National Instruments NI-9269 Getting Started
100 ks/s/ch simultaneous, ±10 v, isolated, 4-channel c series voltage output module
Hide thumbs
Also See for NI-9269:
- Getting started manual (23 pages) ,
- Getting started (12 pages) ,
- Calibration procedure (8 pages)
Related Manuals for National Instruments NI-9269
Summary of Contents for National Instruments NI-9269
- Page 1 NI-9269 Getting Started Tél. 01 47 95 99 71 e-mail : ni@es-france.com ES France - Département NI Fax. 01 47 01 16 22 Site Web : www.es-france.com 127 rue de Buzenval BP 26 - 92380 Garches...
-
Page 2: Table Of Contents
NI-9269 Getting Started NI-9269 Getting Started 100 kS/s/ch Simultaneous, ±10 V, Isolated, 4-Channel C Series Voltage Output Module Contents Connector Types ......... -
Page 3: Connector Types
NI-9269 Getting Started Connector Types The NI-9269 has more than one connector type: NI-9269 with screw terminals and NI-9269 with snap in terminals. Unless the connector type is specified, NI-9269 refers to all connector types. NI-9269 Block Diagram AO0+ Overvoltage/... -
Page 4: Analog Output Connections
– NI 9269 NI-9269 Connection Guidelines • Make sure that devices you connect to the NI-9269 are compatible with the module specifications. • You must use 2-wire ferrules to create a secure connection when connecting more than one wire to a single terminal on the NI-9269. -
Page 5: Increasing Output Voltage Range
NI-9269 Getting Started Increasing Output Voltage Range Each channel of the NI-9269 has a nominal output range of ±10 V and can drive up to ±10 mA of current. The total output current of all channels is limited to ±20 mA. For example, if the output current of AO0 is ±10 mA, the output current of AO<1, 2, 3>... - Page 6 NI-9269 Getting Started Operating humidity (IEC 60068-2-30 Test Db) 80 to 100% RH, condensing Tél. 01 47 95 99 71 e-mail : ni@es-france.com ES France - Département NI Fax. 01 47 01 16 22 Site Web : www.es-france.com 127 rue de Buzenval BP 26 - 92380 Garches...
- Page 7 For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the National Instruments Patent Notice at ni.com/patents. You can find information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/legal/export-compliance for the NI global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other import/export data.
