7. Test the Installation

Perform the following tasks before using the product on the water:

• Mechanical checks

• Power on and initial setup
Mechanical Checks
Before powering on the product, perform the following mechanical checks:
1. Confirm that all securing bolts are fully tightened and the appropriate mechanical locking washers are in
place.
2. Confirm all connections are secure.
3. Confirm all connecting cables and wires are secured and protected as necessary.

Power On the Control Head

See your Humminbird operations manual to configure the radar and start transmission.
Test the Installation
22
