Dimension Description
F
Distance from the centerline to the rear mounting hole.
G
Distance between mounting holes.
H
Distance from the centerline to the front mounting hole.
I
Distance between front and rear mounting holes.
Radar Scanner Dimensions - Underside View
H
31
I
F
G
Measurement
4.59 in (116.5 mm)
9.17 in (233 mm)
1.08 in (27.5 mm)
5.57 in (141.5 mm)
Specifications
