SYSTEM PARTS

Indoor Unit
Part Name
1. Indoor Power Supply
2. Electric Box
3. Communication Cable
4. XK-60 Wired Tether Controller
5. Communication Cable
6. Front Panel
7. Service Cover
8. Liquid Pipe
9. Gas Pipe
10. Drain Hose
11. Outdoor Power Supply
Outdoor Unit
The refrigerant pipe, drain pipe, electrical wiring, and duct for this unit should be installed
by a qualified HVAC professional only.
Air outlet
Air inlet
Air outlet
C UTION
1
2 3
4
5
6 7 8 9 10 11
6
