI 9265, NI-DAQmx, and your application software. All documents are available on and help files install with the ni.com software. NI cDAQ-9174/9178 USB Chassis Quick Start NI-DAQmx installation and hardware setup...

  • Page 3: Test Equipment

    The following setup and environmental conditions are required to ensure the NI 9265 meets published specifications. • Keep connections to the NI 9265 as short as possible. Long cables and wires act as antennae, picking up extra noise that can affect measurements. •...

  • Page 4: Verification

    Complete the following steps to determine the As-Found status of the NI 9265. Set the DMM to Standby mode (STBY). Connect the NI 9265 to the bench-top power supply and the DMM as shown in Figure 1. Figure 1. NI 9265 Current Accuracy Connections...

  • Page 5: Adjustment

    Call the NI 9265 get C Series adjustment points function to obtain an array of recommended calibration currents for the NI 9265. Connect the DMM and the bench-top power supply to the NI 9265 as shown in Figure 1. Set the DMM to read DC current in the 20 mA range.

  • Page 6: Eeprom Update

    EEPROM Update When an adjustment procedure is completed, the NI 9265 internal calibration memory (EEPROM) is immediately updated. If you do not want to perform an adjustment, you can update the calibration date and onboard calibration temperature without making any adjustments by initializing an external calibration, setting the C Series calibration temperature, and closing the external calibration.

  • Page 7: Worldwide Support And Services

    NI product. Refer to the Export Compliance Information at ni.com/legal/export-compliance for the National Instruments global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other import/export data. © 2008–2013 National Instruments. All rights reserved.
