Multiple Radar Installation
It is important to note that multiple radars cannot be connected to the same network. If you are installing
more than one radar on the same vessel, review the following important location requirements:
• Scanners should be mounted above each other, and vertically separated by at least 1.6 ft (0.5 m).
This applies to all installation locations on the vessel.
• Multiple scanners should be mounted in a way that minimizes interference between the vertical
beamwidths of the 2 scanners.
• To minimize any potential interference, mount the scanners with as much physical separation as
possible.
Installation Preparation
Example of a Mast Platform Mount with a Safety Lanyard
mounting safety lanyard attachment
platform point to M8 bolt
10
mast
safety lanyard
attachment point
to mast
