Page 14

The following connection diagram gives an example of how to connect an auxiliary device to the

AXIS Q7401.

AXIS Q7401

*12V max 100mA

* Note: Same voltage as pin 2 of the power connector

3.3V

I/O 3 configured as input

I/O 4 configured as output

AXIS Q7401 Installation Guide

E.g. push button
